Specifications VLT® Automation VT Drive FC 322 D-Frame Instruction Manual
Analog output
Number of programmable analog outputs
Terminal number
Current range at analog output
Max. resistor load to common at analog output
Accuracy on analog output
Resolution on analog output
The analog output is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
Control card, RS-485 serial communication
Terminal number
Terminal number 61
The RS-485 serial communication circuit is functionally seated from other central circuits and galvanically isolated from the
supply voltage (PELV).
Digital output
Programmable digital/pulse outputs
Terminal number
Voltage level at digital/frequency output
Max. output current (sink or source)
Max. load at frequency output
Max. capacitive load at frequency output
Minimum output frequency at frequency output
Maximum output frequency at frequency output
Accuracy of frequency output
Resolution of frequency outputs
1) Terminal 27 and 29 can also be programmed as input.
The digital output is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
0 10
Control card, 24 V DC output
Terminal number
Max. load
The 24 V DC supply is galvanically isolated from the supply voltage (PELV), but has the same potential as the analog and digital
inputs and outputs.
Relay outputs
Programmable relay outputs
Relay 01 Terminal number
1)
Max. terminal load (AC-1) on 1-2 (NO) (Resistive load)
on 1-2 (NO) (Inductive load @ cosφ 0.4)
1)
Max. terminal load (AC-15)
1)
Max. terminal load (DC-1) on 1-2 (NO) (Resistive load)
1)
Max. terminal load (DC-13) on 1-2 (NO) (Inductive load)
1)
Max. terminal load (AC-1) on 1-3 (NC) (Resistive load)
on 1-3 (NC) (Inductive load @ cosφ 0.4)
1)
Max. terminal load (AC-15)
1)
Max. terminal load (DC-1) on 1-3 (NC) (Resistive load)
1)
Max. terminal load (DC-13) on 1-3 (NC) (Inductive load)
Min. terminal load on 1-3 (NC), 1-2 (NO)
Environment according to EN 60664-1
Relay 02 Terminal number
1)
Max. terminal load (AC-1) on 4-5 (NO) (Resistive load)
on 4-5 (NO) (Inductive load @ cosφ 0.4)
1)
Max. terminal load (AC-15)
1)
Max. terminal load (DC-1) on 4-5 (NO) (Resistive load)
Max. terminal load (DC-13) 1) on 4-5 (NO) (Inductive load)
Max. terminal load (AC-1) 1) on 4-6 (NC) (Resistive load)
10-4 MG21E122 - VLT® is a registered Danfoss trademark
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20776-Danfoss-131X8139-VLT-Automation-VT-Drive-VFD-FC322-230V-20-HP.aspx
0/4 - 20 mA
Max. error: 0.8 % of full scale
68 (P,TX+, RX+), 69 (N,TX-, RX-)
Common for terminals 68 and 69
Max. error: 0.1 % of full scale
1-3 (break), 1-2 (make)
2)3)
400V AC, 2A
240V AC, 0.2A
80V DC, 2A
24V DC, 0.1A
240V AC, 2A
240V AC, 0.2A
50V DC, 2A
24V DC, 0.1A
24V DC 10mA, 24V AC 2 mA
overvoltage category III/pollution degree 2
4-6 (break), 4-5 (make)
2)3)
400V AC, 2A
240V AC, 0.2A
80V DC, 2A
24V DC, 0.1A
240V AC, 2A
1
42
500 Ω
8 bit
2
1)
27, 29
0 - 24 V
40 mA
1 kΩ
10 nF
0 Hz
32 kHz
12 bit
12, 13
200mA
2
