- Page 1 Industrial PC Platform NY-series IPC Machine Controller Industrial Panel PC / Industrial Box PC Setup User’s Manual NY532-1500 NY532-1400 NY532-1300 NY512-1500 NY512-1400 NY512-1300 Industrial Panel PC Industrial Box PC W568-E1-01...
-
Page 2: Ny532
No patent liability is assumed with respect to the use of the information contained herein. Moreover, because OMRON is constantly striving to improve its high-quality products, the information contained in this manual is subject to change without notice. Every precaution has been taken in the preparation of this manual. Neverthe- less, OMRON assumes no responsibility for errors or omissions. -
Page 3: Intended Audience
Introduction Introduction Thank you for purchasing an NY-series IPC Machine Controller Industrial Panel PC / Industrial Box This manual provides a collective term of Industrial Panel PC and Industrial Box PC which are applica- ble products as the NY-series Industrial PC. This manual also provides the range of devices that are directly controlled by the Machine Automation Control Software embedded in the NY-series Industrial PC as the Controller. -
Page 4: Relevant Manuals
Relevant Manuals Relevant Manuals The following table provides the relevant manuals for the NY-series Controller. Read all of the manuals that are relevant to your system configuration and application before you use the NY-series Controller. Most operations are performed from the Sysmac Studio Automation Software. Refer to the Sysmac Studio Version 1 Operation Manual (Cat. - Page 5 Relevant Manuals Manual Basic information Purpose of use Maintenance Using motion control ¡ ¡ ¡ Using EtherCAT ¡ Using EtherNet/IP ¡ Refer to the NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (Cat. No. W568) for how to set up and how to use the utilities on Windows.
-
Page 6: Manual Structure
Manual Structure Manual Structure Some of the descriptions of functions in this manual are common to NJ/NX-series. Therefore, note the following conditions. • The same function names are used for the common functions of the NJ/NX/NY-series. If the term “CPU Unit” is included in the function names, such as the CPU Unit names, CPU Unit write protec- tion, and other functions, it indicates the “Controller”... -
Page 7: Special Information
Manual Structure Special Information Special information in this manual is classified as follows: Precautions for Safe Use Precautions on what to do and what not to do to ensure safe usage of the product. Precautions for Correct Use Precautions on what to do and what not to do to ensure proper operation and performance. Additional Information Additional information to read as required. -
Page 8: Table Of Contents
CONTENTS CONTENTS Introduction ......................1 Intended Audience ............................1 Applicable Products .............................1 Relevant Manuals..................... 2 Manual Structure...................... 4 Page Structure .............................4 Special Information ............................5 Precaution on Terminology ..........................5 Terms and Conditions Agreement................ 11 Warranty, Limitations of Liability ........................ 11 Application Considerations ........................11 Disclaimers ..............................12 Safety Precautions.................... - Page 9 CONTENTS Section 2 Initial Settings 2-1 Initial Settings for Windows....................2 - 2 2-1-1 Windows Settings........................2 - 2 2-1-2 Creating Recovery Image of Initial State..................2 - 3 2-1-3 Installing Software ........................2 - 3 2-1-4 User Account Settings........................2 - 4 2-1-5 Customize Windows........................2 - 4 2-2 Starting and Exiting ......................2 - 5 2-2-1 Starting ............................2 - 5...
- Page 10 CONTENTS 5-4-1 Interface Members ........................5 - 6 5-4-2 Usage Method ..........................5 - 7 Section 6 Industrial PC API 6-1 Outline of Industrial PC API ....................6 - 2 6-2 How to Use the Industrial PC API..................6 - 3 6-3 Industrial PC System API .....................6 - 4 6-3-1 Members of the Industrial PC System API .................6 - 4 6-3-2...
- Page 11 CONTENTS Index NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (W568)
- Page 12 CONTENTS NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (W568)
-
Page 13: Terms And Conditions Agreement
Omron’s exclusive warranty is that the Products will be free from defects in materials and workman- ship for a period of twelve months from the date of sale by Omron (or such other period expressed in writing by Omron). Omron disclaims all other warranties, express or implied. -
Page 14: Disclaimers
Disclaimers Performance Data Data presented in Omron Company websites, catalogs and other materials is provided as a guide for the user in determining suitability and does not constitute a warranty. It may represent the result of Omron’s test conditions, and the user must correlate it to actual application requirements. Actual per- formance is subject to the Omron’s Warranty and Limitations of Liability. -
Page 15: Safety Precautions
Safety Precautions Safety Precautions Refer to the following manuals for safety precautions. • NY-series Industrial Box PC Hardware User’s Manual (Cat. No. W556) • NY-series Industrial Panel PC Hardware User’s Manual (Cat. No. W557) • NY-series Industrial Panel PC / Industrial Box PC Software User’s Manual (Cat. No. W558) NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (W568) -
Page 16: Precautions For Safe Use
Precautions for Safe Use Precautions for Safe Use Refer to the following manuals for precautions for safe use. • NY-series Industrial Box PC Hardware User’s Manual (Cat. No. W556) • NY-series Industrial Panel PC Hardware User’s Manual (Cat. No. W557) •... -
Page 17: Precautions For Correct Use
Precautions for Correct Use Precautions for Correct Use Refer to the following manuals for precautions for correct use. • NY-series Industrial Box PC Hardware User’s Manual (Cat. No. W556) • NY-series Industrial Panel PC Hardware User’s Manual (Cat. No. W557) •... -
Page 18: Regulations And Standards
Concepts EMC Directive OMRON devices that comply with EU Directives also conform to the related EMC standards so that they can be more easily built into other devices or the overall machine. The actual products have been checked for conformity to EMC standards.* Whether the products conform to the standards in the system used by the customer, however, must be checked by the customer. -
Page 19: Versions
Versions Versions Hardware revisions and unit versions are used to manage the hardware and software in NY-series Controllers and EtherCAT slaves. The hardware revision or unit version is updated each time there is a change in hardware or software specifications. Even when two Units or EtherCAT slaves have the same model number, they will have functional or performance differences if they have different hardware revisions or unit versions. - Page 20 Versions Outline View Detail View The information that is displayed is different for the Outline View and Detail View. The Detail View displays the unit version, hardware revision, and other versions. The Outline View dis- plays only the unit version. ...
-
Page 21: Related Manuals
Related Manuals Related Manuals The following are the manuals related to this manual. Use these manuals for reference. Manual name Cat. No. Model numbers Application Description NY-series W557 NY532-1£££ Learning the basic An introduction to the entire NY-series sys- IPC Machine Controller specifications of the tem is provided along with the following in- Industrial Panel PC... - Page 22 Related Manuals Manual name Cat. No. Model numbers Application Description NY-series W563 NY532-1£££ Using the built-in Ether- Information on the built-in EtherNet/IP port is IPC Machine Controller NY512-1£££ Net/IP port in an NY- provided. Industrial Panel PC / Industrial series Industrial PC. Information is provided on the basic setup, Box PC tag data links, and other features.
-
Page 23: Revision History
Revision History Revision History A manual revision code appears as a suffix to the catalog number on the front and back covers of the manual. Cat. No. W568-E1-01 Revision code Revision Date Revised content code September 2016 Original production NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (W568) - Page 24 Revision History NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (W568)
-
Page 25: Sections In This Manual
Sections in this Manual Sections in this Manual Introduction to Index Industrial PC Initial Settings Controller Preparation Industrial PC Support Utility NYCompolet Industrial PC API Backup and Recovery Troubleshooting during Setup Appendices NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (W568) - Page 26 Sections in this Manual NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (W568)
-
Page 27: Introduction To The Industrial Pc
Introduction to the Industrial PC This section describes the features, basic system, product models, and operating pro- cedure of an Industrial PC Platform NY-series IPC Machine Controller Industrial Panel PC / Industrial Box PC. 1-1 Features ......................1 - 2 1-2 Operation of the Operating System.............. -
Page 28: Features
1 Introduction to the Industrial PC Features Industrial PC Platform NY-series IPC Machine Controller Industrial Panel PC / Industrial Box PC (here- after Industrial PC) is an industrial PC of the next generation. It accomplishes both high speed and high precision Controller function that is necessary for machine control, and safety, reliability, and maintainability as an industrial PC. -
Page 29: Operation Of The Operating System
1 Introduction to the Industrial PC Operation of the Operating System This section describes how the operating systems of the Industrial PC operate and how the two oper- ating systems relate to. 1-2-1 Overview of Operating System Operation An Industrial PC has two operating systems: Windows and Real-Time OS. Separate processor cores are allocated to each OS. - Page 30 1 Introduction to the Industrial PC Windows Controller Internal network Internal network Backing up or Backing up or restoring data restoring data Shared folder User program (Virtual SD Memory Card) Shutting down and Shutting down and restarting restarting Real-Time OS Accessing the Controller from Windows You can get the Controller data with the support software or application that runs on Windows.
-
Page 31: External Interface For Each Operating System
1 Introduction to the Industrial PC 1-2-3 External Interface for Each Operating System External interfaces for Industrial PCs that are supported by Windows and Real-Time OS (Controller function) are given below. You cannot access an interface which is supported by the other Operating System. Ethernet port Ethernet port EtherNet/IP port... -
Page 32: Product Model Numbers
: 320GB HDD : 128GB SSD iMLC Interface option : RS-232C : DVI-D Logo mark : Omron : Custom : Without display (Industrial Box PC) 1 - 6 NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (W568) -
Page 33: Application Procedures
1 Introduction to the Industrial PC Application Procedures This section gives the operating procedure of the Industrial PCs. This manual gives the detailed de- scriptions in the same order as the following operating procedure. 1-4-1 Overall Procedure Preparations Perform procedures that are required to use the Industrial PC such as assembling, installation, and connection with peripheral devices including a UPS. - Page 34 1 Introduction to the Industrial PC Step Description Reference Creating applications with the Use the API prepared for the Industrial PC, and create Section 6 Industrial PC API on Industrial PC API an application that gets the system status information page 6 - 1 of the Industrial PC as well as the status information of the Controller.
-
Page 35: Monitoring Function
1 Introduction to the Industrial PC Monitoring Function This section describes the monitoring function of the Industrial PC. The function is used to monitor the system status and Controller status of the Industrial PC. The Industrial PC Support Utility is used to obtain and display the system information of the Industrial PC and the status information of the Controller function. -
Page 36: Monitoring Controller Status
1 Introduction to the Industrial PC 1-5-2 Monitoring Controller Status To display the Controller status, start up the Industrial PC Support Utility and click the Controller Sta- tus tab. Item Description Controller unit name Displays the unit name that is set for the Controller. Controller Operating Mode Displays the present operating mode of the Controller. - Page 37 Initial Settings This section describes the basic operation and initial settings of the Industrial PC. It also describes starting and exiting the Industrial PC, the initial settings for Windows af- ter turning ON the power for the first time, the UPS settings, and the Industrial Monitor settings.
-
Page 38: Initial Settings
2 Initial Settings Initial Settings for Windows This section describes the setting items and procedures for Windows when the Industrial PC is started up for the first time. A keyboard and mouse are required to make settings. Before turning on the power supply to the In- dustrial PC, connect a keyboard and mouse to the USB ports. -
Page 39: Creating Recovery Image Of Initial State
The Industrial PC does not have an internet browser pre-installed for security reasons. An executable file for browser installation is provided in D:\OMRON-NY\Installers. Execute an installer that corresponds to the type of your Windows (32 or 64 bit) and your language (Japanese or English). -
Page 40: User Account Settings
2 Initial Settings Installing Firewall Software Install the firewall software that you are permitted to use in your company. The Industrial PC network must be separated from the office network. Precautions for Safe Use • Separate the machine network segment from the office network to avoid communication fail- ures. -
Page 41: Starting And Exiting
2 Initial Settings Starting and Exiting This section gives the basic starting up and exiting operations of the Industrial PC, and the operation sequences. 2-2-1 Starting During starting up, the Monitor displays the startup status. The following description assumes that you are using an Industrial Panel PC, or an Industrial Box PC to which a Monitor is connected. -
Page 42: Exiting
2 Initial Settings 2-2-2 Exiting This section gives procedures to shut down Windows and Real-Time OS (Controller function), and turn OFF the power supply to the Industrial PC. Precautions for Safe Use Before turning OFF the power supply to the Industrial PC, you must ensure that there is no pro- gram running on Windows, and that it is safe to shut down the system while the current pro- gram is running. - Page 43 2 Initial Settings Restarting Windows To restart Windows, use the Restart OS instruction on the Controller. Refer to the NY-series Instruc- tions Reference Manual (Cat. No. W560) for details on using the Restart OS instruction. Restarting the Controller Use the Sysmac Studio or Industrial PC Support Utility to restart the Controller. ...
-
Page 44: Ups Settings
2 Initial Settings UPS Settings If necessary, set the UPS operating mode, Industrial PC’s exiting processing during a power interrup- tion, and I/O signal processing. Refer to the manual for the UPS you use for details on the UPS settings. 2 - 8 NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (W568) -
Page 45: Industrial Monitor Settings
Application Procedures As an example, the procedure to start up from the Start menu is given below. Select OMRON - Industrial Monitor - Industrial Monitor Utility from the Start menu. The Industrial Monitor Utility dialog box is displayed. 2 - 9... - Page 46 2 Initial Settings Refer to Industrial Monitor Utility Dialog Box on page 2 - 10 for details on the screens of the Industrial Monitor Utility as follows. Select an Industrial Panel PC or Industrial Monitor and make the necessary setting. Click the Apply button.
-
Page 47: Industrial Monitor Brightness Utility
Refer to A-5 Industrial PC Tray Utility on page A - 6 for details on the Industrial PC Tray Utility. Application Procedures As an example, the procedure to start up from the Start menu is given below. Select OMRON - Industrial Monitor - Industrial Monitor Brightness Utility from the Start menu. The Industrial Monitor Brightness Utility is displayed. - Page 48 2 Initial Settings Additional Information You can start the Industrial Monitor Utility by clicking the Industrial Monitor Utility but- ton. Refer to 2-4-1 Industrial Monitor Utility on page 2 - 9 for details. 2 - 12 NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (W568)
-
Page 49: Controller Preparation
Controller Preparation This section describes the settings and procedures for Windows and Controller that are required for using the Controller. 3-1 Internal Port Settings ..................3 - 2 3-2 Shared Folder Settings .................. 3 - 3 3-2-1 Windows Settings ....................3 - 3 3-2-2 Controller Setup .................... -
Page 50: Internal Port Settings
3 Controller Preparation Internal Port Settings This section describes the settings of the internal port through which the Controller communicates with Windows. Refer to 1-2-2 Data Exchange between Operating Systems on page 1 - 3. Windows Settings An internal port is set on Windows by default as a virtual network adapter port. The factory setting for the internal port is given below. -
Page 51: Shared Folder Settings
3 Controller Preparation Shared Folder Settings This section describes the settings required for the Controller to use the Windows shared folder as a Virtual SD Memory Card. Refer to the NY-series Industrial Panel PC / Industrial Box PC Software User’s Manual (Cat. No. W558) for details on the function of a Virtual SD Memory Card. - Page 52 3 Controller Preparation The Manage accounts view is displayed. Select Create a new account. The Create a new account view is displayed. Enter an account, select Administrator, and click the Create Account button. In the following example, enter MachineController as an account. 3 - 4 NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (W568)
- Page 53 3 Controller Preparation The new account is created. Click the account that you created on the Manage accounts view. Select Created a pass- word on the displayed Change account view. The Create a password view is displayed. 3 - 5 NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (W568)
- Page 54 The factory setting for the shared folder is given below. Item Value The path for the shared folder D:\OMRON-NY\VirtualSDCard 3 - 6 NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (W568)
-
Page 55: Controller Setup
3 Controller Preparation Item Value Shared folder name VirtualSDCard Shared with Everyone Permission level Read/Write Precautions for Correct Use When you enable file sharing on external networks, change the accounts that are given access to the shared folder from Everyone to properly authorized accounts in order to protect the shared folder against information leaks or data modification. - Page 56 3 Controller Preparation On the Virtual SD Memory Card Settings field of the Basic Settings view, select Use for Virtual SD Memory Card option, and enter required fields. Go online with the target Controller from the Sysmac Studio, and transfer the Controller setup to the Controller by using the Synchronization function.
-
Page 57: Industrial Pc Support Utility
Industrial PC Support Utility This section describes the functions and usage of the Industrial PC Support Utility. 4-1 Outline of Industrial PC Support Utility............4 - 2 4-2 Starting the Industrial PC Support Utility ............ 4 - 3 4-2-1 Starting the Industrial PC Support Utility............4 - 3 4-2-2 Screen of Industrial PC Support Utility............... -
Page 58: Outline Of Industrial Pc Support Utility
4 Industrial PC Support Utility Outline of Industrial PC Support Utili- An Industrial PC Support Utility displays the production information of the Industrial PC, and the sys- tem status as well as the Controller status, and it also backs up the Controller programs. It is pre-in- stalled on Windows of the Industrial PC. -
Page 59: Starting The Industrial Pc Support Utility
Procedure As an example, the procedure to start up from the Start menu is given below. Select OMRON - Industrial PC - Industrial PC Support Utility from the Start menu. The Network Connection dialog box is displayed. Enter the IP address of the internal port on the Controller, and click the Connect button. -
Page 60: Screen Of Industrial Pc Support Utility
4 Industrial PC Support Utility Refer to 3-1 Internal Port Settings on page 3 - 2 for details on the IP address of the internal port on the Controller. Additional Information If the operation authority verification is set for the Controller, from the Sysmac Studio, you must enter the operation authority level and password to start up. -
Page 61: Displaying Production Information
4 Industrial PC Support Utility Displaying Production Information The Industrial PC Support Utility displays the model number, lot number, hardware version, and soft- ware version of the Industrial PC. To display the information, click the Product Information tab. Item Displayed information Example Model Name The model number of the Industrial PC... -
Page 62: System Monitor
4 Industrial PC Support Utility System Monitor The Industrial PC Support Utility displays the internal temperature of the Industrial PC, fan revolution, and battery and UPS status. To display the information, click the System Status tab. Item Description Displayed information Internal Temperature Displays the present internal temperature of the Industrial PC. -
Page 63: Controller Monitor
4 Industrial PC Support Utility Controller Monitor The Industrial PC Support Utility displays the Controller status such as operating mode and current errors. To display the information, click the Controller Status tab. Item Description Displayed information Controller unit name Displays the unit name that is set for the Controller. Controller name Controller operation Mode Displays the present operating mode of the Controller. - Page 64 4 Industrial PC Support Utility Display in Industrial PC Tray Utility For the following items displayed on the Controller Status tab page, you can check the status by the icon in the Industrial PC Tray Utility. Item Status Icon Controller operation Mode RUN Mode Normal PROGRAM Mode...
-
Page 65: Controller Operation
4 Industrial PC Support Utility Controller Operation You can perform operations such as operating mode change, backup and restore for the Controller. To display the operation screen, click the Controller Operation tab. Item Description Displayed information Mode You can change the operating mode of the Controller. The present RUN Mode, or PROGRAM operating mode on the right. -
Page 66: Resetting The Controller
4 Industrial PC Support Utility To change PROGRAM mode to RUN mode, click the Run button. 4-6-2 Resetting the Controller When the Controller stops due to a major fault level Controller error, you can reset the Controller to restore from the error. Always confirm the safety of the system before you reset the Controller. -
Page 67: Controller Backup
4 Industrial PC Support Utility Additional Information When the Controller reset is executed, the Controller is restarted, and the connection between the Industrial PC Support Utility and the Controller is disconnected. 4-6-3 Controller Backup You can back up the data from the Controller to a file, and compare or restore the contents of the backup file. - Page 68 4 Industrial PC Support Utility If there is already a backup file in the selected folder, a dialog box is displayed to confirm over- writing the backup file. Click the Yes button to overwrite. If you do not want to overwrite, click the No button to select another folder.
- Page 69 4 Industrial PC Support Utility If there is no backup file in the selected folder, the following dialog box is displayed. Click the OK button to close the message box, and then select another folder. Select the check box for the target data to restore, and then click the Execute button. The following dialog box is displayed if the Controller is in RUN mode.
- Page 70 4 Industrial PC Support Utility Additional Information • If restoring the data results in changing the IP address of the EtherNet/IP port or internal port, communications may be disconnected. Confirm that the system will not be adversely affected even if the IP address is changed, before you restore the data. •...
- Page 71 4 Industrial PC Support Utility The comparison is started. When the comparison is completed, the comparison result is dis- played in the dialog box. 4 - 15 NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (W568)
-
Page 72: Network Settings For Controller
4 Industrial PC Support Utility Network Settings for Controller You can change the network settings for the Controller, such as EtherNet/IP port settings and internal port settings, that were set on the Sysmac Studio. This function is convenient to change the network settings alone without using the Sysmac Studio after you transferred programs or the network settings from the Sysmac Studio to the Controller. - Page 73 4 Industrial PC Support Utility 169.254.0.0 to 169.254.255.255 192.168.255.0 to 192.168.255.255 Due to Ethernet restrictions, you also cannot specify the IP addresses that are described below. An IP address that is all 0s or all 1s IP addresses that start with 127, 0, or 255 (decimal) Class-D IP addresses (224.0.0.0 to 239.255.255.255) Class-E IP addresses (240.0.0.0 to 255.255.255.255) Refer to the NY-series Industrial Panel PC / Industrial Box PC Built-in EtherNet/IP Port User’s Manual...
-
Page 74: Virtual Sd Memory Card Settings
4 Industrial PC Support Utility Virtual SD Memory Card Settings You can change the Virtual SD Memory Card settings for the Controller. The function is convenient to change the Virtual SD Memory Card settings alone without using the Sysmac Studio. You can make the change only when the Controller is in PROGRAM mode. - Page 75 4 Industrial PC Support Utility Procedure to Change Settings The procedure to change the settings is given below. Enter a set value to change to in each of the applicable entry boxes, and click the Update set- tings button. The Virtual SD Memory Card settings for the Controller are updated. 4 - 19 NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (W568)
-
Page 76: Operation Authority Verification
4 Industrial PC Support Utility Operation Authority Verification The operation authority verification is the function to restrict the operations of the Industrial PC Sup- port Utility according to the operation authority, and then to protect the user programs and data on the Controller. - Page 77 4 Industrial PC Support Utility When you click the Cancel button on the Verification dialog box, the Industrial PC Support Utility starts up with the operation authority set for the "Operation authority when a password entry is omitted" on the Sysmac Studio. Additional Information To change to another operation authority, click the Disconnect button to disconnect from the Controller once.
-
Page 78: 4-10 Report Log
If a problem occurs in the Controller, you can use the Report Log function to save information in a file to help solve the problem. Please provide the files that are saved to the OMRON support center when you request support. - Page 79 4 Industrial PC Support Utility The Save As dialog box is displayed. Select the folder in which to save the log files and click the Save button. The log files are saved, and the contents saved in the folder are displayed. Send the log files to the support center.
- Page 80 4 Industrial PC Support Utility 4 - 24 NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (W568)
-
Page 81: Nycompolet
NYCompolet This section describes the NYCompolet which is a software component used to create applications for operating the Controller. 5-1 Outline of NYCompolet .................. 5 - 2 5-2 How to Use the NYCompolet................. 5 - 3 5-3 Communications Setup ................. 5 - 4 5-3-1 Communications Setup Procedure .............. -
Page 82: Outline Of Nycompolet
5 NYCompolet Outline of NYCompolet The NYCompolet is a software component with which you can create applications to read variables from the Controller and write them to the Controller. With the NYCompolet, you can create an application to get data such as the OK product ratio that is collected by the Controller and another application to overwrite the recipe data, in the Controller, for the production line. -
Page 83: How To Use The Nycompolet
5 NYCompolet How to Use the NYCompolet This section gives the operating procedure of the NYCompolet. Preparation Install the Microsoft Visual Studio to Windows of the Industrial PC. Creating an Application On the Microsoft Visual Studio, create an application program in Visual Basic or Visual C#. Use a method or property of the NYCompolet in the program, when necessary for the purpose. -
Page 84: Communications Setup
NYCompolet, as well as additional functions. The SYSMAC Gateway Console is used to make the communications setup. To start the SYSMAC Gateway Console, select OMRON - SYSMAC Gateway - SYSMAC Gateway Console from the Windows start menu. - Page 85 5 NYCompolet Refer to the help for the SYSMAC Gateway Console for details on each function. To display the help, select OMRON - Industrial PC - SYSMAC Gateway Console - SYSMAC Gateway Console help from the Windows start menu. 5 - 5...
-
Page 86: Nycompolet Interface
Framework. The NYCompolet class members are given below. Refer to the NYCompolet help for details on each member. To display the help, select OMRON - Industrial PC - SYSMAC Gateway Console - NYCompolet help from the Windows start menu. Properties... -
Page 87: Usage Method
5 NYCompolet 5-4-2 Usage Method To use the NYCompolet members, you must declare the NYCompolet class in Visual Basic or Visual Refer to the manual or help for the Microsoft Visual Studio for the procedure to declare the class in Visual Basic or Visual C#. - Page 88 5 NYCompolet 5 - 8 NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (W568)
-
Page 89: Industrial Pc Api
Industrial PC API This section describes the API prepared for the Industrial PC. The API is used to cre- ate an application that gets the system status information of the Industrial PC as well as the status information of the Controller. 6-1 Outline of Industrial PC API ................ -
Page 90: Outline Of Industrial Pc Api
6 Industrial PC API Outline of Industrial PC API The Industrial PC API is an API used to create an application that gets the system status information of the Industrial PC and operates the Controller. The Industrial PC API is the collective term for the following two APIs. Type of API Description Reference... -
Page 91: How To Use The Industrial Pc Api
6 Industrial PC API How to Use the Industrial PC API This section gives the operating procedure of the Industrial PC API. Preparation Install the Microsoft Visual Studio to Windows of the Industrial PC. Creating an Application On the Microsoft Visual Studio, create an application program in Visual C#. Call a method or property of the Industrial PC API in the program, when necessary for the purpose. -
Page 92: Industrial Pc System Api
6 Industrial PC API Industrial PC System API This section describes the member types of the Industrial PC System API and how to use the mem- bers. 6-3-1 Members of the Industrial PC System API The members of the Industrial PC System API are given below. Refer to the help for the Industrial PC API for details on each member. -
Page 93: Industrial Pc Controller Api
6 Industrial PC API Industrial PC Controller API This section describes the types of members of the Industrial PC Controller API and how to use them. The Industrial PC Controller API is constructed with the following classes. • IPCController class •... -
Page 94: Controlleraccessexception Class
6 Industrial PC API Enumerations Name Meaning RunModeTypes Gives the type of the operating mode. ErrorStatusTypes Gives whether a Controller error occurs. UserDefineErrorStatusTypes Gives whether a user-defined error occurs. EthernetPortLedTypes Gives the type of status of the built-in EtherNet/IP network to get. EthernetPortLedStatus Gives the status of the built-in EtherNet/IP network. -
Page 95: Backup And Recovery
Backup and Recovery This section describes backup and recovery procedures for the Industrial PC system, and backup, restoration, and comparison procedures for the Controller. 7-1 Backing up and Recovering the Industrial PC System....... 7 - 2 7-1-1 Outline of Rescue Disk Utility................7 - 2 7-1-2 Applicable Range of Backup Functions with the Rescue Disk Utility.... -
Page 96: Backing Up And Recovering The Industrial Pc System
7 Backup and Recovery Backing up and Recovering the In- dustrial PC System This section describes how to back up and recover the Industrial PC system. You can use the Rescue Disk Utility for backing up and recovery. 7-1-1 Outline of Rescue Disk Utility The Rescue Disk Utility is a tool used to back up and recover data of Windows and Real-Time OS (Controller function) of the Industrial PC. -
Page 97: Backup With The Rescue Disk Utility
Disk Utility will be lost by installing the Rescue Disk Utility. Connect the USB storage device to the USB port on the Industrial PC. From the Windows start menu, select OMRON - Industrial PC, right-click Rescue Disk Crea- tor, and select Run as administrator. - Page 98 7 Backup and Recovery A name of a displayed USB storage device depends on the storage device. In this example, the screen displays the name as My Rescue Disk. Select the USB storage device in which the Rescue Disk Utility was installed and press the En- ter key.
-
Page 99: Recovery With The Rescue Disk Utility
7 Backup and Recovery The power supply to the Industrial PC is turned OFF. Remove the USB storage device with the backup data and keep it in a safe place. Additional Information You can save only one set of backup data to one USB storage device. If a USB storage device already has a backup file and you select the backup file and press the Enter key, a screen shows to confirm overwriting the backup file. - Page 100 7 Backup and Recovery Item Description Windows Partition Restores the data of the Windows system. Select the item to restore and press the Enter key. The screen shows a restoration confirmation message. Select Yes, and press the Enter key. The screen shows the restoration processing. When the restoration is completed, the screen shows Restoration finished.
-
Page 101: Backing Up, Restoring, And Comparing Controller Data
7 Backup and Recovery Backing Up, Restoring, and Compar- ing Controller Data You can use the Controller function to back up all of the data on the settings and user programs in the Controller to a Virtual SD Memory Card or a computer, and restore or compare the backed up data. Refer to the NY-series Industrial Panel PC / Industrial Box PC Software User’s Manual (Cat. - Page 102 7 Backup and Recovery 7 - 8 NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (W568)
-
Page 103: Troubleshooting During Setup
Troubleshooting during Setup This section describes the typical errors that may occur during setup and the proce- dure for troubleshooting. 8-1 Starting in Safe Mode..................8 - 2 8 - 1 NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (W568) -
Page 104: Starting In Safe Mode
8 Troubleshooting during Setup Starting in Safe Mode In Safe mode, the Controller is started up in PROGRAM mode. The mode is used when the Sysmac Studio or the Industrial PC Support Utility cannot connect to the Controller and the Controller operating mode cannot be changed. -
Page 105: Appendices
Appendices This section describes methods for updating the Industrial PC and for changing the in- ternal port settings, and other supplemental information for the body of this manual. A-1 Updating......................A - 2 A-1-1 Updating Windows Software................A - 2 A-2 Changing the Internal Port Settings ............ -
Page 106: A-1 Updating
• Firewall software • Internet browser • Windows security patches • OMRON software Precautions for Correct Use After an OS update or a peripheral device driver update for the Industrial PC is executed, the PC behavior might be different. Confirm that operation is correct before you start actual opera- tion. -
Page 107: A-2 Changing The Internal Port Settings
Appendices A-2 Changing the Internal Port Settings Communications between the Controller and Windows are enabled in the default setting for the inter- nal ports on the Controller and Windows. Normally, you do not have to change the internal port setting. However, you may need to change the initial IP address (192.168.254.***/24) in the following case. -
Page 108: Changing Windows File Sharing Setting
Appendices A-3 Changing Windows File Sharing Set- ting In the factory setting, Windows file sharing is enabled only between Windows and Controllers. To share files on external networks to the Industrial PC, change the setting of the network adapter to use. A-3-1 Procedure to Change In the properties dialog box of the external network to use, select the network adapter, and select the... -
Page 109: A-4 Windows Of Industrial Pc
Appendices A-4 Windows of Industrial PC The types of Windows Operating Systems for the Industrial PC and supported languages are given below. A-4-1 Windows Operating System The available Windows Operating Systems are: • Windows Embedded Standard 7 SP1 - 32 bit •... -
Page 110: A-5 Industrial Pc Tray Utility
Starting the Industrial PC Tray Utility The Industrial PC Tray Utility is configured to start automatically at Windows startup. To manually (re)start the Industrial PC Tray Utility, select OMRON - Omron Tray Application Frame- work from the Windows start menu. -
Page 111: A-5-5 Notification Message Display
Appendices Meaning Displays the available utilities. Click any of the utilities to start. Display the details on the Industrial PC Tray Utility. Closes the Industrial PC Tray Utility. A-5-5 Notification Message Display Click the icon that shows a warning or error to display a popup message. Correct the warning or error by following the instruction given in the message. -
Page 112: A-6 Customize Windows
Appendices A-6 Customize Windows This section provides an overview of the tools to customize Windows. A-6-1 Enhanced Write Filter Enhanced Write Filter (EWF) intercepts disk changes and stores them into a memory overlay in RAM memory instead of applying them to the original volume. Additional Information •... -
Page 113: A-6-2 File-Based Write Filter
Appendices Command Function Remarks ewfmgr /h Displays a helpscreen that explains all com- A complete reference can be found at the mands and options available. Microsoft Developer Network (MSDN). Considerations • EWF and FBWF cannot be used simultaneously. • To prevent data loss in the event of a power failure, the use of a UPS is recommended. •... - Page 114 Appendices Usage FBWF is included in the Windows Embedded Standard 7 image and disabled by default. The configu- ration of this component can be defined with the command line tool FBWFMGR.EXE. To run the FBWF Manager, open the Command Prompt with Administrator rights. Command Function Remarks...
- Page 115 Index I - 1 NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (W568)
