Symbol/Message
AVG
Average
PH
Peak Hold
VH
Valley Hold
HOLD
Trigger set to HOLD function
APH
Advanced Peak Hold
APHA
Advanced Peak Hold with Averaging
AVH
Advanced Valley Hold
AVHA
Advanced Valley Hold with Averaging
<Power Fault> & alarm
Power via USB not sufficient to drive all analog outputs of
indicator are blinking
Communication box (DIN, 6TE), analog
Pushing the keys of the control panel will cause the following actions:
enters the menu or save parameters
enters the next page
No action for 10 s forces the unit to leave the menu without saving of parameters.
MI3
Meaning
Table 4: Symbols and Messages in the Display
Rev. G Nov/2015
Operation
Remark
Software controlled
Software controlled
Software controlled
Software controlled
Configuration of the box is possible
but outputs are set to disabled
