7.2 Emissivity (digital)
Function:
Signal:
Terminal:
The box electronics contains a table with 8 pre-installed settings for emissivity. To activate these
emissivity settings, you need to have the inputs FTC1, FTC2, and FTC3 connected. According to the
voltage level on the FTC inputs, one of the table entries will be activated.
0 = Low signal (0 V)
1 = High signal (from 5 V to V
A non-wired input is considered as not defined!
Table entry Emissivity
(Examples)
0 1.100
1 0.500
2 0.600
3 0.700
4 0.800
5 0.970
6 1.000
7 0.950
Figure 26: Digital Selection of Emissivity with FTC Inputs
The values in the table cannot be changed through the control panel.
7.3 Ambient Temperature Compensation
Function:
Signal:
Terminal:
44
+ 5 VDC
R1 = 200 Ω
4.0 V (ε=0.9)
R2 = 500 Ω
1.5 V (ε=0.4)
R3 = 300 Ω
emissivity (digital control)
digital low/high
FTC1-3, GND
)
DC
FTC3 FTC2 FTC1
0 0 0
0 0 1
0 1 0
0 1 1
1 0 0
1 0 1
1 1 0
1 1 1
Ambient Temperature Compensation
0 to 5 V
DC
FTC2, GND
Rev. G Nov/2015
"product 1"
To the FTC input
of the box
"product 2"
MI3
