Push Stream and Pull Stream Playback URLs
To verify a running stream, use the templates below to place the stream into the VLC
Open Network Stream dialog box (see step 5 of
VLC Media Player
<
StudioStation100_IP
<
DESTINATION_IP
Pull Stream URLs
PULL Streaming:
RTSP Unicast
RTSP Multicast
Push Stream URLs
PUSH Streaming:
Unicast (Destination IP must be set to the location where the stream is played)
TS/UDP
TS/RTP
ES/RTP
Multicast (Destination IP must be multicast IP address)
TS/UDP
TS/RTP
ES/RTP
NOTES:
• <
StudioStation100_IP
• Some dependencies may apply with certain versions of VLC.

Streaming Capabilities and System Scalability

The following tables detail the streaming capabilities of the StudioStation 100. Data for the
tables was obtained through laboratory testing using optimal bandwidth conditions and can
vary depending on the selected video bit rate.
NOTE: Testing to determine the approximate maximum number of pull streams
was done on the encoder with one pull unicast Streaming stream. Recording while
streaming does not reduce the maximum number of Pull streams.
Available Unicast Streams
Video resolution and bit rate affect the total number of unicast streams the
StudioStation 100 can broadcast. The following table compares the selected resolution and
bit rate with the approximate number of unicast streams that will be available. Changing the
resolution or using higher or lower bit rates may increase or decrease the available number
of streams.
on page 107). Substitute the StudioStation 100 IP address for
>. Substitute the destination IP address and port number for
>:< >.
DESTINATION_PORT
URL
rtsp://<StudioStation100_IP>/<stream name>
rtsp://<StudioStation100_IP>/<stream name>/multicast
or
HTTP://<StudioStation100_IP>/live/pull/multicast.sdp
URL
UDP://@<Destination_IP>
RTP://@<Destination_IP>
HTTP://<StudioStaion100_IP>/live/push/S3.sdp
UDP://@<Destination_IP>:<Destination_Port>
RTP://@<Destination_IP>:<Destination_Port>
HTTP://<StudioStaion100_IP>/live/push/S3.sdp
> is the IP address of the StudioStation 100.
StudioStation 100 • Reference Information
Playing a Pull Stream Using
105
