Operation
8.5.5 Advanced Valley Hold
This function works similar to the advanced peak hold function, except that it will search the signal
for a local minimum.
8.5.6 Advanced Peak Hold with Averaging
The output signal delivered by the advanced peak hold functions tends to jump up and down. This is
due to the fact, that only maximum points of the otherwise homogenous trace will be shown. The user
may combine the functionality of the peak hold function with the averaging function by choosing an
average time, thus, smoothing the output signal for convenient tracing.
Temp
The advanced peak hold function with averaging is only adjustable by means of the DataTemp
Multidrop Software.
8.5.7 Advanced Valley Hold with Averaging
This function works similar to the advanced peak hold function with averaging, except it will search
the signal for a local minimum.
56
Figure 39: Advanced Peak Hold with Averaging
Rev. G Nov/2015
output temperature
without averaging
object temperature
Time
