Licensed Third-party Software Used in the StudioStation 100
Package License
libpng libpng license
librsync LGPLv2.1
libssh2 BSD
libungif MIT
libusb LGPLv2.1
libv4l GPLv2
lighttpd BSD-3c

General Product Overview

Input

The StudioStation 100 has one HDMI input and one analog audio captive screw input.
Signals from the input channel and metadata (descriptive information about data content)
are combined in a user-configurable layout and encoded into streams.

Encoding and Output

The StudioStation 100 supports simultaneous streaming and recording, with one HDMI
output. The record and stream encoder settings can be configured as different bit rates,
resolutions, and frame rates.
The HDMI output defaults to the record settings.
See the
types. The video output can be scaled and its aspect ratio modified. The StudioStation 100
also outputs high quality encoded HDMI video with embedded audio on a single output for
display on any HDMI display, supporting resolutions up to 1920x1080 at 60 Hz.
Package
tzdata
udev
usbutils
util-linux
vsftpd
xinetd
zlib
An overview of encoding
License
Public domain
GPLv2
GPLv2
GPLv2, BSD-4c, libblkid and libmount
LGPLv2.1, libuuid BSD-3c
GPLv2
xinetd license
zlib license
on page 51 for a comparison of the two encoding
StudioStation 100 • Introduction 5
