10.13 WebVisu

The visualization of your programmed application is displayed on the html page
"WebVisu", provided you have created it with the visualization editor in
WAGO-I/O-PRO and loaded it into the controller.
Perform the following settings in WAGO-I/O-PRO, so that an html page with
your visualization is automatically created at the transmission of your project:
1. Double click to open the Target System Settings in the Resource register.
2. Open the Visualization register.
3. Select the Web Visualization option with a hatch mark.
4. Confirm with OK.
A link is then created to this html page "WebVisu" by the Web-based
Management system. You can set the html page "WebVisu" as the starting page.
1. Call up the page "PLC" in the web-based Management-System.
2. a.) To set the HTML page "WebVisu" as the start page, use the function
Pos: 84.64 /Serie 750 (WAGO-I/O-SYSTEM)/Web-based Management-System/Seite WebVisu/WebVisu - Hinweis: WebVisu als Startseite deaktivieren! @ 4\mod_1242646529875_21.doc @ 33498 @ @ 1
Returning to the "WebVisu.htm" page is only possible via the IP address of
the fieldbus controller!
The "Webvisu.htm" page does not have any hyperlinks to other Web sites. To
deactivate the starting page function again, or to go to other pages using
hyperlinks, enter the IP address for your controller and the address for the original
starting page in the URL line of your browser with the following syntax:
http://IP address of your controller/webserv/Index.ssi.
Pos: 84.65 /Serie 750 (WAGO-I/O-SYSTEM)/Web-based Management-System/Seite WebVisu/WebVisu - Einleitung 2 (750-841) @ 6\mod_1260282535531_21.doc @ 46857 @ @ 1
b.) To call up the the HTML page "WebVisu" in an eternal window
c) To call up the HTML page "WebVisu" on the WBM site directly, use
750-880, 750-880/025-000 ETHERNET Programmable Fieldbus Controller
WebVisu – Set 'webvisu.htm' as default. When accessing the web-
based management system, the "WebVisu" page is opened instead of
the default WBM start page "Information". However, the links to switch
to the other WBM pages is then no longer available.
(default setting), use the function WebVisu – Open 'webvisu.htm' in
new window. Clicking on the "WebVisu" link opens a new window
that displays the HTML page with visualization of your configured
application. The links to switch to the other WBM pages are still
available with this setting.
the function WebVisu – Open 'webvisu.htm' in frame. Clicking on
the "WebVisu" link opens the HTML page with visualization of your
