Browsers

In order to view the StudioStation 100 embedded web pages, use one of the supported
Web browsers (and versions) listed below.

DataViewer

DataViewer is an enhanced terminal emulation program that facilitates analysis of RS‑232,
USB, and TCP/IP communication with Extron devices. The software allows users to send
commands to a device and view the responses in ASCII or hexadecimal format. Command
and response logs can be saved in text or HTML format.
Dataviewer is available at www.extron.com. Download the installation file and load the
program on the PC connected to the StudioStation 100.
Start the DataViewer program
1.
2.
Google Chrome™ version 48 or higher
®
•
Mozilla Firefox version 44 or higher
® ®
•
Microsoft Internet Explorer
• ®
NOTE: The AV Controls Preview video is not supported by Internet Explorer 11.
To see a preview of the current stream you can either:
• Use a different browser or
• Open a stand‑alone, third‑party video player (such as VideoLAN™
opensource VLC™ media player) and connect to the streaming file from the
StudioStation 100.
Safari version 9 or higher (for Mac
®
•
NOTE: Safari is the preferred browser for Mac OS X operating systems.
Additionally, the device Web UI will be compliant, but not fully featured, with the
•
internal browser client:
QTWeb v4.x
•
Click the DataVeiwer desktop icon.
The Communication Setup dialog box opens. Select a Communication tab (see
figure 70 on the next page).
Select the Comm Port (RS‑232) tab (shown with the correct protocol settings
•
below) if using the rear panel RS‑232 port (
Select the TCP/IP tab if using a network connection (
•
Select the USB tab if using the front panel config port (
•
(for Windows operating systems)
® ®
OS X operating systems)
® ®
).
Õ
Ö
×
