Box Info> Page - RayTek MI3 Operating Instructions Manual

<Temperature Unit> the temperature unit can be set to °C or °F. Note that this setting influences the
<Key Enter Lock>
<Display Backlight> defines the switching behavior for the display:
8.4 <Box Info> Page
<Serial No.>:
<Rev>:
Tbox:
8.5 Post Processing
8.5.1 Averaging
Averaging is used to smooth the output signal. The signal is smoothed depending on the defined time
basis. The output signal tracks the detector signal with significant time delay but noise and short
peaks are damped. Use a longer average time for more accurate damping behavior. The average time
is the amount of time the output signal needs to reach 90% magnitude of an object temperature jump.
Temp
A low level input (GND) at external input FTC3 will promptly interrupt the averaging and will start
the calculation again.
MI3
digital interfaces like RS485 for both object and head ambient temperature.
the box has a user interface lockout feature that keeps the box from being
accidentally changed from the control panel (locked by default under
DataTemp Multidrop Software and Profinet communications). This lockout
mode denies access to the
parameters. The unit can be unlocked by pressing the
button simultaneously for 3 seconds or alternatively by pressing the
for 5 seconds.
<ON>: switches the backlight on
<OFF>: switches the backlight off
<60sec.OFF>: switches the backlight off after the giving time
To preserve the display's longevity, the backlight should be turned off in case of
not using it!
serial number of the box.
firmware revision
current box ambient temperature
Figure 35: Averaging
Rev. G Nov/2015
button to avoid the saving of adjustable
output temperature
object temperature
temperature jump
average time
Operation
button and the
button
90% of temperature
jump
Time
