Table of Contents

Advertisement

Quick Links

Download this manual
Manual
WAGO I/O SYSTEM 750 XTR
750-8202/040-001
PFC200 2ETH RS TELE XTR
Controller PFC200; 2 × ETHERNET; RS-232/-485;
Telecontrol technology; Extreme
Version 1.2.0, valid from FW Version 03.01.07(13)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 750-8202/040-001 and is the answer not in the manual?

Questions and answers

Related Manuals for WAGO 750-8202/040-001

Summary of Contents for WAGO 750-8202/040-001

  • Page 1 Manual WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Controller PFC200; 2 × ETHERNET; RS-232/-485; Telecontrol technology; Extreme Version 1.2.0, valid from FW Version 03.01.07(13)
  • Page 2 We wish to point out that the software and hardware terms as well as the trademarks of companies used and/or mentioned in the present manual are generally protected by trademark or patent. WAGO is a registered trademark of WAGO Verwaltungsgesellschaft mbH. Manual Version 1.2.0, valid from FW Version 03.01.07(13)

  • Page 3: Table Of Contents

    WAGO I/O SYSTEM 750 XTR Table of Contents 750-8202/040-001 PFC200 2ETH RS TELE XTR Table of Contents Notes about this Documentation ............14 Validity of this Documentation ..............14 Copyright....................14 Symbols ....................15 Number Notation ..................16 Font Conventions ................... 16 Important Notes ..................
  • Page 4 Table of Contents WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 3.8.3 Supply ....................48 3.8.4 Clock ....................49 3.8.5 Programming ..................49 3.8.6 Local Bus ..................49 3.8.7 ETHERNET ..................50 3.8.8 Communication Interface ..............50 3.8.9...
  • Page 5 Changing an IP Address Using the “CBM” Configuration Tool and a Terminal Program..............106 7.3.3 Changing an IP Address using “WAGO Ethernet Settings” .... 109 7.3.4 Temporarily Setting a Fixed IP Address .......... 111 Testing the Network Connection ............112 Changing Passwords ................
  • Page 6 Table of Contents WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.5 “PLC WebVisu” Page ..............125 7.8.1.5.1 “Web Server Configuration” Group ........125 7.8.1.6 “Configuration of Host and Domain Name” Page ....... 126 7.8.1.6.1 “HostName” Group ..............126 7.8.1.6.2...
  • Page 7 WAGO I/O SYSTEM 750 XTR Table of Contents 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.19 “Firmware Backup” Page ............151 7.8.1.20 “Firmware Restore” Page ............153 7.8.1.21 “System Partition” Page .............. 155 7.8.1.21.1 “Current Active Partition” Group ..........155 7.8.1.21.2 “Set Inactive Partition Active”...
  • Page 8 Table of Contents WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.35.2 “v3 User n” Group(s) .............. 175 7.8.1.35.3 “Add New v3 User” Group ............176 7.8.1.36 “Diagnostic Information” Page ............ 177 7.8.1.37 “Configuration of OpenVPN and IPsec” Page ......178 7.8.1.37.1...
  • Page 9 WAGO I/O SYSTEM 750 XTR Table of Contents 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.44.4 “MAC Address Filter” > “MAC address filter whitelist” Submenu ................202 7.8.1.44.5 “MAC address filter whitelist” > “Add new / No (n)” Submenu ................202 7.8.1.44.6...
  • Page 10 Table of Contents WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.2.2 Network Tab ................234 7.8.2.3 PLC Tab ..................236 7.8.2.4 Status Tab .................. 237 Run-time System CODESYS 2.3 ............238 Installing the CODESYS 2.3 Programming System ......238 First Program with CODESYS 2.3 ............
  • Page 11 WAGO I/O SYSTEM 750 XTR Table of Contents 750-8202/040-001 PFC200 2ETH RS TELE XTR 9.3.1 Modbus Settings................288 9.3.2 Modbus TCP Settings ..............289 9.3.3 Modbus UDP Settings ..............289 9.3.4 Modbus RTU Settings ..............290 Data Exchange ..................292 9.4.1...
  • Page 12 Table of Contents WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 9.6.3 Diagnostics for the Error Server ............312 Diagnostics ..................... 315 10.1 Operating and Status Messages ............315 10.1.1 Power Supply Indicating Elements ..........315 10.1.2 Fieldbus/System Indicating Elements ..........
  • Page 13 WAGO I/O SYSTEM 750 XTR Table of Contents 750-8202/040-001 PFC200 2ETH RS TELE XTR 14.1.2.7 16-Channel Digital Output Modules ..........355 14.1.3 Analog Input Modules ..............356 14.1.3.1 2-Channel Analog Input Modules ..........356 14.1.3.2 4-Channel Analog Input Modules ..........356 14.1.3.3...

  • Page 14: Notes About This Documentation

    (750-8202/040-001). This documentation is only applicable from FW Version 03.01.07(13). The device PFC200 2ETH RS TELE XTR 750-8202/040-001 shall only be installed and operated according to the instructions in this manual and the system description for the WAGO I/O SYSTEM 750 XTR.

  • Page 15: Symbols

    WAGO I/O SYSTEM 750 XTR Notes about this Documentation 750-8202/040-001 PFC200 2ETH RS TELE XTR Symbols Personal Injury! Indicates a high-risk, imminently hazardous situation which, if not avoided, will result in death or serious injury. Personal Injury Caused by Electric Current! Indicates a high-risk, imminently hazardous situation which, if not avoided, will result in death or serious injury.

  • Page 16: Number Notation

    Notes about this Documentation WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Additional Information: Refers to additional information which is not an integral part of this documentation (e.g., the Internet). Number Notation Table 1: Number Notation Number Code...

  • Page 17: Important Notes

    2.1.1 Subject to Changes WAGO Kontakttechnik GmbH & Co. KG reserves the right to provide for any alterations or modifications. WAGO Kontakttechnik GmbH & Co. KG owns all rights arising from the granting of patents or from the legal protection of utility patents.

  • Page 18: Technical Condition Of Specified Devices

    These modules contain no parts that can be serviced or repaired by the user. The following actions will result in the exclusion of liability on the part of WAGO Kontakttechnik GmbH & Co. KG: •...

  • Page 19: Packaging

    WAGO I/O SYSTEM 750 XTR Important Notes 750-8202/040-001 PFC200 2ETH RS TELE XTR • Observe national and local regulations for the disposal of electrical and electronic equipment. • Clear any data stored on the electrical and electronic equipment. • Remove any added battery or memory card in the electrical and electronic equipment.

  • Page 20: Safety Advice (Precautions)

    Important Notes WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Safety Advice (Precautions) For installing and operating purposes of the relevant device to your system the following safety precautions shall be observed: Do not work on devices while energized! All power sources to the device shall be switched off prior to performing any installation, repair or maintenance work.
  • Page 21 WAGO I/O SYSTEM 750 XTR Important Notes 750-8202/040-001 PFC200 2ETH RS TELE XTR Do not touch hot surfaces! The surface of the housing can become hot during operation. If the device was operated at high ambient temperatures, allow it to cool off before touching it.
  • Page 22 Important Notes WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Avoid electrostatic discharge! The devices are equipped with electronic components that may be destroyed by electrostatic discharge when touched. Please observe the safety precautions against electrostatic discharge per DIN EN 61340-5-1/-3. When handling the devices, please ensure that environmental factors (personnel, work space and packaging) are properly grounded.

  • Page 23: Licensing Terms Of The Software Package Used

    They can be accessed via the WBM page “Legal Information” > “Open Source Software.” You can obtain the source code with licensing terms of the open-source software from WAGO Kontakttechnik GmbH & Co. KG on request. Send your request to support@wago.com with the subject “Controller Board Support Package.”...
  • Page 24 Important Notes WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR performance of your control system. Use encryption methods to protect your data and observe the information provided by the Federal Office for Information Security – “Cloud: Risks and Security Tips”.

  • Page 25: Device Description

    These manuals are available in download area on the web page http://www.wago.com. You can connect all available I/O modules of the WAGO I/O SYSTEM 750 XTR to the controller, enabling it to internally process analog and digital signals from the automation environment, or to supply these signals to other devices via one of the available interfaces.
  • Page 26 CODESYS program to the data in the fieldbus process image and vice versa! Direct access is not possible! The fieldbus configuration can be defined with the WAGO-I/O-PRO or e!COCKPIT controller configuration, depending on the set runtime system (CODESYS 2 or e!RUNTIME).
  • Page 27 </dg_ Only use recommended memory cards! Use only the SD memory cards available from WAGO (item No. 758-879/000- 001 and 758-879/000-2108) as these are suitable for industrial applications subjected to environmental extremes and for use in this device. Compatibility with other commercially available storage media cannot be guaranteed.

  • Page 28: View

    Device Description WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR View Figure 1: View Table 3: Legend for Figure “View” Item Description See section Marking options (Mini WSB) “Display Elements” > “Power LED indicators – power pupply Supply Indicating Elements”...
  • Page 29 WAGO I/O SYSTEM 750 XTR Device Description 750-8202/040-001 PFC200 2ETH RS TELE XTR “Mounting” > “Inserting Devices” Safe locking feature “Removal” > “Removing Devices” “Connectors” > Serial interface – X3 “Communication Interface” “Display Elements” > LED indicators – system “Fieldbus/System Indicating Elements”...

  • Page 30: Labeling

    Device Description WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Labeling The front labeling includes: Device designation Name of the display elements, connections and control elements Serial number with hardware and firmware version The side labeling includes:...

  • Page 31: Connectors

    WAGO I/O SYSTEM 750 XTR Device Description 750-8202/040-001 PFC200 2ETH RS TELE XTR Connectors 3.3.1 Data Contacts/Local Bus Communication between the controller and the I/O modules and system power supply for the I/O modules is provided via the local bus, which consists of 6 data contacts designed as self-cleaning gold spring contacts.

  • Page 32: Power Jumper Contacts/Field Supply

    750-8202/040-001 PFC200 2ETH RS TELE XTR 3.3.2 Power Jumper Contacts/Field Supply The controller 750-8202/040-001 is equipped with 2 self-cleaning power contacts for transferring of the field-side power supply to down-circuit I/O modules. These contacts are designed as spring contacts. Figure 4: Power Jumper Contacts Table 4: Legend for Figure “Power Jumper Contacts”...

  • Page 33: Cage Clamp ® Connectors

    WAGO I/O SYSTEM 750 XTR Device Description 750-8202/040-001 PFC200 2ETH RS TELE XTR 3.3.3 CAGE CLAMP ® Connectors Figure 5: CAGE CLAMP ® Connectors Table 5: Legend for Figure “CAGE CLAMP ® Connectors” Contact Designation Description 24 V System power supply voltage +24 V Field-side power supply voltage U −...

  • Page 34: Service Interface

    750-8202/040-001 PFC200 2ETH RS TELE XTR 3.3.4 Service Interface The service interface is located behind the flap. The Service interface is used for communication with WAGO-I/O-CHECK and “WAGO Ethernet Settings”. Figure 6: Service Interface (Closed and Open Flap) Table 6: Service Interface...

  • Page 35: Network Connectors

    WAGO I/O SYSTEM 750 XTR Device Description 750-8202/040-001 PFC200 2ETH RS TELE XTR 3.3.5 Network Connectors Figure 7: Network Connections – X1, X2 Table 7: Legend for Figure “Network Connections – X1, X2” Contact Signal Description TD + Transmit Data + TD −...

  • Page 36: Communication Interface

    Device Description WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 3.3.6 Communication Interface Figure 8: RS-232/RS-485 – Communication Connection – X3 Table 8: Legend for Figure “RS-232/RS-485 – Communication Connection – X3” RS-232 (DCE) RS-485 Contact Signal...

  • Page 37: Operating As An Rs-232 Interface

    WAGO I/O SYSTEM 750 XTR Device Description 750-8202/040-001 PFC200 2ETH RS TELE XTR 3.3.6.1 Operating as an RS-232 Interface Kommunikationsanschluss Depending on the device type DTE (Data Terminal Equipment, e.g., PC) or DCE (Data Communication Equipment, e.g., PFC, modem), the RS-232 signals have different data directions.

  • Page 38: Operating As An Rs-485 Interface

    Device Description WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 3.3.6.2 Operating as an RS-485 Interface To minimize reflection at the end of the line, the RS-485 line must be terminated at both ends by a cable termination. If required, one pull-up or pull-down resistor may be used.

  • Page 39: Display Elements

    WAGO I/O SYSTEM 750 XTR Device Description 750-8202/040-001 PFC200 2ETH RS TELE XTR Display Elements 3.4.1 Power Supply Indicating Elements Figure 12: Power Supply Indicating Elements Table 10: Legend for Figure “Power Supply Indicating Elements” Description Color Description Green/off Status of system power supply voltage...

  • Page 40: Fieldbus/System Indicating Elements

    Module status Orange/Off Red/Green/ Without function Orange/Off User LED 7, programmable using function Red/Green/ blocks from the WAGO libraries to control the Orange/Off LEDs User LED 6, programmable using function Red/Green/ blocks from the WAGO libraries to control the Orange/Off...

  • Page 41: Memory Card Indicating Elements

    WAGO I/O SYSTEM 750 XTR Device Description 750-8202/040-001 PFC200 2ETH RS TELE XTR 3.4.3 Memory Card Indicating Elements Figure 14: Indicating Elements, Memory Card Slot Table 12: Legend for Figure “Indicating Elements, Memory Card Slot” Designation Color Description Yellow/Off Memory card status Manual Version 1.2.0, valid from FW Version 03.01.07(13)

  • Page 42: Network Indicating Elements

    Device Description WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 3.4.4 Network Indicating Elements Figure 15: Indicating Elements, RJ-45 Jacks Table 13: Legend for Figure “Indicating Elements, RJ-45 Jacks” Designation Color Description Green/Off ETHERNET connection status Yellow/Off...

  • Page 43: Operating Elements

    WAGO I/O SYSTEM 750 XTR Device Description 750-8202/040-001 PFC200 2ETH RS TELE XTR Operating Elements 3.5.1 Operating Mode Switch Figure 16: Mode Selector Switch The function of the mode selector switch depends on the activated runtime system (CODESYS 2 or e!RUNTIME).

  • Page 44: Reset Button

    Device Description WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 3.5.2 Reset Button Figure 17: Reset Button The Reset button is installed behind drilling to prevent operating errors. It is a shortstroke button with a low actuating force of 1.1 N … 2.1 N (110 gf … 210 gf).

  • Page 45: Slot For Memory Card

    </dg_ Only use recommended memory cards! Use only the SD memory cards available from WAGO (item No. 758-879/000- 001 and 758-879/000-2108) as these are suitable for industrial applications subjected to environmental extremes and for use in this device. Compatibility with other commercially available storage media cannot be guaranteed.

  • Page 46: Schematic Diagram

    Device Description WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Schematic Diagram Figure 19: Schematic Diagram Manual Version 1.2.0, valid from FW Version 03.01.07(13)

  • Page 47: Technical Data

    WAGO I/O SYSTEM 750 XTR Device Description 750-8202/040-001 PFC200 2ETH RS TELE XTR Technical Data 3.8.1 Device Data Table 16: Technical Data – Device Width 79 mm Height (from upper edge of DIN-rail) 65 mm Depth 100 mm Weight 210 g...

  • Page 48: Supply

    Device Description WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 3.8.3 Supply Table 18: Technical Data – Supply Internal current consumption (5 VDC) 510 mA Total current for I/O modules (5 VDC) 1700 mA Input current at nominal load typ.

  • Page 49: Clock

    WAGO I/O SYSTEM 750 XTR Device Description 750-8202/040-001 PFC200 2ETH RS TELE XTR 3.8.4 Clock </dg_ Table 19: Technical Data – Clock Drift - system clock (25 °C) 20 ppm Drift - RTC (25 °C) 3 ppm Buffer time RTC (25 °C) 30 days 3.8.5...

  • Page 50: Ethernet

    Device Description WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 3.8.7 ETHERNET Table 22: Technical Data – ETHERNET ETHERNET 2 x RJ-45 (switched or separated mode) Transmission medium Twisted Pair S-UTP, 100 Ω, Cat 5, 100 m maximum cable length Baud rate 10/100 Mbit/s;...

  • Page 51: Mechanical Conditions

    WAGO I/O SYSTEM 750 XTR Device Description 750-8202/040-001 PFC200 2ETH RS TELE XTR 3.8.10 Mechanical Conditions Table 27: Technical Data – Mechanical Conditions Vibration resistance Max. 5g Follow the installation instructions 3.8.11 Climatic Environmental Conditions Table 28: Technical Data ‒ Climatic Environmental Conditions Surrounding air temperature, operation −40 °C …...

  • Page 52: Approvals

    Approvals More information about approvals. Detailed references to the approvals are listed in the document “Overview Approvals WAGO I/O SYSTEM 750”, which you can find via the internet under: www.wago.com  DOWNLOADS  Documentation  System Description. The following approvals have been granted to 750-8202/040-001 fieldbus...

  • Page 53: Standards And Guidelines

    WAGO I/O SYSTEM 750 XTR Device Description 750-8202/040-001 PFC200 2ETH RS TELE XTR 3.10 Standards and Guidelines 750-8202/040-001 fieldbus coupler/controller meets the following standards and guidelines: Table 29: Standards and Rated Conditions for Explosion Protection Applications ATEX acc. Directive 2014/34/EU General Requirements...

  • Page 54: Table 30: Climatic And Mechanical Environmental Conditions And

    Device Description WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 30: Climatic and Mechanical Environmental Conditions and Shipbuilding Standard Test Value Transport EN 60870-2-2 Ct2(2k4) (except precipitation/water/moisture) Mechanical Environmental Conditions EN 61850-3 Achieved EN 60870-2-2 EN 60721-3-1...

  • Page 55: Table 31: Emc - Immunity To Interference

    WAGO I/O SYSTEM 750 XTR Device Description 750-8202/040-001 PFC200 2ETH RS TELE XTR The fieldbus coupler/controller 750-8202/040-001 meets the following EMC standards as these standards relate to the fieldbus coupler/controller: Table 31: EMC – Immunity to Interference Standard Test Value Electrostatic Discharge •...
  • Page 56 Device Description WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 31: EMC – Immunity to Interference Standard Test Value Alternating Components of the Voltage to DC Line Connections • EN 61000-4-17 15 % • EN 60255-26 Damped Oscillatory Waves •...

  • Page 57: Table 32: Emc - Emission Of Interference

    WAGO I/O SYSTEM 750 XTR Device Description 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 32: EMC – Emission of Interference Standard Test Value Enclosure Emission of Interference • EN 61000-6-3 30 dB(µV/m), QP, 30 MHz … 230 MHz • EN 55032 Class B 37 dB(µV/m), QP, 230 MHz …...

  • Page 58: Table 33: Standards And Rated Conditions For Rail Applications (En 50155)

    5.5 EMC (Emission of Interference, EN 50121-3-2 Immunity to Interference) EN 50121-4 EN 50121-5 9.11 Materials (Fire Protection) EN 45545-2 Hazard level HL3 WAGO is a company certified in accordance with the IRIS quality standard. Manual Version 1.2.0, valid from FW Version 03.01.07(13)

  • Page 59: Function Description

    WAGO I/O SYSTEM 750 XTR Function Description 750-8202/040-001 PFC200 2ETH RS TELE XTR Function Description </dg_ Network 4.1.1 Interface Configuration The ETHERNET X1 and X2 interfaces of the controller are connected with an internal 3-port switch, in which the third port is connected to the CPU.

  • Page 60: Network Security

    Function Description WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 4.1.2 Network Security 4.1.2.1 Users and Passwords Several groups of users are provided in the controller which can be used for various services. Default passwords are set for all users. We strongly recommend changing these...

  • Page 61: Wbm User Group

    WAGO I/O SYSTEM 750 XTR Function Description 750-8202/040-001 PFC200 2ETH RS TELE XTR 4.1.2.1.2 WBM User Group WBM has its own user administration system. The users in this system are isolated from the other user groups in the system for security reasons.

  • Page 62: Web Protocols For Wbm Access

    Function Description WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 4.1.2.2 Web Protocols for WBM Access The HTTP and HTTPS web protocols can be used to access the WBM pages for the controller. HTTPS is preferred because it uses the SSL/TLS protocol. The...
  • Page 63 WAGO I/O SYSTEM 750 XTR Function Description 750-8202/040-001 PFC200 2ETH RS TELE XTR BSI Guidelines on Migration to TLS 1.2 The German Federal Office for Information Security guidelines on migration to TLS 1.2 contain “compatibility matrices” that show what software is comparable with TLS 1.2.

  • Page 64: Root Certificates

    Function Description WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 4.1.2.3 Root Certificates For communication encrypted with TLS, root certificates are used to verify the authenticity of the communication partner. A root certificate, which is signed by a certificate authority, serves to verify the validity of all certificates issued by this certificate authority.

  • Page 65: Network Configuration

    WAGO I/O SYSTEM 750 XTR Function Description 750-8202/040-001 PFC200 2ETH RS TELE XTR </dg_ 4.1.3 Network Configuration 4.1.3.1 Host Name/Domain Name Without a host name configuration, the controller is assigned a default name which includes the last three values of the controller's MAC address, e.g., “PFCx00-A1A2A3.”...
  • Page 66 Function Description WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR and destination mask entries is always selected. The default gateway corresponds to the least specific routing entry. All network data packets such that no specific routing entry exists for their destination address and destination mask are sent to this default gateway.
  • Page 67 WAGO I/O SYSTEM 750 XTR Function Description 750-8202/040-001 PFC200 2ETH RS TELE XTR For forwarding network communication through a router, it is necessary to note that corresponding routing entries must be provided not only for the router, but also for the respective endpoints of the communication. The routing entries of the endpoints must ensure that the desired network data packets are sent via the router, both when the connection is established and with the replies.

  • Page 68: Network Services

    Function Description WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 4.1.5 Network Services 4.1.5.1 DHCP Client The controller can get network parameters from an external DHCP master via the DHCP Client service. The following parameters can be obtained: •...

  • Page 69: Table 36: List Of Parameters Transmitted Via Dhcp

    WAGO I/O SYSTEM 750 XTR Function Description 750-8202/040-001 PFC200 2ETH RS TELE XTR The settings are made, for example, in the WBM via the “DHCP Configuration” page. The DHCP server also passes other parameters in addition to the IP address.

  • Page 70: Dns Server

    Function Description WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Not all parameters can be set in the WBM. If you want to set other values for the existing parameters or want to pass other parameters via DHCP, the DHCP server must be manually configured.

  • Page 71: Cloud Connectivity Functionality

    WAGO I/O SYSTEM 750 XTR Function Description 750-8202/040-001 PFC200 2ETH RS TELE XTR 4.1.6 Cloud Connectivity Functionality With the cloud connectivity functionality and an IEC library, the controller is available as a gateway for Internet-of-Things (IoT) applications. This means the...

  • Page 72: Components Of The Cloud Connectivity Software Package

    Observe the necessary data protection and security settings! Before using the cloud connectivity functionality, consult the corresponding handbook and familiarize yourself with data protection and security issues. You will find this in the Downloads area at www.wago.com. 4.1.6.1 Components of the Cloud Connectivity Software Package...

  • Page 73: Memory Card Function

    Memory Card Function </dg_ Only use recommended memory cards! Use only the SD memory cards available from WAGO (item No. 758-879/000- 001 and 758-879/000-2108) as these are suitable for industrial applications subjected to environmental extremes and for use in this device.
  • Page 74 Function Description WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Memory card access from CODESYS only possible with FAT16, FAT32 or NTFS! If the CODESYS user “admin” (see the section “Network” > “Network Security” > “Users and Passwords” > “Services and Users“) is supposed to be able to access files created on the memory card, the memory card must be formatted with FAT16, FAT32 or NTFS.

  • Page 75: Data Backup

    WAGO I/O SYSTEM 750 XTR Function Description 750-8202/040-001 PFC200 2ETH RS TELE XTR 4.2.2 Data Backup The controller has a backup function and a restore function. The necessary settings can be made and the functions can be executed via the WBM pages or via the CBM “Backup”...

  • Page 76: Restore Function

    Function Description WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR The controller has an automatic update function. If this function is activated on a memory card before the data backup and a controller is booted from this memory card, this data is restored automatically on the internal memory of the controller.
  • Page 77 WAGO I/O SYSTEM 750 XTR Function Description 750-8202/040-001 PFC200 2ETH RS TELE XTR File size must not exceed the size of the internal drive! Note that the amount of data in the media/sd/copy/ directory must not exceed the total size of the internal drive.

  • Page 78: Inserting A Memory Card During Operation

    Function Description WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 4.2.3 Inserting a Memory Card during Operation The fieldbus nodes and the PLC program are running. Insert a memory card during ongoing operation. During normal operation, the memory card is incorporated into the file system of the controller as a drive.

  • Page 79: Setting The Home Directory For The Runtime System

    WAGO I/O SYSTEM 750 XTR Function Description 750-8202/040-001 PFC200 2ETH RS TELE XTR 4.2.5 Setting the Home Directory for the Runtime System The home directory for the runtime system is located in the controller's internal memory by default. An existing boot project may be saved in the home directory.

  • Page 80: Load Boot Project

    Function Description WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 4.2.6 Load Boot Project If a boot project exists, it may be loaded, depending on the home directory setting for the runtime system. The following table shows the possible results: Table 38: Loading a Boot Project “Home...

  • Page 81: Mounting

    WAGO I/O SYSTEM 750 XTR Mounting 750-8202/040-001 PFC200 2ETH RS TELE XTR Mounting Installation Position The following mounting positions are approved for the WAGO I/O SYSTEM 750 XTR: • Nominal mounting position (horizontal left) • Floor mounting position • Vertical top mounting position •...

  • Page 82: Figure 21: Mounting Positions

    Mounting WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Figure 21: Mounting Positions Use an end stop in the case of vertical installation! When mounting in the “vertical top” or “vertical bottom" mounting position, also mount an end stop below the fieldbus node to protect the fieldbus node against sliding.

  • Page 83: Overall Configuration

    WAGO Kontakttechnik GmbH & Co. KG supplies standardized carrier rails that are optimal for use with the I/O system. If other carrier rails are used, then a technical inspection and approval of the rail by WAGO Kontakttechnik GmbH & Co. KG should take place.
  • Page 84 Mounting WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR • Most components have a contact to the carrier rail to ground electro- magnetic disturbances. In order to avoid corrosion, this tin-plated carrier rail contact must not form a galvanic cell with the material of the carrier rail which generates a differential voltage above 0.5 V (saline solution of 0.3 %...

  • Page 85: Wago Din Rail

    WAGO I/O SYSTEM 750 XTR Mounting 750-8202/040-001 PFC200 2ETH RS TELE XTR 5.3.2 WAGO DIN Rail WAGO carrier rails meet the electrical and mechanical requirements shown in the table below. Table 39: WAGO DIN Rail Order number Description 210-112 /-113 35 ×...

  • Page 86: Spacing

    Mounting WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Spacing The spacing between adjacent components, cable conduits, casing and frame sides must be maintained for the complete fieldbus node. Figure 22: Spacing The spacing creates room for heat transfer, installation or wiring. The spacing to cable conduits also prevents conducted electromagnetic interferences from influencing the operation.

  • Page 87: Mounting Sequence

    Mounting 750-8202/040-001 PFC200 2ETH RS TELE XTR Mounting Sequence Fieldbus couplers, controllers and I/O modules of the WAGO I/O SYSTEM 750 are snapped directly on a carrier rail in accordance with the European standard EN 60175 (DIN 35). The reliable positioning and connection is made using a tongue and groove system.

  • Page 88: Inserting Devices

    Mounting WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Mixed operation Mixed operation (standard/XTR modules) within a node is possible when groups of modules are electrically isolated on the field side (i.e., electrically isolated power supply). Inserting Devices Do not work when devices are energized! High voltage can cause electric shock or burns.

  • Page 89: Inserting The I/O Module

    WAGO I/O SYSTEM 750 XTR Mounting 750-8202/040-001 PFC200 2ETH RS TELE XTR 5.6.2 Inserting the I/O Module Position the I/O module so that the tongue and groove joints to the fieldbus coupler or controller or to the previous or possibly subsequent I/O module engaged.

  • Page 90: Connect Devices

    Connect Devices WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Connect Devices Only connect or disconnect lines when power is safely isolated! The lines to the device can carry hazardous voltages and currents. Contact with the lines when live can result in severe injury or death. Therefore, read and observe the following safety rules before you perform work on the device: Disconnect the respective system component from the power supply.

  • Page 91: Connecting A Conductor To The Cage Clamp

    Do not connect more than one conductor at one single connection! If more than one conductor must be routed to one connection, these must be connected in an up-circuit wiring assembly, for example using WAGO feed- through terminals. To open the CAGE CLAMP insert the actuating tool into the opening ®...

  • Page 92: Power Supply Concept

    Therefore, you should always dimension the overcurrent protection according to the anticipated power usage. The system and field voltage of the WAGO I/O SYSTEMs 750 XTR is supplied on the head stations and bus supply modules. For components that work with extra low voltage, only SELV/PELV voltage sources should be used.

  • Page 93: Supplementary Power Supply Regulations

    6.3.1 Supplementary Power Supply Regulations The WAGO I/O SYSTEM 750 XTR can also be used in shipbuilding applications and onshore/offshore installations (e.g., platforms, loading facilities), as well as in telecontrol applications. This is possible via certification under the standards of leading agencies such as Germanischer Lloyd and Lloyds Register.

  • Page 94: Figure 28: Power Supply Concept

    Connect Devices WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Figure 28: Power Supply Concept Table 42: Legende for Figure “Power Supply Concept” Pos. Description XTR Fieldbus coupler / controller Supply filter; 24 VDC; higher isolation; extreme...

  • Page 95: Supply Example

    WAGO I/O SYSTEM 750 XTR Connect Devices 750-8202/040-001 PFC200 2ETH RS TELE XTR 6.3.2 Supply Example SupplSggggggggggggggggg The system supply and the field supply shall be separated! You should separate the system supply and the field supply in order to ensure bus operation in the event of a short-circuit on the actuator side.

  • Page 96: Table 43: Legend For Figure "Power Supply Example

    Connect Devices WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 43: Legend for Figure “Power Supply Example” Item Description Power supply on the fieldbus coupler/controller via external system supply module Supply module 24 V Supply module with bus power supply 24 V...

  • Page 97: Power Supply Units

    Connect Devices 750-8202/040-001 PFC200 2ETH RS TELE XTR 6.3.3 Power Supply Units The WAGO I/O SYSTEM 750 XTR requires 24 VDC voltage (system supply) for operation. Recommendation A stable power supply cannot always be assumed everywhere. Therefore, you should use regulated power supplies to ensure the quality of the supply voltage.

  • Page 98: Grounding

    Connect Devices WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Grounding 6.4.1 Grounding the DIN Rail 6.4.1.1 Framework Assembly When setting up the framework, the carrier rail must be screwed together with the electrically conducting cabinet or housing frame. The framework or the housing must be grounded.

  • Page 99: Grounding Function

    WAGO I/O SYSTEM 750 XTR Connect Devices 750-8202/040-001 PFC200 2ETH RS TELE XTR 6.4.2 Grounding Function The grounding function increases the resistance against electro-magnetic interferences. Some components in the I/O system have a carrier rail contact that dissipates electro-magnetic interferences to the carrier rail.

  • Page 100: Shielding

    Higher shielding performance is achieved via low-impedance connection between shield and ground. For this purpose, connect the shield over a large surface area, e.g., WAGO shield connecting system. This is especially recommended for large-scale systems where equalizing current or high impulse- type currents caused by atmospheric discharge may occur.

  • Page 101: Shielded Signal Lines

    I/O module can be achieved even in the presence of interference acting on the signal cable. On some WAGO devices you can directly clamp the shield. For all other devices use the WAGO shield connecting system.

  • Page 102: Commissioning

    102 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Commissioning Switching On the Controller Before switching on the controller ensure that you • have properly installed the controller (see section “Installation”), • have connected all required data cables (see section “Connections”) to the...

  • Page 103: Determining The Ip Address Of The Host Pc

    WAGO I/O SYSTEM 750 XTR Commissioning 103 750-8202/040-001 PFC200 2ETH RS TELE XTR Determining the IP Address of the Host PC To ensure that the host PC can communicate with the controller via ETHERNET, both devices must be located in the same subnet.

  • Page 104: Setting An Ip Address

    Adapt IP addressing to your specific system structure to ensure that the PC and the controller can communicate with one another using one of the available configuration tools (WBM, WAGO ETHERNET Settings or CBM – see section “Configuration”). Example for incorporating the controller (192.168.2.17) into an existing network: The IP address of the host PC is 192.168.1.2.

  • Page 105: Assigning An Ip Address Using Dhcp

    WAGO I/O SYSTEM 750 XTR Commissioning 105 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.3.1 Assigning an IP Address using DHCP The Controller can obtain dynamic IP addresses from a server (DHCP/BootP). In contrast to fixed IP addresses, dynamically assigned addresses are not stored permanently.

  • Page 106: Changing An Ip Address Using The "Cbm" Configuration Tool And A Terminal Program

    106 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.3.2 Changing an IP Address Using the “CBM” Configuration Tool and a Terminal Program You can also assign a new IP address to the ETHERNET interfaces X1 and X2 using the “CBM”...

  • Page 107: Figure 36: Cbm - Selecting "Networking

    WAGO I/O SYSTEM 750 XTR Commissioning 107 750-8202/040-001 PFC200 2ETH RS TELE XTR In the Main menu use the keyboard (arrow keys or numeric keypad) to move to and select Networking and then press [Enter]. Figure 36: CBM – Selecting “Networking”...

  • Page 108: Figure 39: Cbm - Selecting The Ip Address

    108 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR In the menu TCP/IP Configuration select IP Address and press [Enter]. Figure 39: CBM – Selecting the IP Address In the menu Change IP Address enter the new IP address and confirm by clicking [OK].

  • Page 109: Changing An Ip Address Using "Wago Ethernet Settings

    To configure the controller use at least Version 6.4.1.1 dated 2015-06-29 of “WAGO Ethernet Settings”! You can use WAGO communication cables or WAGO radio adapters or even the IP network for data communication. Switch off the power supply to the controller.

  • Page 110: Figure 42: "Wago Ethernet Settings" - "Network" Tab

    “WAGO Ethernet Settings” will restart your controller. This action may require about 30 seconds.) You can now close “WAGO Ethernet Settings”, or make other changes directly in the Web-based Management system as required. To do this, click on [Run WBM] at the right in the window.

  • Page 111: Temporarily Setting A Fixed Ip Address

    WAGO I/O SYSTEM 750 XTR Commissioning 111 750-8202/040-001 PFC200 2ETH RS TELE XTR </dg_ 7.3.4 Temporarily Setting a Fixed IP Address This procedure temporarily sets the IP address for the X1 interface to the fixed address “192.168.1.17”. When the switch is enabled, the fixed address is also used for interface X2.

  • Page 112: Testing The Network Connection

    112 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Testing the Network Connection Carry out a ping network function to check whether you can reach the controller at the IP address you have assigned in the network.

  • Page 113: Changing Passwords

    WAGO I/O SYSTEM 750 XTR Commissioning 113 750-8202/040-001 PFC200 2ETH RS TELE XTR Changing Passwords Change standard passwords The standard passwords are documented in these instructions and therefore do not offer adequate protection! Change the passwords to meet your particular...

  • Page 114: Shutdown/Restart

    114 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR </dg_ Shutdown/Restart Switch off the power supply to shut down the controller. To perform a controller restart, press the Reset button as described in the Section “Triggering Reset Functions” > “Software Reset (Restart).”...

  • Page 115: Initiating Reset Functions

    On a cold start reset the CODESYS 2 application is reset and the memory containing the retain variables is cleared. This corresponds to the WAGO I/O PRO IDE “Reset (Cold)” command. </dg_ To perform a cold start reset, set the mode selector switch to “Reset” and hold it there for more than seven seconds.

  • Page 116: Configuration

    WagoConfigToolLIB.lib (section “Appendix” > “WagoConfigToolLIB.lib”) or the e!RUNTIME library “WagoAppConfigTool.lib” • Access via the PC using “WAGO Ethernet Settings” (section “Configuration Using ‘WAGO Ethernet Settings’”). The CBM is basically for the initial configuration and startup of the controller. Therefore, it only provides a subset of the WBM parameters. For example, parameters that cannot be displayed in a terminal window in a reasonable way and are not necessary for initial startup are not displayed.
  • Page 117 WAGO I/O SYSTEM 750 XTR Commissioning 117 750-8202/040-001 PFC200 2ETH RS TELE XTR The HTML pages (from here on referred to as “pages”) of the Web-Based Management are used to configure the controller. Proceed as follows to access the WBM using a web browser: Connect the controller to the ETHERNET network via the ETHERNET interface X1.

  • Page 118: Wbm User Administration

    118 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Some pages of the WBM are accessible only for certain users. They are only displayed if you have logged into the WBM. You can access the login form via the “Login”...

  • Page 119: Status Information" Page

    WAGO I/O SYSTEM 750 XTR Commissioning 119 750-8202/040-001 PFC200 2ETH RS TELE XTR Figure 45: Password Reminder Table 47: User Settings in the Default State Users Password user user admin wago Observe access rights Users in WBM are authorized exclusively for access to websites. User administration for controller applications is configured separately.

  • Page 120: Table 49: Wbm "Status Information Page - "Network Details Xn" Group(S)

    120 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 49: WBM “Status Information Page – “Network Details Xn” Group(s) Parameter Explanation Status of the ETHERNET interface State (enabled/disabled) Mac Address MAC address identifies and addresses the controller...

  • Page 121: Plc Runtime Information" Page

    WAGO I/O SYSTEM 750 XTR Commissioning 121 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.3 “PLC Runtime Information” Page All information about the enabled runtime system and PLC program created in the programming software is provided on the “PLC Runtime Information” page.

  • Page 122: Task N" Group(S)

    122 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.3.3 “Task n” Group(s) This group is only visible if CODESYS 2 is enabled as the runtime system. One dedicated group is displayed for each task when the PLC program is executed.

  • Page 123: General Plc Runtime Configuration" Page

    WAGO I/O SYSTEM 750 XTR Commissioning 123 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.4 “General PLC Runtime Configuration” Page The settings for the boot project created with the programming software are given on the “General PLC Runtime Configuration” page. 7.8.1.4.1 “General PLC Runtime Configuration” Group Table 53: WBM “General PLC Runtime Configuration”...
  • Page 124 124 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR The home directory change only takes effect after restarting the controller. For this purpose, use the WBM reboot function. Do not shut down the controller too early! Manual Version 1.2.0, valid from FW Version 03.01.07(13)

  • Page 125: Plc Webvisu" Page

    WAGO I/O SYSTEM 750 XTR Commissioning 125 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.5 “PLC WebVisu” Page The settings for the web visualization created in the runtime system are shown on the “PLC WebVisu” page. 7.8.1.5.1 “Web Server Configuration” Group Table 54: WBM “PLC WebVisu”...

  • Page 126: Configuration Of Host And Domain Name" Page

    126 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.6 “Configuration of Host and Domain Name” Page The settings for the general TCP/IP parameters are found on the “Configuration of Host and Domain Name” page. 7.8.1.6.1 “HostName” Group Table 55: WBM “Configuration of Host and Domain Name”...

  • Page 127: Tcp/Ip Configuration" Page

    WAGO I/O SYSTEM 750 XTR Commissioning 127 750-8202/040-001 PFC200 2ETH RS TELE XTR </dg_ 7.8.1.7 “TCP/IP Configuration” Page The TCP/IP settings for the ETHERNET interfaces are shown on the “TCP/IP configuration” page. 7.8.1.7.1 “IP Configuration (Xn)” Group(s) If the switch is enabled, one group (“IP Configuration”) is shown for both connections.

  • Page 128: Default Gateway N" Groups

    128 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.7.2 “Default Gateway n” Groups You can configure two default gateways. The controller transmits all network data not going to a station on the local network to a default gateway. First the gateway with the lowest metric is addressed.

  • Page 129: Dns Server" Group

    WAGO I/O SYSTEM 750 XTR Commissioning 129 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.7.3 “DNS Server” Group Table 59: WBM “TCP/IP Configuration” Page – “DNS Server” Group Parameters Explanation The addresses of the defined DNS servers are Configured: None/ displayed. If no server has been defined, DNS Server n “Configured: None”...

  • Page 130: Ethernet Configuration" Page

    130 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.8 “Ethernet Configuration” Page The settings for Ethernet TCP/IP are located on the “Ethernet Configuration” page. 7.8.1.8.1 “Switch Configuration” Group Table 60: WBM “Ethernet Configuration” Page – “Switch Configuration” Group...

  • Page 131: Interface Xn" Groups

    WAGO I/O SYSTEM 750 XTR Commissioning 131 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.8.2 “Interface Xn” Groups One group (“Interface X1” / “Interface X2”) is displayed for each connection. Table 61: WBM “Ethernet Configuration” Page – “Interface Xn” Groups Parameter...

  • Page 132: Routing" Page

    132 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.9 “Routing” Page On the “Routing” page you can find settings and information on the routing between the network interfaces. 7.8.1.9.1 “General Routing Configuration” Group Table 62: WBM “Routing” Page – “General Routing Configuration” Group...

  • Page 133: Static Routes" Group

    WAGO I/O SYSTEM 750 XTR Commissioning 133 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.9.2 “Static Routes” Group Each configured static route has its own area in the display. To maintain compatibility with earlier firmware versions, at least two routing entries always exist. These can be disabled, but not removed. If a route is either removed or disabled, it is no longer entered in the system.

  • Page 134: Dynamic Routes" Group

    134 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.9.3 “Dynamic Routes” Group All default gateways received via DHCP are displayed here. Default gateways configured via DHCP are given the metric value 10, which means that they are normally used before the statically configured default gateways.

  • Page 135: Port Forwarding" Group

    WAGO I/O SYSTEM 750 XTR Commissioning 135 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.9.5 “Port Forwarding” Group Each entry has its own area in the display. Table 65: WBM “Routing” Page – “Port Forwarding” Group Parameter Explanation Specify here whether port forwarding should be used.

  • Page 136: General Firewall Configuration" Page

    136 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.10 “General Firewall Configuration” Page 7.8.1.10.1 “Global Firewall Parameters” Group Table 66: WBM “General Firewall Configuration” Page – “Global Firewall Parameters” Group Parameters Explanation Enables/disables the complete functionality of the firewall.

  • Page 137: Firewall Parameters Interface Xxx" Group

    WAGO I/O SYSTEM 750 XTR Commissioning 137 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.10.2 “Firewall Parameters Interface xxx” Group These settings in this group refer to the configuration of the firewall at IP level. Table 67: WBM “General Firewall Configuration” Page – “Firewall Parameter Interface xxx” Group...

  • Page 138: Configuration Of Mac Address Filter" Page

    138 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR </dg_ 7.8.1.11 “Configuration of MAC Address Filter” Page You set the firewall configuration at ETHERNET level on this page. The “MAC Address Filter Whitelist” contains a default entry with the following...

  • Page 139: Mac Address Filter State Xn" Group

    WAGO I/O SYSTEM 750 XTR Commissioning 139 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.11.2 “MAC Address Filter State Xn” Group Table 70: WBM “Configuration of MAC Address Filter” Page – “MAC Address Filter State Xn” Group Parameters Explanation Enable or disable here the MAC address filter for the Filter enabled specific interface.

  • Page 140: Configuration Of User Filter" Page

    140 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.12 “Configuration of User Filter” Page 7.8.1.12.1 “User Filter” Group Table 72: WBM “Configuration of User Filter” Page – “User Filter” Group Parameters Explanation Count The number of configured user filters is displayed.

  • Page 141: Add New User Filter" Group

    WAGO I/O SYSTEM 750 XTR Commissioning 141 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.12.3 “Add New User Filter” Group You can enter 10 filters. You only have to enter values in the fields that are to be set for the filter. At least one value must be entered, all other fields can remain empty.

  • Page 142: Configuration Of Time And Date" Page

    142 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.13 “Configuration of Time and Date” Page The settings for date and time are shown on the “Configuration of Time and Date” page. 7.8.1.13.1 “Date on Device” Group Table 75: WBM “Configuration of Time and Date”...

  • Page 143: Time Zone" Group

    WAGO I/O SYSTEM 750 XTR Commissioning 143 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.13.3 “Time Zone” Group You can specify the appropriate time zone for your location in this group. The total number of possible time zones is over 500. A complete listing would exceed the scope of this documentation.

  • Page 144: Tz String" Group

    144 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.13.4 “TZ String” Group In this group you can enter a time zone that is not contained in the “Time Zone” selection. If the controller can associate the TZ string entered with a known time zone that had been missing from the “Time Zone”...

  • Page 145: Configuration Of The Users For The Web-Based Management" Page

    WAGO I/O SYSTEM 750 XTR Commissioning 145 750-8202/040-001 PFC200 2ETH RS TELE XTR </dg_ 7.8.1.14 “Configuration of the Users for the Web-based Management” Page The settings for user administration are shown on this page. 7.8.1.14.1 “Change Password for Selected User” Group...

  • Page 146: Create Bootable Image" Page

    146 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR </dg_ 7.8.1.15 “Create Bootable Image” Page You can create a bootable image on the “Create Bootable Image” page. 7.8.1.15.1 "Create Bootable Image from Active Partition (<Active Partition>"...
  • Page 147 WAGO I/O SYSTEM 750 XTR Commissioning 147 750-8202/040-001 PFC200 2ETH RS TELE XTR Remove the memory card write protection! Because write access to the memory card is possible during the boot process, the memory card cannot be write protected when creating the image and during operation.

  • Page 148: Configuration Of Serial Interface Rs232" Page

    148 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR </dg_ 7.8.1.16 “Configuration of Serial Interface RS232” Page The settings for the serial interface are shown on the “Configuration of Serial Interface RS232” page. 7.8.1.16.1 “Serial Interface Assigned to” Group The application that the serial interface is currently assigned to is displayed.

  • Page 149: Configuration Of Service Interface" Page

    WAGO I/O SYSTEM 750 XTR Commissioning 149 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.17 “Configuration of Service Interface” Page The settings for the service interface are shown on the “Configuration of the Service Interface” page. 7.8.1.17.1 “Service Interface assigned to” Group The application that the service interface is currently assigned to is displayed.

  • Page 150: Reboot Controller" Page

    150 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR </dg_ 7.8.1.18 “Reboot Controller” Page The settings for the system reboot are shown on the “Reboot Controller” page. 7.8.1.18.1 “Reboot Controller” Group Click the [Reboot] button to reboot the system.

  • Page 151: Firmware Backup" Page

    WAGO I/O SYSTEM 750 XTR Commissioning 151 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.19 “Firmware Backup” Page You can find the controller data backup settings on the “Firmware Backup” page. Table 83: “Firmware-Backup” WBM Page Parameters Explanation You can select the data to be backed up here.
  • Page 152 152 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR No backup of the memory card! Backup from the memory card to the internal flash memory is not possible. Account for backup time Generation of backup files can take several minutes. Stop the CODESYS program before you start the backup procedure to help shorten the time required.

  • Page 153: Firmware Restore" Page

    WAGO I/O SYSTEM 750 XTR Commissioning 153 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.20 “Firmware Restore” Page The settings for restoring the controller data are shown on the “Firmware Restore” page. Table 84: “Firmware Restore” WBM Page Parameters Explanation Select the data source for the restore here.
  • Page 154 154 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Note the firmware version! Restoring the controller operating system (“System” selection) is only permissible and possible if the firmware versions at the backup and restore times are identical.

  • Page 155: System Partition" Page

    WAGO I/O SYSTEM 750 XTR Commissioning 155 750-8202/040-001 PFC200 2ETH RS TELE XTR </dg_ 7.8.1.21 “System Partition” Page The settings for specifying the partition that the system will be started from are shown on the “System Partition” page. 7.8.1.21.1 “Current Active Partition” Group The partition currently in use is displayed here.

  • Page 156: Mass Storage" Page

    156 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR </dg_ 7.8.1.22 “Mass Storage” Page A group containing information about the storage volume is displayed for each storage volume that is found, along with an additional group for formatting (when this is possible).

  • Page 157: Software Uploads" Page

    WAGO I/O SYSTEM 750 XTR Commissioning 157 750-8202/040-001 PFC200 2ETH RS TELE XTR </dg_ 7.8.1.23 “Software Uploads” Page The settings for a device update are shown on the “Software Uploads” page. 7.8.1.23.1 “Upload New Software” Group Table 87: WBM “Software Uploads” Page – “Upload New Software” Group...

  • Page 158: Configuration Of Network Services" Page

    158 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.24 “Configuration of Network Services” Page The settings for various services are shown on the “Configuration of Network Services” page. Besides enabling/disabling the individual services, you can also limit the services for each particular interface via the firewall on the “General Firewall...

  • Page 159: Http" Group

    WAGO I/O SYSTEM 750 XTR Commissioning 159 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.24.4 “HTTP” Group Table 92: WBM “Configuration of Network Services” Page – “HTTP” Group Parameter Explanation Service active Enable/disable the HTTP service here. Click the [Submit] button to apply the changes. The change takes effect immediately.

  • Page 160: Opc Ua" Group

    160 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.24.7 “OPC UA” Group Table 95: WBM “Configuration of Network Services” Page – “OPC UA” Group Parameter Explanation Service active Enable/disable the OPC UA service here. Click the [Submit] button to apply the changes. The change only takes effect once the controller restarts.

  • Page 161: Configuration Of Ntp Client" Page

    WAGO I/O SYSTEM 750 XTR Commissioning 161 750-8202/040-001 PFC200 2ETH RS TELE XTR </dg_ 7.8.1.25 “Configuration of NTP Client” Page The settings for the NTP service are shown on the “Configuration of NTP Client” page. 7.8.1.25.1 “NTP Client Configuration” Group Table 96: WBM “Configuration of NTP Client”...

  • Page 162: Configuration Of Plc Runtime Services" Page

    162 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.26 “Configuration of PLC Runtime Services” Page The settings for various services of the activated runtime system are shown on the “Configuration of PLC Runtime Services” page.

  • Page 163: Ssh Server Settings" Page

    WAGO I/O SYSTEM 750 XTR Commissioning 163 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.27 “SSH Server Settings” Page The settings for the SSH service are shown on the “SSH Server Settings” page. 7.8.1.27.1 “SSH Server” Group Table 100: WBM “SSH Server Settings” Page – “SSH Server” Group...

  • Page 164: Tftp Server" Page

    164 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR </dg_ 7.8.1.28 “TFTP Server” Page The settings for the TFTP service are shown on the “TFTP Server” page. 7.8.1.28.1 “TFTP Server” Group Table 101: WBM “TFTP Server” Page – “TFTP Server” Group...

  • Page 165: Dhcp Configuration" Page

    WAGO I/O SYSTEM 750 XTR Commissioning 165 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.29 “DHCP Configuration” Page The settings for the DHCP service are shown on the “DHCP Configuration” page. 7.8.1.29.1 “DHCP Configuration Xn” Group Table 102: WBM “DHCP Configuration” – “DHCP Configuration Xn” Group...

  • Page 166: Configuration Of Dns Service" Page

    166 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.30 “Configuration of DNS Service” Page The settings for the DNS service are shown on the “Configuration of DNS Service” page. 7.8.1.30.1 “DNS Service” Group Table 103: WBM “Configuration of DNS Service” Page – “DNS Service” Group...

  • Page 167: Modbus Services Configuration" Page

    WAGO I/O SYSTEM 750 XTR Commissioning 167 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.31 “Modbus Services Configuration” Page The settings for various Modbus services are shown on the “Modbus Services Configuration” page. The groups are only visible if the e!RUNTIME system is enabled.

  • Page 168: Configuration Of Cloud Connectivity" Page

    168 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.32 “Configuration of Cloud Connectivity” Page On the page “Configuration of Cloud Connectivity” you can find the settings and information for cloud access. Observe the additional documentation! You can find a detailed description of the “Cloud Connectivity”...

  • Page 169: Settings" Group

    WAGO I/O SYSTEM 750 XTR Commissioning 169 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.32.3 “Settings” Group The parameters indicated depend on the cloud platform setting and, if applicable, on other settings in this group. Table 108: WBM “Configuration of Cloud Connectivity” Page – “Settings” Group...
  • Page 170 170 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 108: WBM “Configuration of Cloud Connectivity” Page – “Settings” Group Parameter Explanation Enter the path here to the file encoded in PEM Key file format that contains the private key for cloud service authentication.

  • Page 171: Table 109: Dependencies Of The Selection And Input Fields For The Selected Cloud Platform

    WAGO I/O SYSTEM 750 XTR Commissioning 171 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 109: Dependencies of the Selection and Input Fields for the Selected Cloud Platform Data Cloud Platform Protocol Selection or Input Field Service enabled Cloud platform Host name Group ID >...

  • Page 172: Configuration Of General Snmp Parameters" Page

    172 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.33 “Configuration of General SNMP Parameters” Page The general settings for SNMP are given on the “Configuration of General SNMP Parameters” page. 7.8.1.33.1 “General SNMP Configuration” Group Table 110: WBM “Configuration of General SNMP Parameters”...

  • Page 173: Configuration Of Snmp V1/V2C Parameters" Page

    WAGO I/O SYSTEM 750 XTR Commissioning 173 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.34 “Configuration of SNMP v1/v2c Parameters” Page The general settings for SNMP v1/v2c are shown on the “Configuration of SNMP v1/v2c Parameters” page. 7.8.1.34.1 “SNMP v1/v2c Manager Configuration” Group Table 111: WBM “Configuration of SNMP v1/v2c Parameters”...

  • Page 174: Trap Receiver N" Group(S)

    174 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.34.3 “Trap Receiver n” Group(s) A dedicated group with the following information is displayed for each trap receiver: Table 113: WBM “Configuration of SNMP v1/v2c Parameters” Page – “Trap Receiver n” Group(s)

  • Page 175: Configuration Of Snmp V3 Users" Page

    WAGO I/O SYSTEM 750 XTR Commissioning 175 750-8202/040-001 PFC200 2ETH RS TELE XTR </dg_ 7.8.1.35 “Configuration of SNMP v3 Users” Page The general settings for SNMP v3 are shown on the “Configuration of SNMP v3 Users” page. 7.8.1.35.1 “Actually Configured v3 Users” Group(s) Table 115: WBM “Configuration of SNMP v3”...

  • Page 176: Add New V3 User" Group

    176 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.35.3 “Add New v3 User” Group You can enter 10 users. Table 117: WBM “Configuration of SNMP v3 Users” Page – “Add New v3 User” Group Parameters Explanation Enter the user name here.

  • Page 177: Diagnostic Information" Page

    WAGO I/O SYSTEM 750 XTR Commissioning 177 750-8202/040-001 PFC200 2ETH RS TELE XTR </dg_ 7.8.1.36 “Diagnostic Information” Page The settings for displaying diagnostic messages are shown on the “Diagnostic Information” page. Table 118: WBM “Diagnostic Information” Page Parameter Explanation Read all notifications Activate display of all messages.

  • Page 178: Configuration Of Openvpn And Ipsec" Page

    178 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.37 “Configuration of OpenVPN and IPsec” Page The general settings for OpenVPN and IPsec are shown on the “Configuration of OpenVPN and IPsec” page. 7.8.1.37.1 “OpenVPN” Group Table 119: WBM “Configuration of OpenVPN and IPsec”...

  • Page 179: Certificate Upload" Group

    WAGO I/O SYSTEM 750 XTR Commissioning 179 750-8202/040-001 PFC200 2ETH RS TELE XTR To transfer the selected file from the controller to the PC, click [Start Download] button. The changes only take effect after restarting the controller. For this purpose, use the WBM reboot function.

  • Page 180: Security Settings" Page

    180 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.38 “Security Settings” Page The network security settings are found on the “Security Settings” page. 7.8.1.38.1 “TLS Configuration” Group Table 124: “Security Settings” WBM Page – “TLS Configuration” Group...

  • Page 181: Open Source Licenses" Page

    WAGO I/O SYSTEM 750 XTR Commissioning 181 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.39 “Open Source Licenses” Page The licence conditions for the open source software used for the controller are listed in alphabetical order on the “Open Source Licenses” page.

  • Page 182: Wago Licenses" Page

    750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.40 “WAGO Licenses” Page The licence conditions for the WAGO software used in the controller are listed on the “WAGO Licenses” page. The Console-Based Management Tool (CBM) is basically used for the initial configuration and startup of the controller via a terminal program.

  • Page 183: Information" > "Network Details" Submenu

    WAGO I/O SYSTEM 750 XTR Commissioning 183 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.41.2 “Information” > “Network Details” Submenu In this submenu, the network and interface properties of the controller are displayed. If the EHERNET interfaces are operated in “Switched” mode, a common table (“X1/X2”) is displayed for both connections.

  • Page 184: Plc Runtime" Menu

    184 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.42 “PLC Runtime” Menu This menu contains other submenus with information and settings for the runtime system. Table 128: “PLC Runtime” Menu Menu Item Explanation 0. Back to …...

  • Page 185: Information" > "Runtime Version" Submenu

    WAGO I/O SYSTEM 750 XTR Commissioning 185 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.42.2 “Information” > “Runtime Version” Submenu In this submenu, the runtime version is displayed. Table 130: “PLC Runtime” > “Information” > “Runtime Version” Submenu Parameters Explanation The version of the currently enabled runtime system Version is shown.

  • Page 186: Information" > "Number Of Tasks" Submenu

    186 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.42.5 “Information” > “Number of Tasks” Submenu In this submenu, the number of tasks in the PLC program are displayed. The submenu only appears when CODESYS 2 is enabled as the runtime system.

  • Page 187: Tasks" > "Task N" Submenu

    WAGO I/O SYSTEM 750 XTR Commissioning 187 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.42.8 “Tasks” > “Task n” Submenu In this submenu, information on the selected task is displayed. The submenu only appears when CODESYS 2 is enabled as the runtime system.

  • Page 188: General Configuration" > "Plc Runtime Version" Submenu

    188 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.42.10 “General Configuration” > “PLC Runtime Version” Submenu In this submenu, select which PLC runtime system is enabled. Table 138: “PLC Runtime” > “General Configuration” > “PLC Runtime Version” Submenu...

  • Page 189: Plc Runtime" > "Webvisu" Submenu

    WAGO I/O SYSTEM 750 XTR Commissioning 189 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.42.12 “PLC Runtime” > “WebVisu” Submenu This submenu contains information and settings for the Web visualization. Table 140: “PLC Runtime” > “WebVisu” Submenu Menu Item Submenu Item / Explanation 0.

  • Page 190: Networking" Menu

    190 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.43 “Networking” Menu This menu contains other submenus with settings for the network configuration. Table 141: “Networking” Menu Parameters Explanation 0. Back to … Back to the higher-level menu Opens a submenu with setting options for the 1.

  • Page 191: Host/Domain Name" > "Hostname" Submenu

    WAGO I/O SYSTEM 750 XTR Commissioning 191 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.43.2 “Host/Domain Name” > “Hostname” Submenu In this submenu, you can set the hostname of the controller. Table 143: “Networking” > “Hostname” Submenu Parameters Explanation Enter here the hostname of the controller to be used...

  • Page 192: Tcp/Ip" > "Ip Address" Submenu

    192 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.43.5 “TCP/IP” > “IP Address” Submenu This submenu contains other submenus with settings for the ETHERNET interfaces. The submenu only appears if the controller is operated in “Separated” mode.

  • Page 193: Tcp/Ip" > "Default Gateway" Submenu

    WAGO I/O SYSTEM 750 XTR Commissioning 193 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.43.7 “TCP/IP” > “Default Gateway” Submenu This submenu contains other submenus with settings for the default gateway. Table 148: “Networking” > “TCP/IP” > “Default Gateway” Submenu Menu Item Explanation 0.

  • Page 194: Tcp/Ip" > "Dns Server" Submenu

    194 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.43.9 “TCP/IP” > “DNS Server” Submenu This submenu contains the settings for the DNS server. Table 150: “Networking” > “TCP/IP” > “DNS Server” Submenu Menu Item Submenu Item / Explanation 0.

  • Page 195: Ethernet" > "Switch Configuration" Submenu

    WAGO I/O SYSTEM 750 XTR Commissioning 195 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.43.11 “Ethernet” > “Switch Configuration” Submenu This submenu contains the settings for the Switch configuration. Table 152: “Networking” > “Ethernet” > “Switch Configuration” Submenu Submenu Submenu Item / Explanation 0.

  • Page 196: Ethernet Ports" > "Interface Xn" Submenu

    196 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.43.13 “Ethernet Ports” > “Interface Xn” Submenu This submenu contains the settings for the selected ETHERNET interface. Table 154: “Networking” > “Ethernet” > “Ethernet Ports” > “Interface Xn” Submenu...

  • Page 197: Firewall" Menu

    WAGO I/O SYSTEM 750 XTR Commissioning 197 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.44 “Firewall” Menu This menu contains other submenus for the firewall functionality settings. Table 155: “Firewall” Menu Menu Item Explanation 0. Back to … Back to the higher-level menu 1.

  • Page 198: Firewall" > "General Configuration" Submenu

    198 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.44.1 “Firewall” > “General Configuration” Submenu This submenu contains the general settings for the firewall. Table 156: “Firewall” > “General Configuration” Submenu Menu Item Submenu Item / Explanation 0.

  • Page 199: General Configuration" > "Interface Xxx" Submenu

    WAGO I/O SYSTEM 750 XTR Commissioning 199 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.44.2 “General Configuration” > “Interface xxx” Submenu This submenu contains the firewall settings on the IP level for the selected interface. Table 157: “Firewall” > “General Configuration” > “Interface xxx” Submenu...

  • Page 200: Table 158: Ports For Telecontrol Functionality

    200 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Click [<OK>] to apply the entry. Click [<Abort>] to discard the entry. The firewall ports listed in the following table are open by default on controllers with telecontrol functionality. The corresponding telecontrol services can be executed via these ports without the firewall blocking their communication.

  • Page 201: Firewall" > "Mac Address Filter" Submenu

    WAGO I/O SYSTEM 750 XTR Commissioning 201 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.44.3 “Firewall” > “MAC Address Filter” Submenu This submenu contains the settings for the MAC address filter. Table 159: “Firewall” > “MAC Address Filter” Submenu Menu Item Submenu Item / Explanation 0.

  • Page 202: Mac Address Filter" > "Mac Address Filter Whitelist" Submenu

    202 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.44.4 “MAC Address Filter” > “MAC address filter whitelist” Submenu This submenu displays all available filter entries. Table 160: “Firewall” > “MAC Address Filter” > “MAC address filter whitelist” Submenu...

  • Page 203: Firewall" > "User Filter" Submenu

    WAGO I/O SYSTEM 750 XTR Commissioning 203 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.44.6 “Firewall” > “User Filter” Submenu This submenu displays all available filter entries. Table 162: “Firewall” > “User Filter” Submenu Menu Item Explanation 0. Back to …...

  • Page 204: User Filter" > "Add New / No (N)" Submenu

    204 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.44.7 “User Filter” > “Add New / No (n)” Submenu In this submenu, you can create, change or delete filter entries. Table 163: “Firewall” > “User Filter” > “Add New / No (n)” Submenu...

  • Page 205: Clock" Menu

    WAGO I/O SYSTEM 750 XTR Commissioning 205 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.45 “Clock” Menu This menu contains other submenus for the date and time settings. Table 164: “Clock” Menu Menu Item Submenu Item / Explanation 0. Back to …...

  • Page 206: Administration" Menu

    206 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.46 “Administration” Menu This menu contains settings for controller administration. Table 165: “Administration” Menu Menu Item Submenu Item / Explanation 0. Back to … Back to the higher-level menu Opens a submenu with settings for the user 1.

  • Page 207: Administration" > "Users" Submenu

    WAGO I/O SYSTEM 750 XTR Commissioning 207 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.46.1 “Administration” > “Users” Submenu This submenu contains settings for the user passwords. Table 166: “Administration” > “Users” Submenu Menu Item Explanation 0. Back to … Back to the higher-level menu 1.

  • Page 208: Package Server" Menu

    208 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.47 “Package Server” Menu This menu contains other submenus with functions for firmware backup and restore, as well as information and setting options for the current system partition.

  • Page 209: Firmware Backup" > "Auto Update Feature" Submenu

    WAGO I/O SYSTEM 750 XTR Commissioning 209 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.47.2 “Firmware Backup” > “Auto Update Feature” Submenu This submenu contains a setting option for the Auto Update function. The submenu only appears if the data for the firmware backup has been selected.

  • Page 210: Package Server" > "Firmware Restore" Submenu

    210 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.47.4 “Package Server” > “Firmware Restore” Submenu This submenu contains a selection option for the restore source drive. In addition to the enabled partition, the current status is displayed.

  • Page 211: Package Server" > "System Partition" Submenu

    WAGO I/O SYSTEM 750 XTR Commissioning 211 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.47.6 “Package Server” > “System Partition” Submenu This submenu contains information and setting options for the current system partition. Table 174: “Package Server” > “System Partition” Submenu...

  • Page 212: Mass Storage" Menu

    212 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.48 “Mass Storage” Menu This menu contains information on the internal flash memory and, if inserted, on the external memory card. In addition to the menu item, the status is displayed for the enabled partition.

  • Page 213: Software Uploads" Menu

    WAGO I/O SYSTEM 750 XTR Commissioning 213 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.49 “Software Uploads” Menu This menu contains choices and settings for the device update. You can select fieldbus software, program licenses and update scripts, for example, for transfer from a PC to the controller.

  • Page 214: Ports And Services" Menu

    Opens a submenu with settings for the DHCPD 9. DHCPD service 10. DNS Opens a submenu with settings for the DNS service Opens a submenu with settings for the WAGO-I/O- 11. IOCHECK PORT CHECK port Opens a submenu with settings for the Modbus TCP 12. Modbus TCP...

  • Page 215: Ports And Services" > "Telnet" Submenu

    WAGO I/O SYSTEM 750 XTR Commissioning 215 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.50.1 “Ports and Services” > “Telnet” Submenu This submenu contains the settings for the Telnet service. Table 178: “Ports and Services” > “Telnet” Submenu Menu Item Submenu Item / Explanation 0.

  • Page 216: Ports And Services" > "Ftps" Submenu

    216 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.50.3 “Ports and Services” > “FTPS” Submenu This submenu contains the settings for the FTPS service. Table 180: “Ports and Services” > “FTPS” Submenu Menu Item Submenu Item / Explanation 0.

  • Page 217: Ports And Services" > "Https" Submenu

    WAGO I/O SYSTEM 750 XTR Commissioning 217 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.50.5 “Ports and Services” > “HTTPS” Submenu This submenu contains the settings for the HTTPS service. Table 182: “Ports and Services” > “HTTPS” Submenu Menu Item Submenu Item / Explanation 0.

  • Page 218: Ports And Services" > "Ssh" Submenu

    218 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.50.7 “Ports and Services” > “SSH” Submenu This submenu contains the settings for the SSH service. Table 184: “Ports and Services” > “SSH” Submenu Menu Item Submenu Item / Explanation 0.

  • Page 219: Ports And Services" > "Dhcpd" Submenu

    WAGO I/O SYSTEM 750 XTR Commissioning 219 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.50.9 “Ports and Services” > “DHCPD” Submenu This submenu contains the settings for the DHCPD service. Table 186: “Ports and Services” > “DHCPD” Submenu Menu Item Explanation 0.

  • Page 220: Ports And Services" > "Dns" Submenu

    220 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.50.11 “Ports and Services” > “DNS” Submenu This submenu contains the settings for the DNS service. Table 188: “Ports and Services” > “DNS” Submenu Menu Item Submenu Item / Explanation 0.

  • Page 221: Ports And Services" > "Iocheck Port" Submenu

    WAGO I/O SYSTEM 750 XTR Commissioning 221 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.50.12 “Ports and Services” > “IOCHECK PORT” Submenu This submenu contains settings for the WAGO-I/O-CHECK port. Table 189: “Ports and Services” > “IOCHECK PORT” Submenu Menu Item Submenu Item / Explanation 0.

  • Page 222: Ports And Services" > "Modbus Udp" Submenu

    222 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.50.14 “Ports and Services” > “Modbus UDP” Submenu This submenu contains the settings for the Modbus UDP service. Table 191: “Ports and Services” > “Modbus UDP” Submenu...

  • Page 223: Firewall Status" Submenu

    WAGO I/O SYSTEM 750 XTR Commissioning 223 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.50.16 “…” > “Firewall Status” Submenu This submenu contains firewall settings for the selected service. Table 193: “Ports and Services” > “Firewall Status” Submenu Menu Item Submenu Item / Explanation 0.

  • Page 224: Ports And Services" > "Plc Runtime Services" Submenu

    224 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.50.17 “Ports and Services” > “PLC Runtime Services” Submenu This submenu contains the settings for the PLC runtime system services. Table 194: “Ports and Services” > “PLC Runtime Services” Submenu...

  • Page 225: Plc Runtime Services" > "Codesys 2" Submenu

    WAGO I/O SYSTEM 750 XTR Commissioning 225 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.50.18 “PLC Runtime Services” > “CODESYS 2” Submenu This submenu contains the settings for the CODESYS 2 service. Table 195: “Ports and Services” > “PLC Runtime Services” > “CODESYS 2” Submenu...

  • Page 226: Plc Runtime Services" > "E!Runtime" Submenu

    226 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.50.19 “PLC Runtime Services” > “e!RUNTIME” Submenu This submenu contains the settings for the e!RUNTIME service. Table 196: “Ports and Services” > “PLC Runtime Services” > “e!RUNTIME” Submenu...

  • Page 227: Snmp" Menu

    WAGO I/O SYSTEM 750 XTR Commissioning 227 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.51 “SNMP” Menu This menu contains other submenus with the SNMP settings. Table 197: “SNMP” Menu Parameters Explanation 0. Back to … Back to the higher-level menu 1.

  • Page 228: Snmp" > "Snmp V1/V2C Manager Configuration" Submenu

    228 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.51.2 “SNMP” > “SNMP v1/v2c Manager Configuration” Submenu This submenu contains the SNMP v1/v2c Manager settings. Table 199: “SNMP” > “SNMP v1/v2c Manager Configuration” Submenu Parameters Submenu Item / Explanation 0.

  • Page 229: Snmp" > "Snmp V3 Configuration" Submenu

    WAGO I/O SYSTEM 750 XTR Commissioning 229 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.51.4 “SNMP” > “SNMP v3 Configuration” Submenu This submenu contains settings for SNMP v3. Table 201: “SNMP” > “SNMP v3 Configuration” Submenu Parameters Explanation 0. Back to …...

  • Page 230: Snmp" > "(Secure)Snmp Firewalling" Submenu

    230 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.1.51.5 “SNMP” > “(Secure)SNMP firewalling” Submenu These submenus contain the SNMP firewall settings. Table 202: “SNMP” > “(Secure )SNMP firewalling” Submenu Menu Item Submenu Item / Explanation 0.

  • Page 231: Configuration Using "Wago Ethernet Settings

    To configure the controller, use at least Version 6.4.1.1 dated 2015-06-29 or newer of “WAGO Ethernet Settings”! You must select the correct COM port after starting “WAGO Ethernet Settings”. Figure 46: “WAGO Ethernet Settings” – Start Screen For this, click “Settings” and then “Communication”.

  • Page 232: Figure 47: "Wago Ethernet Settings" - Communication Link

    750-8202/040-001 PFC200 2ETH RS TELE XTR Figure 47: “WAGO Ethernet Settings” – Communication Link Once you have configured “WAGO Ethernet Settings” and have clicked [Apply], connection to the controller is established automatically. If “WAGO Ethernet Settings” has already been started with the correct parameters, you can establish connection to the controller by clicking [Read].

  • Page 233: Identification Tab

    Besides some fixed values — e.g., item No., MAC address and firmware version — the currently used IP address and the configuration method are also shown here. Figure 48: “WAGO Ethernet Settings” – Identification Tab (Example) Manual Version 1.2.0, valid from FW Version 03.01.07(13)

  • Page 234: Network Tab

    Specify the specific network parameters for static configuration. Restricted setting for default gateways! Only the default gateway 1 can be set via “WAGO Ethernet Settings.” The default gateway 2 can only be set in the WBM! Preferred DNS server, alternative DNS server Enter the IP address (when required) for an accessible DNS server when identifying network names.
  • Page 235 WAGO I/O SYSTEM 750 XTR Commissioning 235 750-8202/040-001 PFC200 2ETH RS TELE XTR Hostname The host name of the controller is displayed here. In the controller's initial state, this name is composed of the string “PFCx00” and the last three bytes of the MAC address.

  • Page 236: Plc Tab

    236 Commissioning WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.2.3 PLC Tab Figure 50: “WAGO Ethernet Settings” – Protocol Tab Here you can select the runtime system. Manual Version 1.2.0, valid from FW Version 03.01.07(13)

  • Page 237: Status Tab

    WAGO I/O SYSTEM 750 XTR Commissioning 237 750-8202/040-001 PFC200 2ETH RS TELE XTR 7.8.2.4 Status Tab Figure 51: “WAGO Ethernet Settings” – Status Tab General information about the controller status is displayed here. Manual Version 1.2.0, valid from FW Version 03.01.07(13)

  • Page 238: Run-Time System Codesys 2.3

    750-8202/040-001 PFC200 2ETH RS TELE XTR Run-time System CODESYS 2.3 Installing the CODESYS 2.3 Programming System The WAGO target files must also be included for the installation of CODESYS. These contain all device-specific information for the WAGO 750/758 product series.

  • Page 239: Figure 52: Target System Settings (1)

    WAGO I/O SYSTEM 750 XTR Run-time System CODESYS 2.3 239 750-8202/040-001 PFC200 2ETH RS TELE XTR Click on [OK]. The “Target system settings” configuration window then opens. Figure 52: Target System Settings (1) To accept the default configuration for the fieldbus controller click [OK].

  • Page 240: Creating The Plc Configuration

    240 Run-time System CODESYS 2.3 WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR In this “New component” window create a new program function block. In the example shown here, the new function block “PLC_PRG” is created in the “ST”...

  • Page 241: Figure 56: "Resources" Tab

    WAGO I/O SYSTEM 750 XTR Run-time System CODESYS 2.3 241 750-8202/040-001 PFC200 2ETH RS TELE XTR The PLC configuration is used to configure the fieldbus controller, along with the connected I/O modules and to declare variables for accessing the inputs and outputs of the I/O modules.

  • Page 242: Figure 57: Control Configuration - Edit

    There are three options for accepting the topology for the I/O modules connected to the fieldbus controller. The simplest way is to scan in the topology using WAGO-I/O-CHECK. To do this, click on the “Start WAGO-I/O-CHECK and scan” button. Figure 58: “Start WAGO-I/O-CHECK and Scan” Button Ensure proper installation of WAGO-I/O-CHECK! This function requires that the latest version of WAGO-I/O-CHECK be installed and the IP address set under “Online >...

  • Page 243: Figure 59: Wago-I/O-Check - Starting Screen

    WAGO-I/O-CHECK is started. Figure 59: WAGO-I/O-CHECK – Starting Screen To connect to the controller and read in the module configuration, click [Identify]. If this action is successful click [Save] and exit WAGO-I/O-CHECK. Manual Version 1.2.0, valid from FW Version 03.01.07(13)

  • Page 244: Figure 60: I/O Configurator Empty

    244 Run-time System CODESYS 2.3 WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR The detected I/O modules then appear in the configuration window. Passive I/O Modules Remember that passive I/O modules, such as a power supply module (750-602/040-000) or end module (750-600/040-000) will not be shown in the I/O configurator.

  • Page 245: Figure 62: "Module Selection" Window

    WAGO I/O SYSTEM 750 XTR Run-time System CODESYS 2.3 245 750-8202/040-001 PFC200 2ETH RS TELE XTR You can select a module in the new “Module selection” window that then appears. Figure 62: “Module Selection” Window You can change the position of an I/O module by marking it and then using the arrow buttons at the right edge of the window to move it up or down.

  • Page 246: Figure 64: Variable Declaration

    246 Run-time System CODESYS 2.3 WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Use [Import configuration from file] to add a configuration imported previously using WAGO-I/O-CHECK. To close the I/O Configurator, click [OK]. The individual inputs and outputs of the selected I/O module are displayed in the right half of the configuration window.

  • Page 247: Editing The Program Function Block

    WAGO I/O SYSTEM 750 XTR Run-time System CODESYS 2.3 247 750-8202/040-001 PFC200 2ETH RS TELE XTR 8.2.4 Editing the Program Function Block To edit the PLC_PRG program function block, go to the “Function block” tab and double-click on the PLC_PRG program module.

  • Page 248: Figure 68: Example Of An Allocation

    248 Run-time System CODESYS 2.3 WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Repeat Step 2 for the “Input_1” variable. Figure 68: Example of an Allocation To compile, click on Project > Compile all in the menu bar.

  • Page 249: Loading And Running The Plc Program In The Fieldbus Controller (Ethernet)

    WAGO I/O SYSTEM 750 XTR Run-time System CODESYS 2.3 249 750-8202/040-001 PFC200 2ETH RS TELE XTR 8.2.5 Loading and Running the PLC Program in the Fieldbus Controller (ETHERNET) Requirement: • The simulation is deactivated (Online > Simulation). • The PC is linked to the controller via ETHERNET. Refer to Section “Device Description”...

  • Page 250: Figure 70: Creating A Communication Link - Step 2

    250 Run-time System CODESYS 2.3 WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR In the “Name” field enter a designation for your fieldbus controller and then click on “Tcp/Ip (Level 2 Route)”. Then click [OK]. Figure 70: Creating a Communication Link – Step 2 In the “Communication Parameters”...

  • Page 251: Creating A Boot Project

    WAGO I/O SYSTEM 750 XTR Run-time System CODESYS 2.3 251 750-8202/040-001 PFC200 2ETH RS TELE XTR 8.2.6 Creating a Boot Project Create a boot project to ensure that the PLC program starts automatically again after a fieldbus controller restart. In the menu bar select Online > Create boot project.

  • Page 252: Syntax Of Logical Addresses

    252 Run-time System CODESYS 2.3 WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Syntax of Logical Addresses Access to individual memory elements according to IEC 61131-3 is possible using only the following special symbols: Table 203: Syntax of Logical Addresses...

  • Page 253: Figure 72: Task Configuration

    WAGO I/O SYSTEM 750 XTR Run-time System CODESYS 2.3 253 750-8202/040-001 PFC200 2ETH RS TELE XTR Figure 72: Task Configuration To create a task right-click on “Task configuration” and in the contextual menu select “Attach task”. Manual Version 1.2.0, valid from FW Version 03.01.07(13)

  • Page 254: Figure 73: Changing Task Names 1

    254 Run-time System CODESYS 2.3 WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR To assign a new name to the task (e.g. PLC_Prog), click on “New Task”. Then select the type of task. In this example, this is the “cyclic” type.

  • Page 255: Figure 74: Call-Up To Add To The Program Module

    WAGO I/O SYSTEM 750 XTR Run-time System CODESYS 2.3 255 750-8202/040-001 PFC200 2ETH RS TELE XTR Add the program module PLC_PRG that you have just created (see Section “Editing the Program Modules”). To do this, right-clock on the “Clock” symbol and in the contextual menu select “Attach program call-up”.

  • Page 256: Cyclic Tasks

    256 Run-time System CODESYS 2.3 WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 8.4.1 Cyclic Tasks You can assign a priority for each task in order to establish the task processing sequence. Figure 75: Cyclic Task Order of Task Processing The priorities given below do not specifiy the order of task processing.

  • Page 257: Freewheeling Tasks

    WAGO I/O SYSTEM 750 XTR Run-time System CODESYS 2.3 257 750-8202/040-001 PFC200 2ETH RS TELE XTR Priority 21 … 31: Applications such as long-lasting arithmetic operations and non-real-time- relevant access to ETHERNET and the file system, to fieldbus data and the RS- 232 interface (when provided) are to be carried out as tasks with the lowest priorities 21 …...

  • Page 258: System Events

    258 Run-time System CODESYS 2.3 WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR System Events Event tasks can be used in the CODESYS task configuration in addition to cyclical tasks. Event tasks call up certain events in the device.

  • Page 259: Table 204: Events

    WAGO I/O SYSTEM 750 XTR Run-time System CODESYS 2.3 259 750-8202/040-001 PFC200 2ETH RS TELE XTR The following events can be activated: Table 204: Events Name Description start The event is called directly after the user program starts. stop The event is called directly after the user program stops.

  • Page 260: Creating An Event Handler

    260 Run-time System CODESYS 2.3 WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 8.5.1 Creating an Event Handler The example here is provided to illustrate how to define and use an event handler. The event handler “excpt_dividebyzero” is used in this example.

  • Page 261: Figure 80: Codesys - New Module Has Been Generated

    WAGO I/O SYSTEM 750 XTR Run-time System CODESYS 2.3 261 750-8202/040-001 PFC200 2ETH RS TELE XTR Figure 80: CODESYS – New Module has been Generated Handling for the event that has occurred is now programmed in this new function. In the example here, the event is documented in a global variable.

  • Page 262: Figure 82: Codesys - Variable Contents Prior To Division By "0

    262 Run-time System CODESYS 2.3 WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Figure 82: CODESYS – Variable Contents Prior to Division by “0” Figure 83: CODESYS – Variable Contents After Division by “0” and Call-up of the Event Handler Manual Version 1.2.0, valid from FW Version 03.01.07(13)

  • Page 263: Process Images

    WAGO I/O SYSTEM 750 XTR Run-time System CODESYS 2.3 263 750-8202/040-001 PFC200 2ETH RS TELE XTR Process Images A process image is a memory area in which the process data is stored in a defined sequence and consists of the I/O modules attached to the local bus, the PFC variables, the bit memory address area and the slaves attached to the fieldbus.

  • Page 264: Process Images For I/O Modules Connected To The Controller

    264 Run-time System CODESYS 2.3 WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Figure 85: Flag Area 8.6.1 Process Images for I/O Modules Connected to the Controller After starting the fieldbus controller, it automatically detects all connected I/O modules.

  • Page 265: Process Image For Slaves Connected To The Fieldbus

    (I/O module 1 to 64 ) in the RAM Write Byte %QB0 to %QB1999 * The use of up to 250 I/O modules is possible with the WAGO local bus extension modules. Manual Version 1.2.0, valid from FW Version 03.01.07(13)

  • Page 266: Table 206: Access To The Process Images Of The Input And Output Data

    NVRAM: 128 kB Write * The use of up to 250 I/O modules is possible with the WAGO local bus extension modules. The total size of the memory for flag and retain variables is 128 kB (131060 bytes).

  • Page 267: Addressing Example

    WAGO I/O SYSTEM 750 XTR Run-time System CODESYS 2.3 267 750-8202/040-001 PFC200 2ETH RS TELE XTR Addressing Example The following addressing example clarifies the access to the process image: Table 208: Arrangement of the I/O Modules for the Addressing Example...

  • Page 268: Local Bus Synchronization

    268 Run-time System CODESYS 2.3 WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 209: Addressing Example I/O module Input data Output data Description Type End module 750-600 The passive 750-600 end module does not transmit any data.
  • Page 269 WAGO I/O SYSTEM 750 XTR Run-time System CODESYS 2.3 269 750-8202/040-001 PFC200 2ETH RS TELE XTR Example: CODESYS task interval (CTI): 100 µs Local bus cycle (LBZ): 2000 µs Result: Matching of the CODESYS task interval to the local bus cycle of 2000 µs.

  • Page 270: Case 2: Codesys Task Interval Smaller Than Twice The Local Bus Cycle

    270 Run-time System CODESYS 2.3 WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 8.9.2 Case 2: CODESYS Task Interval Smaller than Twice the Local Bus Cycle Execution of the local bus is synchronized with the set CODESYS task interval.

  • Page 271: Case 3: Codesys Task Interval Greater Than Twice The Local Bus Cycle

    WAGO I/O SYSTEM 750 XTR Run-time System CODESYS 2.3 271 750-8202/040-001 PFC200 2ETH RS TELE XTR 8.9.3 Case 3: CODESYS Task Interval Greater than Twice the Local Bus Cycle The I/O data from the local bus are refreshed once prior to the CODESYS task and once after the CODESYS task.

  • Page 272: Case 4: Codesys Task Interval Greater Than 10 Ms

    272 Run-time System CODESYS 2.3 WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 8.9.4 Case 4: CODESYS Task Interval Greater than 10 ms Synchronization takes place as in case 3; however, the output modules would be reset to their default state after 100 ms without a local bus cycle. This reliably prevents the execution of a local bus cycle after at least every 10 ms.

  • Page 273: Local Bus (Kbus) Settings

    WAGO I/O SYSTEM 750 XTR Run-time System CODESYS 2.3 273 750-8202/040-001 PFC200 2ETH RS TELE XTR 8.9.5 Local Bus (KBus) Settings Figure 90: Local Bus (KBus) Settings Manual Version 1.2.0, valid from FW Version 03.01.07(13)

  • Page 274: Table 210: Local Bus (Kbus) Settings

    274 Run-time System CODESYS 2.3 WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 210: Local Bus (KBus) Settings Parameter Explanation The update mode is used to configure how the local bus process data is to be updated (refreshed).

  • Page 275: Effect Of Update Mode On Codesys Tasks

    WAGO I/O SYSTEM 750 XTR Run-time System CODESYS 2.3 275 750-8202/040-001 PFC200 2ETH RS TELE XTR 8.9.5.1 Effect of Update Mode on CODESYS Tasks 8.9.5.1.1 Asynchronous Update Mode In the asynchronous update mode there is no direct influence on CODESYS task behavior.

  • Page 276: Memory Settings In Codesys

    276 Run-time System CODESYS 2.3 WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 8.10 Memory Settings in CODESYS The list below illustrates the standard memory allocation of the PFC200: • Program memory: 16 Mbyte (max.) • Data memory: 64 Mbytes •...

  • Page 277: Data Memory And Function Block Limitation

    WAGO I/O SYSTEM 750 XTR Run-time System CODESYS 2.3 277 750-8202/040-001 PFC200 2ETH RS TELE XTR 8.10.2 Data Memory and Function Block Limitation The data memory is set for 64 Mbytes in the controller's initial state. This set value has already been requested in the system after a successful program download and can be fully utilized.

  • Page 278: Remanent Memory

    278 Run-time System CODESYS 2.3 WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 8.10.3 Remanent Memory A total of 128 kbytes of remanent memory is available for the IEC-61131 application. The remanent section is subdivided into the flag area (memory) and the retain area.

  • Page 279: Figure 95: Selecting The Visualization Technique In The Target System

    WAGO I/O SYSTEM 750 XTR Run-time System CODESYS 2.3 279 750-8202/040-001 PFC200 2ETH RS TELE XTR PC along with a web browser. An applet is stored in the file system of a Web server and is accessible to web browsers via an HTML page.

  • Page 280: Figure 96: Creating The Plc_Visu Starting Visualization

    280 Run-time System CODESYS 2.3 WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Generate a start page for the visualization. Right-click the “Visualization” folder in the “Visualization” tab. Select Add object ... from the contextual menu. The “New visualization” dialog box opens.

  • Page 281: Limits Of Codesys Visualization

    WAGO I/O SYSTEM 750 XTR Run-time System CODESYS 2.3 281 750-8202/040-001 PFC200 2ETH RS TELE XTR Frequently Asked Questions Additional information (FAQs) on CODESYS Web visualization is also provided in the Section “Frequently Asked Questions about CODESYS Web Visualization” and in the online Help function for CODESYS 2.3.
  • Page 282 282 Run-time System CODESYS 2.3 WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Processor Time Make sure when configuring tasks, that there is sufficient processor time available for all processes. Network Load The controller's CPU processes both the PLC program and network traffic.

  • Page 283: Eliminating Errors In Codesys Web Visualization

    WAGO I/O SYSTEM 750 XTR Run-time System CODESYS 2.3 283 750-8202/040-001 PFC200 2ETH RS TELE XTR 8.11.2 Eliminating Errors in CODESYS Web Visualization If you are experiencing problems when working with the CODESYS Web visualization, use the following table to find the solution. If you cannot eliminate the problem, please contact WAGO support.

  • Page 284: Faqs About Codesys Web Visualization

    284 Run-time System CODESYS 2.3 WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 8.11.3 FAQs about CODESYS Web Visualization How can I optimize the applet for special screen resolutions? In order to optimize the Web visualization for display on a device with a fixed resolution, proceed as follows: In the “Target system settings”, enter the pixel width and height in the tab...
  • Page 285 WAGO I/O SYSTEM 750 XTR Run-time System CODESYS 2.3 285 750-8202/040-001 PFC200 2ETH RS TELE XTR Why does the visualization element “TREND” in the Web visualization only work “Online”? The following settings must be selected for visualization projects: Resources tab >...

  • Page 286: Modbus - Codesys 2

    286 Modbus – CODESYS 2 WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Modbus – CODESYS 2 </dg_ General Modbus is a non-vendor-specific, open fieldbus standard for a wide range of applications in production and process automation. The Modbus communications...

  • Page 287: Configuration

    WAGO I/O SYSTEM 750 XTR Modbus – CODESYS 2 287 750-8202/040-001 PFC200 2ETH RS TELE XTR Configuration All of the Modbus operating modes are configured using the CODESYS PLC configuration. Figure 97: CODESYS PLC Configuration - Modbus Settings The Modbus slave configuration is composed of four basic parameter groups: •...

  • Page 288: Modbus Settings

    288 Modbus – CODESYS 2 WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 9.3.1 Modbus Settings The “Modbus settings” group contains the following configuration parameters. Table 212: Modbus Settings Parameters Explanation PLC stop Response of the Modbus slave when the controller has halted...

  • Page 289: Modbus Tcp Settings

    WAGO I/O SYSTEM 750 XTR Modbus – CODESYS 2 289 750-8202/040-001 PFC200 2ETH RS TELE XTR 9.3.2 Modbus TCP Settings The “Modbus TCP Settings” contains the following configuration parameters for the “Modbus TCP” mode: Table 213: Modbus TCP Settings Parameters...

  • Page 290: Modbus Rtu Settings

    290 Modbus – CODESYS 2 WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 9.3.4 Modbus RTU Settings The “Modbus RTU Settings” group contains the following configuration parameters for the “Modbus RTU” mode: Table 215: Modbus RTU Settings...
  • Page 291 WAGO I/O SYSTEM 750 XTR Modbus – CODESYS 2 291 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 215: Modbus RTU Settings Parameters Explanation Flow control Data flow control (Supported only for the setting “RS-232” for the physical interface.) None No data flow control...

  • Page 292: Data Exchange

    Modbus flag area – is an area, in which both Modbus Read and Write • services can be executed. Modbus register – is an area, in which the WAGO specific information and • configuration registers are contained. Only Modbus register services may be executed in this area.

  • Page 293: Process Image

    WAGO I/O SYSTEM 750 XTR Modbus – CODESYS 2 293 750-8202/040-001 PFC200 2ETH RS TELE XTR 9.4.1 Process Image The main data interfaces between the PLC and the Modbus slave are the local Modbus process images in the PLC address area based on IEC 61131. The Modbus input process image (Modbus Input) is in the PIO and the Modbus output process image (Modbus Output) in the PII.

  • Page 294: Flag Area

    294 Modbus – CODESYS 2 WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 9.4.2 Flag Area Modbus can also exchange data and fieldbus variables with the PLC via the flag area. Caution is urged, however, when using data and/or variables in this area that is accessed by both Modbus and the PLC.

  • Page 295: Modbus Registers

    750-8202/040-001 PFC200 2ETH RS TELE XTR 9.4.3 Modbus Registers WAGO specific registers are implemented in the last Modbus-relevant address area; this simplifies the reading of certain system and Modbus information, as well as configuration. The Modbus address area reserved for these registers ranging from the Modbus starting address of 4096 (0x1000) up to the Modbus end address of 12287 (0x2FFF), without any allocation to the IEC 61131 address area.

  • Page 296: Modbus Mapping For Write Bit Services Fc5, Fc15

    296 Modbus – CODESYS 2 WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 9.4.4.2 Modbus Mapping for Write Bit Services FC5, FC15 The table below outlines the mapping for the Modbus-writing, bit-oriented services: • FC5 – Write Single Coil •...

  • Page 297: Modbus Mapping For Read Register Services Fc3, Fc4, Fc23

    WAGO I/O SYSTEM 750 XTR Modbus – CODESYS 2 297 750-8202/040-001 PFC200 2ETH RS TELE XTR 9.4.4.3 Modbus Mapping for Read Register Services FC3, FC4, FC23 The table below outlines the mapping for the Modbus-reading, register-oriented services: • FC3 – Read Holding Registers, •...

  • Page 298: Table 218: Modbus Mapping For Read Register Services Fc3, Fc4, Fc23

    298 Modbus – CODESYS 2 WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 218: Modbus Mapping for Read Register Services FC3, FC4, FC23 Modbus Address IEC 61131 Description (hexadecimal values Address in parentheses) 12288 … 65535 %MW0 …...

  • Page 299: Modbus Mapping For Write Register Services Fc6, Fc16, Fc22, Fc23

    WAGO I/O SYSTEM 750 XTR Modbus – CODESYS 2 299 750-8202/040-001 PFC200 2ETH RS TELE XTR 9.4.4.4 Modbus Mapping for Write Register Services FC6, FC16, FC22, FC23 The table below outlines the mapping for Modbus-writing, register-oriented services. • FC6 – Write Single Register, •...

  • Page 300: Table 219: Modbus Mapping For Write Register Services Fc6, Fc16, Fc22

    300 Modbus – CODESYS 2 WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 219: Modbus Mapping for Write Register Services FC6, FC16, FC22, FC23 Modbus Address IEC 61131 Description (hexadecimal values Address in parentheses) 12288 … 65535 %MW0 …...

  • Page 301: Wago Modbus Registers

    750-8202/040-001 PFC200 2ETH RS TELE XTR WAGO Modbus Registers System and Modbus data can be read and some Modbus parameters configured using the WAGO Modbus registers. The following table lists all of the WAGO Modbus registers. Table 220: WAGO Modbus Registers...

  • Page 302: Process Image Properties

    Major firmware version 8212 0x2014 Minor firmware version 8213 0x2015 MBS version The WAGO Modbus registers are described in more details in the following sections. 9.5.1 Process Image Properties 9.5.1.1 Register 0x1022 – Number of Registers in the Modbus Input Process Image This register contains the number of registers available in the Modbus input process image (Modbus input).

  • Page 303: Network Configuration

    WAGO I/O SYSTEM 750 XTR Modbus – CODESYS 2 303 750-8202/040-001 PFC200 2ETH RS TELE XTR 9.5.2 Network Configuration 9.5.2.1 Register 0x1028 – IP Configuration This register contains information about the set IP configuration. Possible values: 1 = BootP 2 = DHCP 4 = Fixed IP address 9.5.2.2...

  • Page 304: Plc Status Register

    304 Modbus – CODESYS 2 WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 9.5.3 PLC Status Register Register 0x1040 provides the status (state) that the controller is currently in. Possible values: 1 = PLC running − PLC status is RUNNING.

  • Page 305: Figure 101: State Diagram, Alternative_Watchdog Operation Mode

    WAGO I/O SYSTEM 750 XTR Modbus – CODESYS 2 305 750-8202/040-001 PFC200 2ETH RS TELE XTR Figure 101: State Diagram, ALTERNATIVE_WATCHDOG Operation Mode The state diagram for the ALTERNATIVE_WATCHDOG operation mode shows that the watchdog is always active as soon as a timeout time > 0 is set in the register 0x1102 (Watchdog Timeout).

  • Page 306: Register 0X1100 - Watchdog Command

    306 Modbus – CODESYS 2 WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Figure 102: State Diagram, Switchover Operation Mode 9.5.4.1 Register 0x1100 – Watchdog Command This register receives commands for the Modbus watchdog. It cannot be read, i.e.

  • Page 307: Table 221: Watchdog Commands

    WAGO I/O SYSTEM 750 XTR Modbus – CODESYS 2 307 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 221: Watchdog Commands Value Name Explanation 0x5555 WATCHDOG_ Starts the configured watchdog; START in the WATCHDOG_UNCONFIGURED state if no timeout is configured, the response is an ILLEGAL_DATA_VALUE (0x03) exception.

  • Page 308: Register 0X1101 - Watchdog Status

    308 Modbus – CODESYS 2 WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 9.5.4.2 Register 0x1101 – Watchdog Status This register provides the current state of the Modbus watchdog. The following states are possible: Table 222: Watchdog Status...

  • Page 309: Register 0X1103 - Watchdog Config

    WAGO I/O SYSTEM 750 XTR Modbus – CODESYS 2 309 750-8202/040-001 PFC200 2ETH RS TELE XTR 9.5.4.4 Register 0x1103 – Watchdog Config This register contains the configuration parameters for the watchdog. The register is organized in bits, see following table.

  • Page 310: Register 0X1104 - Watchdog Operation Mode

    9.5.5 Modbus Constants Registers Registers 0x2000 … 0x2008 provide constants based on the table “WAGO Modbus Registers”. It is possible to read all of the constants, or a consecutive portion of them at once. 9.5.6 Electronic Nameplate Registers 0x2010 to 0x2015 contain information from the electronic nameplate.

  • Page 311: Register 0X2011 - Series Designator

    Modbus – CODESYS 2 311 750-8202/040-001 PFC200 2ETH RS TELE XTR 9.5.6.2 Register 0x2011 – Series Designator This register provides the designation (ID) for the WAGO series (Series Code) for the controller. Example: 750 for WAGO I/O SYSTEM 750. 9.5.6.3 Register 0x2012 –...

  • Page 312: Diagnostics

    “PLC Status Registers”. The status of the Modbus Watchdog can be requested using a register service (FC3 or FC4) with a query to the WAGO specific register 0x1101 – “Watchdog Status Register”. Information about this is given in the Section “Modbus Watchdog”.
  • Page 313 WAGO I/O SYSTEM 750 XTR Modbus – CODESYS 2 313 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 225: Diagnostics for the Error Server Diagnostics Diagnostic text Method of Explanation saving 0x00090006 Modbus Slave Permanent Starting the Modbus slave in UDP start failed UDP mode failed.
  • Page 314 314 Modbus – CODESYS 2 WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 225: Diagnostics for the Error Server Diagnostics Diagnostic text Method of Explanation saving 0x00090108 Modbus Slave Permanent Modbus slave RTU RTU configuration configuration for the RS-485 in RS-485 mode mode has failed.

  • Page 315: Diagnostics

    WAGO I/O SYSTEM 750 XTR Diagnostics 315 750-8202/040-001 PFC200 2ETH RS TELE XTR Diagnostics 10.1 Operating and Status Messages The following tables contain descriptions of all operating and status messages for the controller which are indicated by LEDs. 10.1.1 Power Supply Indicating Elements...

  • Page 316: Fieldbus/System Indicating Elements

    316 Diagnostics WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 10.1.2 Fieldbus/System Indicating Elements Figure 104: Indicating Elements for Fieldbus/System The SYS LED indication depends on the runtime system enabled (CODESYS 2 or e!RUNTIME). The following indications apply to the CODESYS 2 runtime system: Manual Version 1.2.0, valid from FW Version 03.01.07(13)

  • Page 317: Table 228: Diagnostics Via Sys Led

    WAGO I/O SYSTEM 750 XTR Diagnostics 317 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 228: Diagnostics via SYS LED Status Explanation Remedy Green Ready to operate - System start completed without errors Orange Device is in startup/boot process and the RST button is not pressed.

  • Page 318: Table 229: Diagnostics Via Sys Led

    318 Diagnostics WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR The following indications apply to the e!RUNTIME runtime system: Table 229: Diagnostics via SYS LED Status Explanation Remedy Green Ready to operate - System start completed without...

  • Page 319: Table 230: Diagnostics Run Led

    WAGO I/O SYSTEM 750 XTR Diagnostics 319 750-8202/040-001 PFC200 2ETH RS TELE XTR The RUN LED indication depends on the runtime system enabled (CODESYS 2 or e!RUNTIME). The following indications apply to the CODESYS 2 runtime system: Table 230: Diagnostics RUN LED...

  • Page 320: Table 231: Run Led Diagnostics

    320 Diagnostics WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR The following indications apply to the e!RUNTIME runtime system: Table 231: RUN LED Diagnostics Status Explanation Remedy Green Applications loaded and all in the “RUN” status Green flashing No application and Load an application or boot project.

  • Page 321: Table 232: Diagnostics I/O Led

    WAGO I/O SYSTEM 750 XTR Diagnostics 321 750-8202/040-001 PFC200 2ETH RS TELE XTR The I/O LED indicates following diagnostics: Table 232: Diagnostics I/O LED Status Explanation Solution Green Data cycle on the local bus, normal operating status. Orange flashing Startup phase; the local Wait until initialization has bus is being initialized.

  • Page 322: Table 233: Ms-Led Diagnostics

    322 Diagnostics WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR The MS LED indicates following diagnostics: Table 233: MS-LED Diagnostics Status Explanation Remedy No error Red flashing A configuration error An explanation of the flashing sequence (flashing exists.

  • Page 323: Diagnostics Messages Via Flashing Sequences

    WAGO I/O SYSTEM 750 XTR Diagnostics 323 750-8202/040-001 PFC200 2ETH RS TELE XTR 10.2 Diagnostics Messages via Flashing Sequences 10.2.1 Flashing Sequences A diagnosis (fault/error) is always displayed as three flashing sequences in a cyclic manner: The first flashing sequence (flickering) initiates reporting of the fault/error.

  • Page 324: Figure 105: Flashing Sequence Process Diagram

    324 Diagnostics WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Figure 105: Flashing Sequence Process Diagram Manual Version 1.2.0, valid from FW Version 03.01.07(13)

  • Page 325: Example Of A Diagnostics Message Indicated By A Flashing Sequence

    WAGO I/O SYSTEM 750 XTR Diagnostics 325 750-8202/040-001 PFC200 2ETH RS TELE XTR 10.2.2 Example of a Diagnostics Message Indicated by a Flashing Sequence The example below illustrates the representation of a diagnostics message via a flashing sequence. The I/O LED indicates a data error on the local bus. The data error is caused by the removal of an I/O module located at the 6th position of the bus node.

  • Page 326: Meaning Of Blink Codes And Procedures For Troubleshooting

    This section describes the diagnostics presented as blink codes via the I/O LEDs. If the diagnostics cannot be cleared by the measured specified for them, contact WAGO support. Be ready to explain to them the blink code that is displayed. Phone:...

  • Page 327: Table 235: Error Code 1, Explanation Of Blink Codes And Procedures For

    WAGO I/O SYSTEM 750 XTR Diagnostics 327 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 235: Error Code 1, Explanation of Blink Codes and Procedures for Troubleshooting Error Cause Remedy Argument Invalid parameter Switch off the power to the controller checksum for local and replace it.

  • Page 328: Table 236: Error Code 2, Explanation Of Blink Codes And Procedures For

    328 Diagnostics WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 235: Error Code 1, Explanation of Blink Codes and Procedures for Troubleshooting Error Cause Remedy Argument Error occurred while Switch off the power to the controller writing to the serial and replace it.

  • Page 329: Table 237: Error Code 3, Explanation Of Blink Codes And Procedures For

    WAGO I/O SYSTEM 750 XTR Diagnostics 329 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 237: Error Code 3, Explanation of Blink Codes and Procedures for Troubleshooting Error Cause Solution Argument If a power supply module (e.g., 750-602) is connected to the controller, ensure that this module functions properly (see Section “LED Signaling”).

  • Page 330: Table 238: Error Code 4, Explanation Of Blink Codes And Procedures For

    330 Diagnostics WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 238: Error Code 4, Explanation of Blink Codes and Procedures for Troubleshooting Error Cause Solution Argument Switch off the power to the controller. Maximum permissible Reduce the number of I/O modules number of I/O modules to an acceptable value.

  • Page 331: Table 241: Error Code 9, Explanation Of Blink Codes And Procedures For

    WAGO I/O SYSTEM 750 XTR Diagnostics 331 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 241: Error Code 9, Explanation of Blink Codes and Procedures for Troubleshooting Error Cause Remedy Argument Invalid program Malfunction of the program sequence: statement Contact WAGO Support.

  • Page 332: Meaning Of Blink Codes And Procedures For Troubleshooting

    This section describes the diagnostics presented as blink codes via the MS LEDs. If the diagnostics cannot be cleared by the measured specified for them, contact WAGO support. Be ready to explain to them the blink code that is displayed. Phone: +49 571 887 44 55 5...

  • Page 333: Service

    WAGO I/O SYSTEM 750 XTR Service 333 750-8202/040-001 PFC200 2ETH RS TELE XTR Service 11.1 Inserting and Removing the Memory Card </dg_ 11.1.1 Inserting the Memory Card Use an actuating tool or a screwdriver to open the transparent cover flap by flipping it upwards.

  • Page 334: Removing The Memory Card

    334 Service WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 11.1.2 Removing the Memory Card First, remove any seal that may be in place. Use an actuating tool or a screwdriver to open the transparent cover flap by flipping it upwards.

  • Page 335: Firmware Changes

    Therefore, use only documentation appropriate for the target firmware after a firmware change. If you have any questions, feel free to contact our WAGO Support. 11.2.1 Perform Firmware Upgrade Do not switch the controller off! The controller can be damaged by interrupting the upgrade process.

  • Page 336: Perform Firmware Downgrade

    336 Service WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 11.2.2 Perform Firmware Downgrade Do not switch the controller off! The controller can be damaged by interrupting the downgrade process. Do not switch the controller off during the downgrade process and do not...

  • Page 337: Factory Reset

    Stored boot projects are deleted, including existing web visualization data. Subsequently installed firmware functions are not overwritten. If you have any questions, contact WAGO Support. The controller is restarted after the factory reset. Proceed as follows to factory reset the controller: Press the Reset button (RST).

  • Page 338: Removal

    338 Removal WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Removal Risk of injury due to sharp-edged blade contacts! The blade contacts are sharp-edged. Handle the I/O module carefully to prevent injury. Do not touch the blade contacts.

  • Page 339: Removing The I/O Module

    WAGO I/O SYSTEM 750 XTR Removal 339 750-8202/040-001 PFC200 2ETH RS TELE XTR 12.1.2 Removing the I/O Module Remove the I/O module from the assembly by pulling the release tab. Figure 108: Removing the I/O Module (Example) Electrical connections for data or power jumper contacts are disconnected when removing the I/O module.

  • Page 340: Use In Hazardous Environments

    WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Use in Hazardous Environments The WAGO I/O SYSTEM 750 (electrical equipment) is designed for use in Zone 2 hazardous areas and shall be used in accordance with the marking and installation regulations.

  • Page 341: Marking Configuration Examples

    WAGO I/O SYSTEM 750 XTR Use in Hazardous Environments 341 750-8202/040-001 PFC200 2ETH RS TELE XTR 13.1 Marking Configuration Examples 13.1.1 Marking for Europe According to ATEX and IECEx Figure 109: Marking Example According to ATEX and IECEx Figure 110: Text Detail – Marking Example According to ATEX and IECEx Manual Version 1.2.0, valid from FW Version 03.01.07(13)

  • Page 342: Table 244: Description Of Marking Example According To Atex And Iecex

    342 Use in Hazardous Environments WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 244: Description of Marking Example According to ATEX and IECEx Marking Description TUEV 07 ATEX 554086 X Approving authority resp. certificate numbers IECEx TUN 09.0001 X...

  • Page 343: Figure 111: Marking Example For Approved Ex I I/O Module According To

    WAGO I/O SYSTEM 750 XTR Use in Hazardous Environments 343 750-8202/040-001 PFC200 2ETH RS TELE XTR Figure 111: Marking Example for Approved Ex i I/O Module According to ATEX and IECEx Figure 112: Text Detail – Marking Example for Approved Ex i I/O Module According to ATEX and...

  • Page 344: Table 245: Description Of Marking Example For Approved Ex I I/O Module According To Atex And Iecex

    344 Use in Hazardous Environments WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 245: Description of Marking Example for Approved Ex i I/O Module According to ATEX and IECEx Marking Description TUEV 12 ATEX 106032 X Approving authority resp.

  • Page 345: (Cec)

    WAGO I/O SYSTEM 750 XTR Use in Hazardous Environments 345 750-8202/040-001 PFC200 2ETH RS TELE XTR 13.1.2 Marking for the United States of America (NEC) and Canada (CEC) Figure 113: Marking Example According to NEC Figure 114: Text Detail – Marking Example According to NEC 500...

  • Page 346: Figure 115: Text Detail - Marking Example For Approved Ex I I/O Module

    346 Use in Hazardous Environments WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Figure 115: Text Detail – Marking Example for Approved Ex i I/O Module According to NEC 505 Table 247: Description of Marking Example for Approved Ex i I/O Module According to NEC 505...

  • Page 347: Figure 117: Text Detail - Marking Example For Approved Ex I I/O Modules

    WAGO I/O SYSTEM 750 XTR Use in Hazardous Environments 347 750-8202/040-001 PFC200 2ETH RS TELE XTR Figure 117: Text Detail – Marking Example for Approved Ex i I/O Modules According to CEC 18 attachment J Table 249: Description of Marking Example for Approved Ex i I/O Modules According to CEC 18...

  • Page 348: Installation Regulations

    348 Use in Hazardous Environments WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 13.2 Installation Regulations For the installation and operation of electrical equipment in hazardous areas, the valid national and international rules and regulations which are applicable at the installation location must be carefully followed.
  • Page 349 WAGO I/O SYSTEM 750 XTR Use in Hazardous Environments 349 750-8202/040-001 PFC200 2ETH RS TELE XTR Explosive atmosphere occurring simultaneously with assembly, installation or repair work must be ruled out. Among other things, these include the following activities • Insertion and removal of components •...

  • Page 350: Special Notes Regarding Ansi/Isa Ex

    350 Use in Hazardous Environments WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 13.2.2 Special Notes Regarding ANSI/ISA Ex For ANSI/ISA Ex acc. to UL File E198726, the following additional requirements apply: • Use in Class I, Division 2, Group A, B, C, D or non-hazardous areas only •...

  • Page 351: Appendix

    (with word alignment). The internal mapping method for data greater than one byte conforms to Intel formats. The following section describes the representation for WAGO I/O SYSTEM 750 XTR I/O modules in the process image, as well as the configuration of the process values.

  • Page 352: Digital Input Modules

    352 Appendix WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 14.1.1 Digital Input Modules The digital input modules provide a process value of one bit per channel, which indicates the status of the respective channel. These bits are mapped into the input process image.

  • Page 353: Digital Output Modules

    WAGO I/O SYSTEM 750 XTR Appendix 353 750-8202/040-001 PFC200 2ETH RS TELE XTR 14.1.2 Digital Output Modules The digital output modules provide one bit as the process value per channel that indicates the status of the respective channel. These bits are mapped into the output process image.

  • Page 354: 4-Channel Digital Output Modules With Diagnostics And Input Data

    354 Appendix WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 14.1.2.4 4-Channel Digital Output Modules with Diagnostics and Input Data In addition to the 4-bit process values in the output process image, the digital output modules provide 4 bits of data in the input process image. A diagnostic bit for each output channel indicates an overload, short circuit or wire breakage.

  • Page 355: 16-Channel Digital Output Modules

    WAGO I/O SYSTEM 750 XTR Appendix 355 750-8202/040-001 PFC200 2ETH RS TELE XTR 14.1.2.7 16-Channel Digital Output Modules Table 259: 16-Channel Digital Output Modules Output Process Image Bit 15 Bit 14 Bit 13 Bit 12 Bit 11 Bit 10 Bit 9 Bit 8 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0...

  • Page 356: Analog Input Modules

    Information on the structure of control and status bytes For detailed information on the structure of a particular I/O module’s control/status bytes, please refer to that module’s manual. Manuals for each module can be found on the Internet at www.wago.com. 14.1.3.1 2-Channel Analog Input Modules...

  • Page 357: 3-Phase Power Measurement Module

    WAGO I/O SYSTEM 750 XTR Appendix 357 750-8202/040-001 PFC200 2ETH RS TELE XTR 14.1.3.3 3-Phase Power Measurement Module The above Analog Input Modules have a total of 9 bytes of user data in both the Input and Output Process Image (6 bytes of data and 3 bytes of control/status).

  • Page 358: Analog Output Modules

    Information on the structure of control and status bytes For detailed information on the structure of a particular I/O module’s control/status bytes, please refer to that module’s manual. Manuals for each module can be found on the Internet at www.wago.com. 14.1.4.1 2 Channel Analog Output Modules...

  • Page 359: Specialty Modules

    WAGO I/O SYSTEM 750 XTR Appendix 359 750-8202/040-001 PFC200 2ETH RS TELE XTR 14.1.5 Specialty Modules In addition to the data bytes, the control/status byte is also displayed for select I/O modules. This byte is used for the bi-directional data exchange of the I/O module with the higher-level control system.

  • Page 360: Ssi Transmitter Interface I/O Modules

    360 Appendix WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 14.1.5.2 SSI Transmitter Interface I/O Modules The process image depends on the parameterized operating mode! The operating mode of the configurable I/O module can be set. Based on the operating mode, the process image of these I/O modules is then the same as that of the respective version.

  • Page 361: Table 268: Counter Modules

    WAGO I/O SYSTEM 750 XTR Appendix 361 750-8202/040-001 PFC200 2ETH RS TELE XTR and Output Process Image, which has a total of 3 words mapped into each image. Word alignment is applied. Table 268: Counter Modules Input Process Image Byte Designation...

  • Page 362: Can Gateway

    362 Appendix WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR 14.1.5.5 CAN Gateway The process image size of the CAN Gateway can be set in the specified sizes of 8, 12, 16, 20, 24, 32, 40 or 48 bytes.

  • Page 363: Codesys 2 Libraries

    WAGO I/O SYSTEM 750 XTR Appendix 363 750-8202/040-001 PFC200 2ETH RS TELE XTR 14.2 CODESYS 2 Libraries Additional functions for the controller 750-8202/040-001are provided using libraries. 14.2.1 General Libraries This section contains general CODESYS libraries supported by the controller 750-8202/040-001.

  • Page 364: Syslibcom.lib

    364 Appendix WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 271: CODESYS System Libraries Library Function C/IEC 61131 SysTaskInfo.lib Evaluation of task information in IEC 61131 the Online mode Util.lib Various logical operations IEC 61131 Util_no_Real.lib...

  • Page 365: Syslibfile.lib

    WAGO I/O SYSTEM 750 XTR Appendix 365 750-8202/040-001 PFC200 2ETH RS TELE XTR 14.2.1.3 SysLibFile.lib The controller 750-8202/040-001supports the following function blocks of the “SysLibFile.lib” library: SysFileClose SysFileCopy SysFileDelete SysFileEOF SysFileGetPos SysFileGetSize SysFileGetTime SysFileOpen SysFileRead SysFileRename SysFileSetPos SysFileWrite Ensure that files are saved! Files are not reliably saved on the data medium until you call up the “SysFileClose”...

  • Page 366: Syslibfileasync.lib

    366 Appendix WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 272: Possible Macros for File Access Macro Booting from Internal Memory Booting from Memory Card HOME:// “/home/codesys/” “/home/codesys/” (internal NAND memory) (memory card) CARD:// “/media/sd/” “/home/codesys/”...

  • Page 367: Syslibrtc.lib

    Additional information about this is given in the online Help function for CODESYS-IDE. 14.2.1.6 BusDiag.lib The controller 750-8202/040-001 supports the following function blocks of the “BusDiag.lib” library: DiagGetBusState DiagGetState The document containing a description of this library and the function blocks it includes is available for download on the Internet at www.wago.com.

  • Page 368: Mod_Com.lib

    PI_INFORMATION SET_DIGITAL_INPUT_OFFSET SET_DIGITAL_OUTPUT_OFFSET SLAVE_ADDRESS The document containing a description of this library and the function blocks it includes is available for download on the Internet at www.wago.com. 14.2.1.8 SerComm.lib The controller 750-8202/040-001supports the following function blocks of the “SerComm.lib” library:...

  • Page 369: Table 275: Description Of The Configuration Scripts For "Information

    WAGO I/O SYSTEM 750 XTR Appendix 369 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 275: Description of the Configuration Scripts for “Information” Parameters Status Call-Up Output/Input Effective Controller Details: Identifies various information about the controller Product get_coupler_details read Product description...

  • Page 370: Table 276: Description Of The Configuration Scripts For "Codesys

    370 Appendix WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 276: Description of the Configuration Scripts for “CODESYS” Parameters Status Call Output/Input Effecti Information CODESYS get_coupler_details Version of the CODESYS Immedia Webserver read codesys-Webserver- Webserver tely...

  • Page 371: Table 277: Description Of The Configuration Scripts For "Networking - Host/Domain Name

    WAGO I/O SYSTEM 750 XTR Appendix 371 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 277: Description of the Configuration Scripts for “Networking - Host/Domain Name” Parameters Status Call Output/Input Effecti Host Name Display of the host name. The return value is blank when...
  • Page 372 372 Appendix WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 278: Description of the Configuration Scripts for “Networking - TCP/IP” Parameters Status Call Output/Input Effecti Default Gateway 1 Current status of the default gateway 1. get_default_gateway_...

  • Page 373: Table 279: Description Of The Configuration Scripts For "Networking - Ethernet

    WAGO I/O SYSTEM 750 XTR Appendix 373 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 279: Description of the Configuration Scripts for “Networking - ETHERNET” Parameters Status Call-Up Output/Input Effective Switch Configuration Query the switch configuration: Possible return values: read get_dsa_mode 0 = „switched“...

  • Page 374: Table 280: Description Of The Configuration Scripts For "Ntp

    374 Appendix WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 280: Description of the Configuration Scripts for “NTP” Parameters Status Call Output/Input Effecti Configuration Data Query the status of the NTP server get_ntp_config read Possible return values are:...

  • Page 375: Table 281: Description Of The Configuration Scripts For "Clock

    WAGO I/O SYSTEM 750 XTR Appendix 375 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 281: Description of the Configuration Scripts for “Clock” Parameters Status Call-Up Output/Input Effective Clock Time and Date get_clock_data read Local time and date date-local Date on device,...

  • Page 376: Table 282: Description Of The Configuration Scripts For "Administration

    376 Appendix WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 282: Description of the Configuration Scripts for "Administration" Parameters Status Call Output/Input Effecti Configuration of Service Interface User of the serial interface. Active: Current value Configured: Value set, but not...

  • Page 377: Table 284: Description Of Configuration Scripts For "Ports And Services" - "Network Services

    WAGO I/O SYSTEM 750 XTR Appendix 377 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 284: Description of Configuration Scripts for “Ports and Services” – “Network Services Parameters Status Call-Up Output/Input Valid Network Services Telnet Read the status of the Telnet server.

  • Page 378: Table 285: Description Of Configuration Scripts For "Ports And Services" - "Plc Runtime Services

    378 Appendix WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 285: Description of Configuration Scripts for “Ports and Services” – “PLC Runtime Services” Parameters Status Call Output/Input Effecti General Settings Version of the enabled PLC runtime...
  • Page 379 WAGO I/O SYSTEM 750 XTR Appendix 379 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 285: Description of Configuration Scripts for “Ports and Services” – “PLC Runtime Services” Parameters Status Call Output/Input Effecti CODESYS 2 Settings Read status of the runtime-...
  • Page 380 380 Appendix WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 285: Description of Configuration Scripts for “Ports and Services” – “PLC Runtime Services” Parameters Status Call Output/Input Effecti e!Runtime Settings Read status of the runtime- get_runtime_config cfg-...

  • Page 381: Table 286: Description Of Configuration Scripts For "Ports And Services" - "Ssh/Tftp

    WAGO I/O SYSTEM 750 XTR Appendix 381 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 286: Description of Configuration Scripts for “Ports and Services” – “SSH/TFTP” Parameters Status Call-Up Output/Input Valid SSH Server Read the status of the SSH port. Possible return values:...
  • Page 382 382 Appendix WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 287: Description of Configuration Scripts for “SNMP” Parameters Status Call-Up Output/Input Valid General SNMP information parameters get_snmp_data Specifies the SNMP parameter Right read device-name “sysName”. away...

  • Page 383: Table 287: Description Of Configuration Scripts For "Snmp

    WAGO I/O SYSTEM 750 XTR Appendix 383 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 287: Description of Configuration Scripts for “SNMP” Parameters Status Call-Up Output/Input Valid SNMP Trap Receiver Configuration for v1 and v2c Any number of trap receivers can be configured. A trap receiver that has been set up is always active;...
  • Page 384 384 Appendix WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 287: Description of Configuration Scripts for “SNMP” Parameters Status Call-Up Output/Input Valid Configuration of SNMP v3 Any number of SNMP v3 users can be created. A user that has been set up is always active; the complete data set must be deleted to deactivate a user.

  • Page 385: Wagolibcpuusage.lib

    The controller 750-8202/040-001supports the following function blocks of the “WagoLibCpuUsage.lib” library: CPU_Usage The document containing the description of the library and the function block it includes is available for download on the Internet at www.wago.com. Manual Version 1.2.0, valid from FW Version 03.01.07(13)

  • Page 386: Wagolibdiagnosticids.lib

    “WagoLibDiagnosticIDs.lib” library: DIAGNOSTIC_SEND_ID DIAGNOSTIC_SET_TEXT_FOR_ID The document containing the description of the library and the function block it includes is available for download on the Internet at www.wago.com. 14.2.1.12 WagoLibLed.lib The controller 750-8202/040-001supports the following function blocks of the “WagoLibLed.lib” library:...

  • Page 387: Wagolibnetsnmpmanager.lib

    SNMPM_GET_V3 SNMPM_SET SNMPM_SET_V3 The document containing a description of this library and the function blocks it includes is available for download on the Internet at www.wago.com. 14.2.1.15 WagoLibSSL.lib The controller 750-8202/040-001supports the following function blocks of the “WagoLibSSL.lib” library: SSL_CTX...

  • Page 388: Wagolibterminaldiag.lib

    The controller 750-8202/040-001supports the following function blocks of the “WagoLibTerminalDiag.lib” library: GET_TERMINALDIAG The document containing a description of this library and the function blocks it includes is available for download on the Internet at www.wago.com. Manual Version 1.2.0, valid from FW Version 03.01.07(13)

  • Page 389: List Of Figures

    Figure 30: Carrier Rail Contact (Example) ............99 Figure 31: Cable Shield at Ground Potential ............. 100 Figure 32: Examples of the WAGO Shield Connecting System ......101 Figure 33: Application of the WAGO Shield Connecting System ...... 101 Figure 34: “Open DHCP”, Example Figure ............105 Figure 35: CBM main menu (example) ..............
  • Page 390 WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Figure 48: “WAGO Ethernet Settings” – Identification Tab (Example)....233 Figure 49: “WAGO Ethernet Settings” – Network Tab ........234 Figure 50: “WAGO Ethernet Settings” – Protocol Tab ........236 Figure 51: “WAGO Ethernet Settings”...
  • Page 391 WAGO I/O SYSTEM 750 XTR List of Figures 391 750-8202/040-001 PFC200 2ETH RS TELE XTR Figure 95: Selecting the Visualization Technique in the Target System Settings ..................... 279 Figure 96: Creating the PLC_VISU Starting Visualization ......... 280 Figure 97: CODESYS PLC Configuration - Modbus Settings ......287 Figure 98: Modbus Process Image ..............

  • Page 392: List Of Tables

    Table 38: Loading a Boot Project ................ 80 Table 39: WAGO DIN Rail ................... 85 Table 40: Permissible WAGO Carrier Rails When Using XTR PFC200 ....85 Table 41: Filter Modules for 24 V Power Supply ..........93 Table 42: Legende for Figure “Power Supply Concept” ........94 Table 43: Legend for Figure “Power Supply Example”...
  • Page 393 WAGO I/O SYSTEM 750 XTR List of Tables 393 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 45: Default IP Addresses for ETHERNET Interfaces ....... 104 Table 46: Network Mask 255.255.255.0 ............104 Table 47: User Settings in the Default State ............119 Table 48: WBM “Status Information”...
  • Page 394 394 List of Tables WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 79: WBM “Configuration of the users for the Web-based Management” Page – “Change Password for Selected User” Group ......145 Table 80: WBM “Create Bootable Image” page – “Create bootable image from active partition”...
  • Page 395 WAGO I/O SYSTEM 750 XTR List of Tables 395 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 110: WBM “Configuration of General SNMP Parameters” Page – “General SNMP Configuration” Group ............172 Table 111: WBM “Configuration of SNMP v1/v2c Parameters” Page –...
  • Page 396 396 List of Tables WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 144: “Networking” > “Host/Domain Name” > “Domain Name” Submenu ....................191 Table 145: “Networking” > “TCP/IP” Submenu ..........191 Table 146: “Networking” > “IP Address” Submenu ..........192 Table 147: “Networking”...
  • Page 397 WAGO I/O SYSTEM 750 XTR List of Tables 397 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 186: “Ports and Services” > “DHCPD” Submenu ........219 Table 187: “Ports and Services” > “DHCPD” > “Xn” Submenu ......219 Table 188: “Ports and Services” > “DNS” Submenu .......... 220 Table 189: “Ports and Services”...
  • Page 398 398 List of Tables WAGO I/O SYSTEM 750 XTR 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 229: Diagnostics via SYS LED ..............318 Table 230: Diagnostics RUN LED ..............319 Table 231: RUN LED Diagnostics ..............320 Table 232: Diagnostics I/O LED ................ 321 Table 233: MS-LED Diagnostics ................
  • Page 399 WAGO I/O SYSTEM 750 XTR List of Tables 399 750-8202/040-001 PFC200 2ETH RS TELE XTR Table 264: 4 Channel Analog Output Modules ..........358 Table 265: Serial interfaces with alternative data format ........359 Table 266: SSI transmitter interface modules with alternative data format ..360 Table 267: Incremental Encoder Interface ............
  • Page 400 WAGO Kontakttechnik GmbH & Co. KG Postfach 2880 • D - 32385 Minden Hansastraße 27 • D - 32423 Minden Phone: +49 571 887 – 0 Fax: +49 571 887 – 844169 E-Mail: info@wago.com Internet: www.wago.com...

Table of Contents

Save PDF
