BASIC OPERATION

D Band edge warning beep

When you tune outside of an amateur band's fre-
quency range, a warning beep sounds.
This function can be turned OFF in set mode, if desired.
q Push [EXIT/SET] several times to close a multi-
function screen, if necessary.
w Push [SET] (F-6) to select set mode menu screen.
• Pushing and holding [EXIT/SET] for 1 sec. also selects
set mode menu screen.
e Push [OTHERS] (F-5) to enter others set mode.
r Push [Y] (F-1) or [Z] (F-2) to select "Beep (Band
Edge)."
t Rotate the main dial to select the band edge warn-
ing beep function.
y Push [EXIT/SET] to exit the set mode.
The beep output level can be set in level set mode.
(p. ??)
When the band edge warning beep is set to "ON":
The band edge warning beep is activated according
to the set mode setting as follows.
• ON (Default)
Band edge beep sounds when an operating frequency
enters or exits a default amateur band. (default)
• ON (User)
A beep sounds when an operating frequency enters or
exits an amateur band that is set in band edge screen.
• ON (User) & TX Limit
A beep sounds when an operating frequency enters
or exits an amateur band that is set in band edge
screen and transmission is limited out of the band.
To programming the band edge:
When "ON (User)" or "ON (User) & TX Limit" is
selected, [BAND] appears in the display above the
function switch (F-5), and up to 30 band edge fre-
quencies can be set in band edge screen.
q Push [BAND] (F-5) to enter the band edge screen.
w Push [Y] (F-1) or [Z] (F-2) to select the desired
band edge.
• Push [Ω ≈] (F-3) to select the set content for band
edge, lower or upper.
• Push [INS] (MF6) to insert a new blank band edge line.
• Push and hold [DEL] (MF7) for 1 sec. to delete the
selected band edge line.
• Push and hold [DEF] (F-4) for 1 sec. to display the
band edge initialize screen. Then, push and hold
[OK] (F-5) to initialize all band edge frequency settings.
e Input the desired frequency with the keypad.
• Push [GENE •] to input ". (decimal point)" between the
MHz units and kHz units.
• Program the frequency in ascending order.
• The frequency that is duplicated or out of an amateur
band cannot be programmed.
r Push [EXIT/SET] to exit the set mode.
31
OTHERS
F-5
F-1 F-2
ON (Default) (default)
ON (User)
BAND
OTHERS
[DEL] [INS]
F-5
F-1 F-2 F-3 F-4
DEF
Band edge screen
NOTE: All 30 band edge frequencies are set in
default. So you should delete a one of band edges
before programming.
SET
F-6
Main dial
EXIT/SET
SET
F-6
[DIAL]
EXIT/SET
