General Specifications - Rigol DS1102E Datasheet

General Specifications

Display
Display Type
Display Resolution
Display Color
Display Contrast (typical)
Backlight Brightness (typical)
Probe Compensator Output
Output Voltage (typical)
Frequency (typical)
Power Supply
Supply Voltage
Power Consumption
Fuse
Environmental
Ambient Temperature
Cooling Method
Humidity
Altitude
Mechanical
Dimensions
Weight
IP Protection
IP2X
Calibration Interval
The recommended calibration interval is one year
145mm (5.6 inch) diagonal TFT Liquid Crystal Display
320 horizontal ×RGB×234 vertical pixels
64k color
150:1
300 nit
Approximately 3Vpp (peak to peak value)
1kHz
100 ~ 240VAC , 45~440Hz, CAT II
RMS
Less than 50W
2A, T level, 250 V
Operating 10℃~ 40℃
Non-operating -20℃~ +60℃
fan cooling
below +35℃: ≤90% relative humidity
+35℃~ +40℃: ≤60% relative humidity
Operating at 3,000 m or below
Non-operating at 15,000 m or below
Width
Height
Depth
Without package
Packaged
303mm
154mm
133mm
2.3kg
3.5kg
5
