- Page 1 Revision Date: Rev: Document Number: 05/04/2017 MAN – FD215CV-C-Q-VGA Page 1 of 12 Installation and Operation Manual FD215CV-C-Q-VGA 21.5” LCD Quad-Screen Display © 2017 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. 470-239-7421 or FDSAvionics.com...
-
Page 2: Table Of Contents
Power ............................6 Power Pinout ...........................6 Operation Instructions ......................7 Button Control ........................7,8 Technical Drawing.........................9 Technical Support ........................10 Instructions for Continued Airworthiness ..............10 Warranty ..........................11 Log of Revisions ........................12 © 2017 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. 470-239-7421 or FDSAvionics.com... -
Page 3: General Information
Front View Additional Information The FD215CV-C-Q-VGA utilizes a state of the art digital video decoding chipset for three (3) analog video inputs and one (1) HD-SDI input. The LCD is protected with a .060” non- glare Lexan lens to prevent scratching of the LCD and to meet stringent FAA abrasive load criteria. -
Page 4: Specifications
In Progress Installation Instructions All cabin equipment, such as the FD215CV-C-Q-VGA, should be installed on a non- essential bus and have a dedicated circuit breaker. It is a requirement that a switch be installed in the cockpit so that the pilot can de-energize the system should it become necessary. -
Page 5: Power And Ground Wiring
It is the installer's responsibility to understand the product's requirements to install the product in compliance with industry standards and safety. VGA Wiring The FD215CV-C-Q-VGA uses standard VGA cables for input. Rear View with Connectors (refer to page 9) © 2017 FDS Avionics Corp. -
Page 6: Power
28VDC Power 28VDC Power 28VDC Ground 28VDC Ground Pin out for HD-SDI Input (Standard BNC – 75 OHM) – 31-242 Description Center Video Signal Shell Video Return © 2017 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. 470-239-7421 or FDSAvionics.com... -
Page 7: Operation Instructions
No pilot or aircrew action is necessary during flight or ground operation. The operator will be able to change the video output from the FD215CV-C-Q-VGA using the video source select button on the display. When applying 28VDC power, the display will turn on and look for a valid input on the last known source. - Page 8 Press 1 and 2 simultaneously for at least 1 second to select an appropriate video resolution. (VGA, SVGA, XGA, UXGA.) Press 3 and 4 simultaneously for at least 4 seconds to reset the unit. © 2017 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. 470-239-7421 or FDSAvionics.com...
-
Page 9: Technical Drawing
Revision Date: Rev: Document Number: 05/04/2017 MAN – FD215CV-C-Q-VGA Page 9 of 12 Technical Drawing © 2017 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. 470-239-7421 or FDSAvionics.com... -
Page 10: Technical Support
05/04/2017 MAN – FD215CV-C-Q-VGA Page 10 of 12 Technical Support Should you have any questions concerning this product or other FDS Avionics Corp. products, please contact our Product Support representatives at (470) 239-7421. FDS Avionics Corp. 6435 Shiloh Road Alpharetta, GA 30005... -
Page 11: Warranty
Warranty Information All FDS Avionics Corp. products are warranted to be free from material or manufacturing defects for a period of 24 months from the date of shipment for General Aviation customers or 12 months from the date of shipment for Government/Special Mission customers. -
Page 12: Log Of Revisions
Some states do not allow limitation on the length of an implied warranty. In such states, the exclusions or limitations of this limited warranty may not apply. Log of Revisions Date Page Description 02/09/2012 Initial Release 05/04/2017 Corporate name change, warranty, phones numbers © 2017 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. 470-239-7421 or FDSAvionics.com...
