Profinet
17.2 Programming
17.2.1 I/O Device Configuration
The fieldbus communicator takes over the task of the I/O device in Profinet IO. Selecting the
Pyrometer modules for the process data exchange and defining the time grid is done when
configuring the I/O controller. The configuration and parameter setting of the fieldbus communicator
and Pyrometer modules is based on the device's GSD file.
17.2.1.1 GSD File
Under Profinet IO, the features of the devices are described by the manufacturer in form of a GSD file
and made available to the user. The GSD file for the MI3 IO device:
GSDML-V2.25-Raytek-MI3-xxxxxxxx
17.2.1.2 Configuration
The I/O device is configured in accordance with the physical arrangement of the node (slot oriented).
Slot 0 contains the fieldbus communicator in its function as station substitute. It does not deliver
process data itself (except its own internal temperature and trigger input state), but provides the
parameters required to perform overall setting of the I/O device.
The slot 1 to maximum 8 reflects the physical arrangement of the pyrometer modules that deliver a
part of the process and diagnostics data. All specific information on the relevant module is contained
in the associated GSD file.
As part of a configuration with multiple pyrometer modules it is to make sure to modify the default
module standard name <MI3 pyrometer> uniquely. Furthermore, it must be ensured to modify the
parameter <Pyrometer number> (default value 1) uniquely as well (see section 17.2.2.2 Parameters of
the Pyrometer Module, page 113).
17.2.2 Parameter Setting
Setting the parameters of both the fieldbus communicator and the connected pyrometer module is
performed via "record data" sets. All modules allow the diagnostics message to be locked or released.
Once all settings have been made, the I/O device signals that it is ready to send cyclic productive data.
