Icom IC-7600 Instruction Manual page 64

4
RECEIVE AND TRANSMIT
D Data saving
The contents of the PSK memory/received signal can
be saved into the USB-Memory.
q During PSK decode screen indication, push
[<MENU1>] (F-1) to select the PSK decode sec-
ond menu.
w Push [SAVE] (F-4) to select decode file save screen.
e Change the following conditions if desired.
• File name:
z Push [EDIT] (F-4) to select file name edit con-
dition.
• Push [DIR/FILE] (F-1) several times to select the
file name, if necessary.
x Push [ABC] (MF6), [123] or [Symbol] (MF7)
to select the character group, then rotate the
main dial to select the character.
• [ABC]
(MF6)
0 to 9 (numerals); [Symbol] (MF7): ! # $ % & ' ` ^
– ( ) { } _ ~ @ can be selected.
• Push [Ω] (F-1) to move the cursor left, push
[≈] (F-2) to move the cursor right, [DEL] (F-3)
delete a character and push [SPACE] (F-4) to
insert a space.
c Push [EXIT/SET] to set the file name.
• File format
z Push and hold [SAVE/OPT] (F-5) for 1 sec. to
enter save option screen.
x Rotate the main dial to select the saving for-
mat from Text to HTML.
• "Text" is the default setting.
• Push and hold [DEF] (F-4) for 1 sec. to select the
default setting.
c Push [EXIT/SET] to return to the previous
indication.
• Saving location
z Push [DIR/FILE] (F-1) to select tree view
screen.
x Select the desired directory or folder in the
USB-Memory.
• Push [Ω ≈] (F-4) to select the upper directory.
• Push [Y] (F-2) or [Z] (F-3) to select folder in the
same directory.
• Push and hold [Ω ≈] (F-4) for 1 sec. to select a
folder in the directory.
• Push [REN] (MF5) to rename the folder.
• Push and hold [DEL] (MF6) for 1 sec. to delete
the folder.
• Push and hold [MAKE] (MF7) for 1 sec. to mak-
ing a new folder. (Edit the name with the same
manner as the "• File name" above.)
c Push [DIR/FILE] (F-1) twice to select the file
name.
r Push [SAVE/OPT] (F-5).
• After saving is completed, returns to PSK decode sec-
ond menu automatically.
For your convenience!
Two data formats, Text and HTML, are available for
PC data storage.
61
: A to Z (capital letters); [123] (MF7):
The USB-Memory is not supplied by Icom.
123
Symbol ABC F-1
F-1
/
<MENU1> DIR/FILE SAVE
• Decode file save screen— file name edit
F-4
DEF SAVE/OPT
F-2
MAKE REN DEL
F-1
DIR/FILE SAVE/OPT
• Save option screen
When a PC keyboard is connected to [USB] connector
on the front panel, the file name can also be edited from
the keyboard. In this case, a USB hub is required.
DEL SPACE
F-2 F-3 F-4
Main dial
F-4 EXIT/SET
/
EDIT
Main dial
F-5 EXIT/SET
F-3 F-4
F-5
