• Serial peripheral interface (SPI) flash memory
2 Mbit
• Analog audio interface
AD1835A codec
4x2 RCA phono jack for 4 channels of stereo output
2x1 RCA phono jack for 1 channel of stereo input
3.5 mm headphone jack for 1 channel stereo output
• Universal asynchronous receiver/transmitter (UART)
ADM3202 RS-232 driver/receiver
DB9 female connector
• National Instruments Educational Laboratory Virtual Instrumen-
tation Suite (ELVIS) Interface
LabVIEW™-based virtual instruments
Multifunction data acquisition device
Bench-top workstation and prototype board
• LEDs
11 LEDs: 1 power (green), 1 board reset (red), 1 USB mon-
itor (amber), and 8 general purpose (amber)
• Push buttons
5 push buttons: 1 reset, 2 connected to DAI,
2 connected to the
ADSP-21375 EZ-KIT Lite Evaluation System Manual
pins of the processor
FLAG
