CyberData 011214 Operation Manual page 43

Web Page Item
Periodically sync time with server
Time update period (in hours)
Current Time
Relay Settings
Activate Relay with DTMF Code
Relay Pulse Code
Relay Pulse Duration (in seconds)
Relay Activation Code
Relay Deactivation Code
Play tone during DTMF Activation
Activate Relay During Ring
Activate Relay During Night Ring
Activate Relay While Call Active
Activate Relay on Button Press
Relay on Button Press Duration
Operations Guide
Table 2-8. Device Configuration Parameters (continued)
Description
When selected, the time is periodically updated with the NTP server
at the configured interval below.
The time interval after which the device will contact the NTP server to
update the time. Enter up to 4 digits.
Allows you to input the current time. (6 character limit)
Activates the relay when the DTMF Activation Code is entered on the
phone during a SIP call with the device. RFC2833 DTMF payload
types are supported.
DTMF code used to pulse the relay when entered on a phone during
a SIP call with the device. Relay will activate for Relay Pulse Duration
seconds then deactivate. Activate Relay with DTMF Code must be
enabled. Enter up to 25 digits (* and # are supported).
The length of time (in seconds) during which the relay will be
activated when the DTMF Relay Activation Code is detected. Enter
up to 5 digits.
Activation code used to activate the relay when entered on a phone
during a SIP call with the device. Relay will be active indefinitely, or
until the DTMF Relay Deactivation code is entered. Activate Relay
with DTMF Code must be enabled. Enter up to 25 digits (* and # are
supported).
Code used to deactivate the relay when entered on a phone during a
SIP call with the device. Activate Relay with DTMF Code must be
enabled. Enter up to 25 digits (* and # are supported).
When selected, the device will play a tone out of the speaker upon
DTMF relay activation. The tone plays for the DTMF Activation
Duration (in seconds).
When selected, the relay will be activated for as long as the device is
ringing. When Auto-Answer Incoming Calls is enabled, the device will
not ring and this option does nothing.
When selected, the relay will be activated as long as the Nightringer
extension is ringing.
When selected, the relay will be activated as long as the SIP call is
active.
When selected, the relay will be activated when the Call button is
pressed.
The length of time (in seconds) during which the relay will be
activated when the Call button is pressed. Enter up to 5 digits. A
Relay on Button Press Duration value of 0 will pulse the relay once
when the Call button is pressed.
930809U
Installing the SIP Outdoor Intercom with Keypad
Configure the Device
CyberData Corporation
35
