Power Draw

GPRS
7 volts
9 volts
20 volts
32 volts
HSPA
7 volts
9 volts
20 volts
32 volts
Note: Multi-Tech Systems, Inc. recommends that you incorporate a 10% buffer into the power source when
determining product load.

RF Specifications

Frequency RX
Frequency TX
®
MultiConnect rCell 100 Series Router User Guide
Typical Maximum
0.305A, 2.14W 0.495A, 3.47W
0.230A, 2.12W 0.332, 3.05W
0.111A, 2.22W 0.164A, 3.28W
0.075A, 2.40W 0.112A, 3.58W
Typical Maximum
0.417A, 2.92W 0.625A, 4.38W
0.272A, 2.52W 0.455, 4.18W
0.140A, 2.80W 0.216A, 4.32W
0.090A, 2.88W 0.155A, 4.96W
GSM 850 EGSM
869 to 894 MHz 900 925 to 960 MHz
824 to 849 MHz 880 to 915 MHz
Peak TX Peak Rst (Inrush
Current)
1.74A 2.30A
1.28A 4.12A
.520A 3.03A
0.337A 2.50A
Peak TX Peak Rst (Inrush
Current)
0.792A 2.30A
0.588A 4.12A
.320A 3.03A
0.250A 2.50A
GSM 1800 GSM 1900
1805 to 1800 MHz 1930 to 1990 MHz
1710 to 1785 MHz 1850 to 1910 MHz
PRODUCT OVERVIEW
