Configure the RADIUS server properly to provide authentication and accounting functions for
users. In this example, the username is configured as user1 on the RADIUS server.
•
Customize the authentication pages, compress them to a file, and upload the file to the root
directory of the storage medium of the switch. In this example, the file is abc.zip.
Configuration procedure
1. Create VLANs, assign IP addresses to the VLAN interfaces, and assign interfaces to the
VLANs. (Details not shown.)
2. Configure a RADIUS scheme:
# Create a RADIUS scheme named rs1.
<Device> system-view
[Device] radius scheme rs1
# Specify the primary authentication server and primary accounting server, and configure the
keys for communication with the servers.
[Device-radius-rs1] primary authentication 192.168.0.112
[Device-radius-rs1] primary accounting 192.168.0.112
[Device-radius-rs1] key authentication simple radius
[Device-radius-rs1] key accounting simple radius
# Exclude the ISP domain name from the username sent to the RADIUS server.
[Device-radius-rs1] user-name-format without-domain
[Device-radius-rs1] quit
3. Configure an authentication domain:
# Create an ISP domain named dm1.
[Device] domain dm1
# Configure AAA methods for the ISP domain
[Device-isp-dm1] authentication portal radius-scheme rs1
[Device-isp-dm1] authorization portal radius-scheme rs1
[Device-isp-dm1] accounting portal radius-scheme rs1
[Device-isp-dm1] quit
4. Configure a local portal Web server:
# Configure a local port Web server to use HTTP to exchange authentication information with
clients.
[Device] portal local-web-server http
# Specify the file abc.zip as the default authentication page file for the local portal Web server.
(This file must exist in the directly root directory of the storage medium.)
[Device-portal-local-websvr-http] default-logon-page abc.zip
# Specify 80 as the port number listened by the portal Web server for HTTP.
[Device–portal-local-websvr-http] tcp-port 80
[Device-portal-local-websvr-http] quit
5. Configure Web authentication:
# Create Web authentication server named user.
[Device] web-auth server user
# Specify
[Device-web-auth-server-user] url http://20.20.0.1/portal/
# Specify the IP address of the Web authentication server as 20.20.0.1 (the IP address of
Loopback 0) and the port number as 80.
[Device-web-auth-server-user] ip 20.20.0.1 port 80
[Device-web-auth-server-user] quit
http://20.20.0.1/portal/ as the redirection URL for the Web authentication server.
