Ink Tank Cover (Inside) - Canon ipf8300 User Manual

Printer Parts > Printer parts
c. Printhead L
The printhead is equipped with ink nozzles. The carriage serves a key role in printing.
d. Printhead R
The printhead is equipped with ink nozzles. The carriage serves a key role in printing.
e. Printhead Fixer Lever
Locks the Printhead Fixer Cover.
f. Cutter Unit
A round-bladed cutter for automatic paper cutting. Retracted when not in use.
g. Shaft Cleaner
Prevents the Carriage Shaft from becoming dirty.
h. Cutter Unit Detachment Lever
Used when replacing the Cutter Unit.

Ink Tank Cover (Inside)

9
Note: The figure shows the printer as loaded with 700 ml (23.7 fl oz) Ink Tank.
a. Ink tanks
Cartridges of ink in various colors.
b. Ink Tank Lock Lever
886
A lever that locks the Ink Tank in place and protects it. Lift and lower the lever when replacing an Ink Tank. To open
it, lift the stopper of the lever until it stops, and then push it down toward the front. To close it, push it down until it
clicks into place.
