Warnings and Alarms VLT® Automation VT Drive FC 322 D-Frame Instruction Manual
No. Description Warning
33 Inrush fault
34 Fieldbus communication fault
35 Out of frequency range
36 Mains failure
37 Phase imbalance
39 Heatsink sensor
40 Overload of digital output terminal 27
41 Overload of digital output terminal 29
42 Overload of digital output on X30/6 or overload
of digital output on X30/7
46 Power card supply
47 24V supply low
48 1.8V supply low
49 Speed limit
50 AMA calibration failed
51 AMA check U and I
nom nom
52 AMA low I
nom
53 AMA motor too big
54 AMA motor too small
55 AMA parameter out of range
56 AMA interrupted by user
57 AMA timeout
58 AMA internal fault
59 Current limit
60 External interlock
62 Output frequency at maximum limit
64 Voltage limit
65 Control board over-temperature
66 Heatsink temperature low
67 Option configuration has changed
68 Safe stop activated
69 Power card temperature
70 Illegal FC configuration
71 PTC 1 safe stop
72 Dangerous failure
73 Safe Stop auto restart
76 Power unit setup
79 Illegal PS config
80 Drive Initialised to Default Value
91 Analog input 54 wrong settings
92 No flow
93 Dry pump
94 End of curve
95 Broken belt
96 Start delayed
97 Stop delayed
98 Clock fault
104 Mixing Fan fault
220 Overload trip
243 Brake IGBT
