General Information

The FD201CV-C-1 is a special mission which has features that allow installation in a
standard rack mount configuration. There are 16 (sixteen) line interface buttons that
interface with the mission computer.

Front View

Additional Information

The FD201CV-C-1 utilizes a state of the art digital video decoding chipset for the analog
video input. Two video sources are activated: the VGA (computer graphics i.e. moving
maps) and composite video (i.e. camera inputs).
The LCD is protected with a .060" non-glare Lexan lens to prevent scratching of the LCD,
and to meet stringent FAA abrasive load criteria.
The high-definition monitor also features dual USB 2.0 powered ports to allow for quick
and easy access to files via thumb drive. Each port supplies up to 500ma to power
external devices. It also has 16 buttons which can be programmed to meet the operator's
needs.
© 2017 FDS Avionics Corp.
All Rights Reserved.
Document Number:
MAN – FD201CV-C-1
Revision Date:
Rev:
05/05/2017
E
Page 3 of 16
