2. On the Sensor page, enter values for the parameters indicated in
Note
Web Page Item
Door Sensor Settings
Door Sensor Normally Closed
Door Open Timeout (in seconds)
Flash Button LED
Activate Relay
Play Audio Locally
Make call to extension
Dial Out Extension
Dial Out ID
Play recorded audio
Repeat Sensor Message
Sensor Strobe Settings
Blink Strobe on Sensor
Scene
ADA Compliant
Slow Fade
Fast Fade
Slow Blink
Fast Blink
Operations Guide
The question mark icon (
after the Toggle Help button is pressed
Table 2-19. Sensor Configuration Parameters
Description
Select the inactive state of the door sensor. The door sensor is also known as
the Sense Input on the device's terminal block.
The time (in seconds) the device will wait before it performs an action when the
on-board door sensor is activated. The action(s) performed are based on the
configured Door Sensor Settings below. Enter up to 5 digits.
When selected, the Call button LED will flash until the on-board door sensor is
deactivated (roughly 10 times/second).
When selected, the device's on-board relay will be activated until the on-board
door sensor is deactivated.
When selected, the device will loop an audio file out of the speaker until the door
sensor is deactivated.
When selected, the device will call an extension when the on-board door sensor
is activated. Use the Dial Out Extension field below to specify the extension the
device will call.
Specify the extension the device will call when the on-board door sensor is
activated. Enter up to 64 alphanumeric characters.
An additional Caller identification string added to outbound calls. Enter up to 64
alphanumeric characters.
When selected, the device will call the Dial Out Extension and play an audio file
to the phone answering the SIP call (corresponds to Door Ajar on the
Audiofiles page).
The number of times to repeat the audio message through the local speaker or
to the remote endpoint. A value of 0 will repeat forever. Enter a value from 0-
65536.
The following strobe settings will only appear if a CyberData Strobe
product is connected to your device. If a CyberData Strobe product is not
connected to your device, you will not see the strobe settings.
When selected, the Strobe will blink a scene when the sensor is triggered.
Select desired scene (only one may be chosen).
Strobe will blink ON at the specified brightness for 150ms then OFF for 350ms
during the duration of the event.
Strobe will increase in brightness from 0 to the specified brightness and back to
0 over the course of about 3.5 seconds during the duration of the event.
Strobe will increase in brightness from 0 to the specified brightness and back to
0 over the course of about 1.5 seconds during the duration of the event.
Strobe will blink ON at the specified brightness for one second then OFF for one
second during the duration of the event.
Strobe will blink ON at the specified brightness then OFF five times per second
during the duration of the event.
930809U
Installing the SIP Outdoor Intercom with Keypad
Configure the Sensor Configuration Parameters
) in the following table shows which web page items will be defined
.
Table 2-19.
