Icom IC-7600 Instruction Manual page 17

o RTTY TUNING INDICATOR
Shows the tuning condition in RTTY mode.
!0 MODE INDICATOR
Shows the selected mode.
!1 FREQUENCY READOUTS
Shows the operating frequency.
• Gray characters are used for non-active readout.
!2 MEMORY CHANNEL READOUTS
Shows the selected memory channel contents in
VFO mode.
Shows the VFO contents in memory mode.
!3 SELECT MEMORY CHANNEL INDICATOR
Indicates the displayed memory channel is set as a
select memory channel.
!4 MULTI-FUNCTION SCREEN
Shows the screens for the multi-function digital
meter, spectrum scope, voice recorder, memory list,
scan, memory keyer, RTTY decoder, PSK decoder,
IF filter selection or set modes, etc.
!5 VFO/MEMORY CHANNEL INDICATOR
Indicates the VFO mode or selected memory chan-
nel number.
!6 LCD FUNCTION SWITCH GUIDE
Indicates the function of the LCD function switches
([F-1] to [F-6]).
!7 MULTI-FUNCTION SWITCH GUIDE
Indicates the function of the multi-function switches.
!8 TX INDICATOR
Indicates the frequency readout for transmit.
• " " appears during an operating frequency is not in
an amateur band. When the band edge warning beep is
set to "OFF" (p. ??), "
• Appears on the sub band readout when the split func-
tion is turned ON.
!9 RIT INDICATOR
" " appears when RIT function is in use.
@0 ∂TX INDICATOR
" appears when ∂TX function is in use.
"
@1 RIT/∂TX SHIFT FREQUENCY INDICATOR
Shows the shift frequency for the RIT or ∂TX func-
tion.
(p. ??)
(p. ??)
" does not appear.
PANEL DESCRIPTION
@2 NOTCH INDICATOR
(p. ??)
" " appears when the manual notch function
is in use. This function is available in SSB, CW,
RTTY, PSK and AM modes.
" " appears when the auto notch function is in
use. This function is available in SSB, AM and
FM modes.
@3 APF/TPF INDICATOR
" " appears when the audio peak filter func-
tion is in use. This function is available in CW
mode. (p. ??)
" " appears when the twin peak filter func-
tion is in use. This function is available in RTTY
mode. (p. ??)
@4 DUAL WATCH INDICATOR
" " appears when the dualwatch function
is in use.
