Absolute (abs) Block

Icon
A
Output = A absolute
The absolute block converts a value entered at "A" to an absolute value, e.g. a negative value becomes a positive value.
y
X to the Power of Y (x )
y
An X block gives a value of X to the power of Y, in other words X multiplied by itself Y amount of times. In the example below, 2 to the power of
3 (or 2 cubed) equals 8.
Icon
A
B
Output=A
Min, Max, Equals, blocks
Icon
A
B
If A < B Output = A
If B < A Output = B
<, >, ≤, ≥ blocks
A
Icon
B
If A < B Output = On
Warning
Ensure that all power is
switched off before
installing or maintaining
this product
b
Icon
A
B
If A > B Output = A
If B > A Output = B
Icon
A
B
If A > B Output = On
Revision 2.6
Icon
A
B
If A = B Output = on
If A = B Output = off
Icon
A
B
If A ≤ B Output = On
www.resourcedm.com
Icon
A
B
If A ≥ B Output = On
