Summary of Contents for Leica ScanStation P40
- Page 1 Leica ScanStation P50/P40/P30 Quick Guide Version 2.0 English...
- Page 2 Important Information about your Instrument Important Information about your Instrument Read and follow the User Manual on the accompanying data storage device before using the product. ☞ Keep for future reference! Intended use • Measuring horizontal and vertical angles. Measuring distances. •...
- Page 3 The classification is in accordance with IEC 60825-1 (2014-05). Locations of laser apertures Laser beam Laser beam (Laser plum- met) Exit for laser beam (Laser plummet) 008030_001 Important Information about your Instrument...
- Page 4 Conformity to • FCC Part 15 (applicable in US) national regula- Hereby, Leica Geosystems AG, declares that the radio equipment type • tions ScanStation P50/P40/P30 is in compliance with the essential require- ments and other relevant provisions of Directive 2014/53/EU. The declara- tion of conformity can be consulted at http://www.leica-...
- Page 5 Japanese Radio Law and Japanese Telecommunications Business Law • Compliance. • This device is granted pursuant to the Japanese Radio Law ( 電波法 and the Japanese Telecommunications Business Law 電気通信事業法 This device should not be modified (otherwise the granted designa- •...
-
Page 6: Instrument Components
Instrument Components Instrument Components Components of the Antenna ScanStation Removable handle P50/P40/P30 Rotating mirror (laser and camera aperture) Battery compartment B Circular level Socket for power supply, 5 pin female with blue colour ring Socket for time synchroni- zation, 9 pin female ON/OFF button USB socket Loudspeaker... -
Page 7: Technical Data
Technical Data Environmental Temperature range: specifications Type Operating temperature Storage temperature ScanStation [°C] [°C] P50/P40/P30 Instrument -20 to +50 -40 to +70 AC-power supply 0 to +40 -25 to +65 Protection against water, dust and sand: Type Protection Instrument IP54 (IEC 60529) Dust protected Protection against splashing water from any direction Humidity:... -
Page 8: Care And Transport
Care and Transport Care and Transport Care and transport Carry the product in its original container or carry the tripod with its legs • splayed across your shoulder, to protect the product against shock and vibra- tion. Periodically carry out test measurements and perform the field adjustments •... -
Page 9: Operation
Operation ☞ The battery must be charged before using it for the first time. Turning on and off the instrument 2s > ON 2s > OFF 008031_001 Operation... -
Page 10: Ec Declaration Of Conformity
EC Declaration of Conformity EC Declaration of This corresponds to EN ISO/IEC 17050-1. Conformity We, Leica Geosystems AG, CH-9435 Heerbrugg (Switzerland), declare under our sole responsibility that the product(s) ScanStation P50/P40/P30, following the provision of Directive(s) 2006/42/EC Machinery (MD) •... - Page 11 EN 61000-6-3:2007 + A1:2011 • EN 300328 2.1.1 • EN 301 489-1 V2.1.1:2017-02 • EN 301 489-17 V3.1.1:2017-02 • Leica Geosystems AG ☞ For a signed version and translations into the official EU lan- guages please refer to: http://www.leica-geosystems.com/ce EC Declaration of Conformity...
- Page 12 827778-2.0.0en Original text Printed in Switzerland © 2017 Leica Geosystems AG, Heerbrugg, Switzerland www.leica-geosystems.com...
