Web Page Item
Misc Settings
Device Name
Auto-Answer Incoming Calls
Button Lit When Idle
Button Brightness (0-255)
Play Ringback Tone
Enable Push to Talk
Enable DTMF Push to Talk
Prevent Call Termination
Disable HTTPS (NOT recommended)
Operations Guide
Table 2-8. Device Configuration Parameters (continued)
Description
Type the device name. Enter up to 25 characters.
When selected, the device will automatically answer incoming calls.
When Auto-Answer Incoming Calls is disabled, the device will play a
ring tone (corresponds to Ring Tone on the Audiofiles page) out of
the speaker until someone presses the Call button to answer the call
or the caller disconnects before the call can be answered.
When selected, the Call button LED is illuminated while the device is
idle (a call is not in progress).
The desired Call button LED brightness level. Acceptable values are
0-255, where 0 is the dimmest and 255 is the brightest. Enter up to
three digits.
When selected, the device will play a ringback tone (corresponds to
Ringback Tone on the Audiofiles page) out of the speaker while
placing an outbound call. The Ringback Tone will play until the call is
answered.
This option is for noisy environments. When enabled, the
microphone will be muted normally. When the Call button is pressed
and held, it will unmute the microphone and allow the operator to
send audio back. Using Push to Talk prevents the operator from
terminating a call by pressing the Call button. The call must be
terminated by the phone user.
This option is for noisy environments. When enabled, in an active
call, the remote phone can force receive only audio (setting the mic
gain to max and muting the speaker) by pressing the * key.
Pressing the # key will force send only audio (setting the max
speaker volume and muting the mic). Pressing the 0 key will restore
full duplex operation with the normal microphone and speaker
volume.
When this option is enabled, a call cannot be terminated using the
call button.
Disables the encrypted connection to the webpage. We do not
recommend disabling HTTPS for security reasons.
Click on the Test Audio button to do an audio test. When the Test
Audio button is pressed, you will hear a voice message for testing
the device audio quality and volume.
Click on the Test Microphone button to do a microphone test. When
the Test Microphone button is pressed, the following occurs:
1. The device will immediately start recording 3 seconds of audio.
2. The device will beep (indicating the end of recording).
3. The device will play back the recorded audio.
Click on the Test Relay button to do a relay test.
930809U
Installing the SIP Outdoor Intercom with Keypad
Configure the Device
