LEDs and Push Buttons
Table 1-2. Push Button Connections
Push Button Label
PB1
PB2
PB3
PB4
Table 1-3 summarizes the LED connections to the processor. To use the
LEDs connected to the DAI or DPI, configure the respective registers of
the processor. For more information, refer to the ADSP-21368 SHARC
Processor Hardware Reference (includes ADSP-21375).
Table 1-3. LED Connections
LED Reference Designator
LED1
LED2
LED3
LED4
LED5
LED6
LED7
LED8
An example program is included in the EZ-KIT Lite installation
directory to demonstrate the functionality of the LEDs and push
buttons.
1-12
Push Button Reference Designator
SW8
SW11
SW10
SW9
Processor Pin
DPI6
DPI7
DPI8
DPI13
DPI14
DAI15
DAI16
FLAG3/~MS3/~IRQ3
ADSP-21375 EZ-KIT Lite Evaluation System Manual
Processor Pin
FLAG1/~IRQ1
FLAG0/~IRQ0
DAI19
DAI20
