Tx Function; D ∂Tx Monitor Function; Monitor Function - Icom IC-7300 Basic Manual

4
RECEIVING AND TRANSMITTING

∂TX function

The ∂TX function shifts the transmit frequency up to
. kH without shifting the receive frequency.
1. Push TX .
• The ∂TX function turns ON.
turns the
Pushing TX
While using the Fine Tuning function (p. 3-3), the ∂TX
frequency is displayed in 4 digits, instead of 3.
2. Set the ∂TX frequency to match the receiving
station's frequency.
To reset the ∂TX frequency to "0.00," hold down
CLEAR for 1 second.
You can add the frequency shift to the operating
frequency by holding down
3. After communicating, push
function OFF.
D ∂TX monitor function
When the ∂TX function is ON, you can directly monitor
the operating frequency by holding down
∂TX function ON or OFF.
∂TX frequency
Set ∂TX
frequency.
for 1 second
TX
TX to turn the ∂TX
XFC
.
XFC
.
While holding down

Monitor function

The Monitor function enables you to monitor your
transmit audio. Use this function to check the
voice characteristics while adjusting transmit audio
parameters.
You can hear the CW sidetone regardless of the Monitor
function setting.
1. Select the mode that you want to monitor.
FUNCTION
2. Push
• Opens the FUNCTION screen.
3. Touch [MONI] to turn ON the Monitor function.
Touching [MONI] turns the Monitor function ON or OFF.
Rotate
4. Touch [MONI] for 1 second.
.
5. Adjust MONITOR to the clearest audio output
between 0
normal voice level.
NOTE When using the VOICE DELAY (p. 4-7), turn OFF
the Monitor function. Otherwise the transmitted audio will
echo.
4-8
.
and 100 , while speaking at your
Rotate
Push
