Alarms

The front panel alarm LED alerts for events as determined in the web page (see
page 66). There are three levels of alarm severity:
•
•
•
The table below lists alarms generated by the StudioStation 100, what they mean, and how
they are cleared.
NOTE: All active alarms can be manually cleared by an administrator via the web page.
Alarm
Audio Loss The StudioStation 100 generates this alarm only
during a recording if one of these occurs:
•
Audio is absent before a recording starts (signal
is at or below -60 dBFS), an alarm triggers after
5 minutes of the start of the recording.
•
Alarm triggers after 10 seconds of audio loss.
Auth Failures Any combination of access interfaces (web page,
Telnet, API, SFPT, SIS via SSH) that require
authentication, with a maximum of 20 failed login
attempts within 20 seconds on any combination of
user IDs (including non-existent user IDs).
•
Disk Error A read of write error is detected on the
selected storage volume.
•
The target storage volume is not found (for
example: Front USB is selected but the
StudioStation 100 does not detect any external
storage).
•
Disk Space The StudioStation 100 is recording and the
external USB storage volume has dropped to
<10 minutes of recording time.
•
At the start of an event, if the target volume
does not have sufficient space to record.
File Upload When the file transfer method is configured and
the StudioStation 100 fails to upload files after five
sequential attempts.
Firmware Failure When the StudioStation 100 is in a failed firmware
state.
HDCP Video If the signal is HDCP protected and the
StudioStation 100 cannot negotiate HDCP.
•
NTP Sync If the StudioStation 100 attempts to
automatically sync with the configured NTP
server and fails the primary and retry attempts.
•
If the StudioStation 100 fails multiple manual
sync attempts.
Record Halt When a recording is terminated without a
command to stop.
Temperature Internal When the StudioStation 100 internal temperature
exceeds 60° C for 2 minutes.
USB Overcurrent When a USB port current draw exceeds the 1.5 A
(front, rear and RCP) limit of the ports.
Video Loss When video sync is lost during a recording for a
period of 2 seconds.
Notify — The StudioStation 100 sends an e-mail and unsolicited SIS response.
Display — The alarm indicator is active on the front panel, AAP or wallplate, and web
page.
Log — The StudioStation 100 records the alarm to file.
Alarm Generated Alarm Cleared
•
During a recording, the audio signal is
maintained above -60 dBFS for a contiguous
period of 10 seconds
•
The recording session ends.
Can only be cleared by an administrator via the
web page (see Alarms and Traps
or SIS commands (see
page 79).
•
Replace the affected internal or external
storage.
•
Choose a different target storage volume.
•
Remove the write protection from the volume.
•
Replace the affected storage.
•
Choose an alternate target storage volume
with adequate space.
•
Stop recording.
•
The file transfer method is updated.
•
The next automatic or manual file transfer is
successful.
•
Reboot the unit.
•
Reset the unit.
•
Update the firmware.
The HDCP source is no longer active or is taken
off the input.
The NTP Sync succeeds without retries for a
period of five synchronization attempts.
Can only be cleared by an Administrator via the
web page (see Alarms and Traps
When the StudioStation 100 system temperature
drops below 50° C.
When the offending device is removed from the
StudioStation 100.
Video sync is detected for 6 seconds.
StudioStation 100 • Front Panel and Operations
Alarms on
on page 55)
Clear active alarms on
on page 55)
