Specifications
VLT® Automation VT Drive FC 322 D-Frame Instruction Manual
3) Measured using 5 m screened motor cables at rated load and rated frequency.
4) The typical power loss is at nominal load conditions and expected to be within ±15% (tolerance relates to
variety in voltage and cable conditions).
5) Field wiring terminals on FC 322 N132, N160 and N315 models are not intended to receive conductors one size
larger.
Values are based on a typical motor efficiency (eff2/eff3 border line). Motors with lower efficiency will add to the
power loss in the frequency converter and those with higher efficiency will decrease it.
The losses are based on the default switching frequency. The losses increase significantly at higher switching
frequencies. LCP and typical control card power consumptions are included. Further options and customer load
may add up to 30 W to the losses. (Though typically, only 4 W extra for a fully loaded control card, or options for
slot A or slot B, each).

10.2 General Technical Data

Mains supply (L1, L2, L3)
Supply voltage
Mains voltage low / mains voltage drop-out:
During low mains voltage or a mains drop-out, the FC continues until the intermediate circuit voltage drops below the minimum
stop level, which corresponds typically to 15% below the FC's lowest rated supply voltage. Power-up and full torque cannot be
expected at mains voltage lower than 10% below the FC's lowest rated supply voltage.
Supply frequency
Max. imbalance temporary between mains phases
True Power Factor (λ)
Displacement Power Factor (cos Φ) near unity
Switching on input supply L1, L2, L3 (power ups)
0
10
Environment according to EN60664-1
The unit is suitable for use on a circuit capable of delivering not more than 100,000 RMS symmetrical Amperes, 480/600 V
Motor Output (U, V, W)
Output voltage
Output frequency
Switching on output
Ramp times
* Dependent on voltage and power
Torque Characteristics
Starting torque (Constant torque)
Starting torque
Overload torque (Constant torque)
Percentage relates to the frequency converter's nominal torque
Cable lengths and cross sections
Max. motor cable length, screened/armoured
Max. motor cable length, unscreened/unarmoured
Max. cross section to motor, mains, load sharing and brake *
Maximum cross section to control terminals, rigid wire
Maximum cross section to control terminals, flexible cable
Maximum cross section to control terminals, cable with enclosed core
Minimum cross section to control terminals
10-2
MG21E122 - VLT® is a registered Danfoss trademark
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20776-Danfoss-131X8139-VLT-Automation-VT-Drive-VFD-FC322-230V-20-HP.aspx
380-480V ± 10%
50/60Hz ± 5%
3.0% of rated supply voltage
≥ 0.9 nominal at rated load
(> 0.98)
maximum one time/2 minutes
overvoltage category III / pollution degree 2
0 - 100% of supply voltage
0 - 800 Hz*
Unlimited
0.01 - 3600 sec.
maximum 110% for 60 secs. *
maximum 135% up to 0.5 sec.*
maximum 110% for 60 secs.*
150 m
300 m
2
2
1.5 mm
/16 AWG (2 x 0.75 mm
)
1 mm
2
/18 AWG
0.5 mm
2
/20 AWG
2
0.25 mm
