Ethernet
Pressing on the <Start> button triggers the data storage in accordance to the defined time interval,
given in seconds. The internal memory of the box is 64 MB in size allowing a permanent data storage
over 24 days at a saving interval of 1 s independent from the number of connected heads.
Pressing on the <Start> button again will initiate a new recording session by overwriting
the previously stored data.
Clicking on the <Get data> button opens a dialog box to download the previously stored data as *.dat
file. The data logging file comes in a standard ASCII text format accessible e.g. by means of the
Windows Notepad.
for the measured object temperature and the internal temperature for sensing head 1
The data logging function is password protectable to ensure data consistency while having multiple
clients connected to the MI3 http server.
A valid password accepts digits only! The factory presetting is 1234.
108
Figure 88: Example for a logging file with recorded data
