Chapter 26 Configuring SPAN and RSPAN
Command
Step 5
end
Step 6 show monitor [session session_number]
show running-config
Step 7 copy running-config startup-config
To delete an RSPAN session, use the no monitor session session_number global configuration
command. To remove a destination port from the RSPAN session, use the no monitor session
session_number destination interface interface-id global configuration command. The ingress options
are ignored with the no form of the command.
This example shows how to configure VLAN 901 as the source remote VLAN in RSPAN session 2, to
configure Gigabit Ethernet source port 2 as the destination interface, and to enable forwarding of
incoming traffic on the interface with VLAN 6 as the default receiving VLAN.
Switch(config)# monitor session 2 source remote vlan 901
Switch(config)# monitor session 2 destination interface gigabitethernet1/2 ingress vlan 6
Switch(config)# end

Specifying VLANs to Filter

Beginning in privileged EXEC mode, follow these steps to configure the RSPAN source session to limit
RSPAN source traffic to specific VLANs:
Command
Step 1 configure terminal
Step 2 no monitor session {session_number | all |
local | remote}
Step 3 monitor session session_number source
interface interface-id
Step 4 monitor session session_number filter vlan
vlan-id [, | -]
OL-13018-01
Purpose
Return to privileged EXEC mode.
Verify the configuration.
(Optional) Save the configuration in the configuration file.
Purpose
Enter global configuration mode.
Remove any existing SPAN configuration for the session.
For session_number, the range is 1 to 66.
Specify all to remove all SPAN sessions, local to remove all local
sessions, or remote to remove all remote SPAN sessions.
Specify the characteristics of the source port (monitored port) and
SPAN session.
For session_number, the range is 1 to 66.
For interface-id, specify the source port to monitor. The interface
specified must already be configured as a trunk port.
Limit the SPAN source traffic to specific VLANs.
For session_number, enter the session number specified in step 3.
For vlan-id, the range is 1 to 4094.
(Optional) Use a comma (,) to specify a series of VLANs or use a
hyphen (-) to specify a range of VLANs. Enter a space before and after
the comma; enter a space before and after the hyphen.
Cisco IE 3000 Switch Software Configuration Guide
Configuring SPAN and RSPAN
26-21
