Part Description
Two-channel RCA interconnect cable MONSTER CABLE
Headphone Out Jack (J9)
Part Description
3.5 mm stereo jack
Power Jack (J4)
The power connector (
the EZ-KIT Lite board.
Part Description
2.5 mm power jack
7V power supply
The power connector supplies DC power to the EZ-KIT Lite board.
Table 2-14
shows the power supply specifications.
Table 2-14. Power Supply Specifications
Terminal
Center pin
Outer ring
ADSP-21375 EZ-KIT Lite Evaluation System Manual
ADSP-21375 EZ-KIT Lite Hardware Reference
Manufacturer
Mating Cable
Manufacturer
A/D ELECTRONICS
) provides all of the power necessary to operate
J4
Manufacturer
SWITCHCRAFT
DIGI-KEY
Mating Power Supply (shipped with EZ-KIT Lite)
CUI INC.
Connection
+7 VDC@2.14A
GND
Part Number
BI100-1M
Part Number
ST-323-5
Part Number
RAPC712X-ND
DMS070214-P6P-SZ
2-23
