2. Apply the Master's Explicit Request Messages to change the Slave's
Baud Rate.
Master (MAC ID =0x0A)
_ Group 2 Message
|
_ Destination MAC ID=0x09
|
|
_ Message ID =4
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
ID=10 001001 100. Data= 0A 10 03 01 02
_ Group 2 Message
|
_ Source MAC ID=0x09
|
|
_ Message ID =3
|
|
|
|
|
|
|
|
|
|
|
|
ID=10 000011 011. Data= 0A 90
Note: After finishing the change of the MAC ID on-line, the I-7242D will send a
shutdown message and reset. However if users want to change the baud rate
of I-7242D, they must send the reset service to reset the I-7242D. Then the
new baud rate of the I-7242D will become effective.
I-7242D DeviceNet/Modbus RTU Gateway User's Manual, July 2006, Version 1.1
_ Frag=0. Transaction ID=0. Destination MAC ID= 0x0A
|
_ Service=Set Attribute Request
|
| _ Class ID=3
|
| | _ Instance ID=1
|
| | | _ Attribute ID=2
|
| | | |
_
Attribute Data= 0x01 -- New Baud Rate
01
_ Frag=0. Transaction ID=0. Destination MAC ID= 0x0A
|
_ Service= Set Attribute Response
|
|
|
|
I-7242D user manual
Slave (MAC ID =0x09)
88/124
