CyberData 011214 Operation Manual page 51

Web Page Item
Speed Dial Timeout
Keypad 1
Keypad 2
Keypad 3
Keypad 4
Keypad 5
Keypad 6
Keypad 7
Keypad 8
Keypad 9
Keypad 0
Keypad *
Keypad #
Call Button
Send Multicast Audio
Multicast Address
Multicast Port
Repeat Message
Button Tones
Play Button Tones
Note
Operations Guide
Table 2-13. Button Configuration Parameters (continued)
Description
The amount of time you must hold the button before it calls the configured extension.
When this is set to 0 the phone will dial the configured extension as soon as the button is
released.
Dial this extension when the 1 key is pressed.
Dial this extension when the 2 key is pressed.
Dial this extension when the 3 key is pressed.
Dial this extension when the 4 key is pressed.
Dial this extension when the 5 key is pressed.
Dial this extension when the 6 key is pressed.
Dial this extension when the 7 key is pressed.
Dial this extension when the 8 key is pressed.
Dial this extension when the 9 key is pressed.
Dial this extension when the 0 key is pressed.
Dial this extension when the * key is pressed.
Dial this extension when the # key is pressed.
Dial this extension when the call button is pressed.
When selected, the device will play an audio file to the specified multicast address and
port.
Note: The keypad must be in Security mode to send Multicast Audio.
The multicast address used for multicasting an audio file.
The multicast port used for multicasting an audio file.
The number of times to repeat the audio message to the remote endpoint. Enter a value
from 1-65536.
Play a tone when the keypad buttons are pressed.
Click the Save button to save your configuration settings.
Note: You need to reboot for changes to take effect.
Click on the Reboot button to reboot the system.
Click on the Start button to start a button test.
Click on the Toggle Help button to see a short description of some of the web page
items. First click on the Toggle Help button, and you will see a question mark (
next to some of the web page items. Move the mouse pointer to hover over a question
mark to see a short description of a specific web page item.
You must click on the Save button for the changes to take effect.
930809U
Installing the SIP Outdoor Intercom with Keypad
Configure the Button Parameters
CyberData Corporation
43
) appear
