Programming VLT® Automation VT Drive FC 322 D-Frame Instruction Manual
Parameter International North American
Default Parameter Default Parameter
Value
4-13 Motor Speed 1500 RPM 1800 RPM
High Limit [RPM]
See Note 3
4-14 Motor Speed 50 Hz 60 Hz
High Limit [Hz]
See Note 4
4-19 Max Output 100 Hz 120 Hz
Frequency
4-53 Warning Speed 1500 RPM 1800 RPM
High
5 5
5-12 Terminal 27 Coast inverse External interlock
Digital Input
5-40 Function Relay Alarm No alarm
6-15 Terminal 53 50 60
High Ref./Feedb.
Value
6-50 Terminal 42 Speed 0 - HighLim Speed 4-20 mA
Output
14-20 Reset Mode Manual reset Infinite auto reset
22-85 Speed at 1500 RPM 1800 RPM
Design Point [RPM]
See Note 3
22-86 Speed at 50 Hz 60 Hz
Design Point [Hz]
24-04 Fire Mode 50 Hz 60 Hz
Max Reference
Table 5.1 International/North American Default Parameter Settings

5.5 Parameter Menu Structure

Establishing the correct programming for applications
often requires setting functions in several related
parameters. These parameter settings provide the
frequency converter with system details it needs to
operate properly. System details may include such things
as input and output signal types, programming terminals,
minimum and maximum signal ranges, custom displays,
automatic restart, and other features.
•
See the LCP display to view detailed parameter
programming and setting options
•
Press [Info] in any menu location to view
additional details for that function
•
Press and hold [Main Menu] to enter a parameter
number for direct access to that parameter
•
Details for common application set ups are
provided in 6 Application Examples
5-4 MG21E122 - VLT® is a registered Danfoss trademark
