The i-7241D DNS/DCON Gateway
1. Introduction
This manual introduces the user to implement the i-7241D module
into their applications in a quick and easy way. This document only
provides with the basic instructions. For more detailed information, please
refer to the i-7241D user manual located on the ICPDAS CD-ROM or
download it from the ICPDAS web site:
http://www.icpdas.com/download/can/Gateway_Converter.htm
The goal of this manual is focused on helping users to quickly
familiarize themselves with the i-7241D module. Users can apply the i-
7241D module as follows.
i-7241D DNS/DCON Gateway Quick Start User Guide (Version 1.3, Jan/2008) ------ 1
Quick Start User Guide

Advertisement

loading

Related Manuals for ICP DAS USA i-7241D

Summary of Contents for ICP DAS USA i-7241D

  • Page 1 This document only provides with the basic instructions. For more detailed information, please refer to the i-7241D user manual located on the ICPDAS CD-ROM or download it from the ICPDAS web site: http://www.icpdas.com/download/can/Gateway_Converter.htm...

  • Page 2: Hardware Structure

    ‘2’ -> Hardware Error 5-> 38400 bps ‘d’ -> Default Setting 6-> 57600 bps 7-> 115200 bps CAN bus baud rate 0-> 125K bps 1-> 250K bps 2-> 500K bps i-7241D DNS/DCON Gateway Quick Start User Guide (Version 1.3, Jan/2008) ------ 2...

  • Page 3: How To Start

    4. Apply EDS file in DeviceNet application After configuring the i-7241D and creating the specific EDS files, apply the EDS file to your DeviceNet application. 5. Start to communicate with DeviceNet master i-7241D DNS/DCON Gateway Quick Start User Guide (Version 1.3, Jan/2008) ------ 3...

  • Page 4: Hardware Installation

    Step 2: Before using the utility tool, connecting the i-7000 modules and the i-7241D correctly. Then turn off the i-7241D and connect the INIT* pin with the GND pin. Step 3: Turn on the i-7241D. Execute the CAN_GW.exe file. The startup figure would be displayed.
  • Page 5 Step 4: Press the “Connect” button to connect the i-7241D. Then the “Com Port Scan Parameter Setting” dialog will be pop-up as follows. Please set the correct Com port communication parameters to scan the i-7000 modules. Then press the “OK” button to scan the modules.
  • Page 6 Step 7: Press “Build EDS file” to start to build the specific EDS file for the i-7241D. If the I/O connection path stored in EEPROM of i-7241D is not matched with before setting, the warning dialog box would pop-up. Step 8: Start to build the specific EDS file for your DeviceNet gateway. The DeviceNet EDS file information is according to the following dialog box.
  • Page 7 Step 11: The last step is to press the “Finish” button to create the EDS file and store these information into the i-7241D’s EEPROM. You can find the EDS file “DNS_DCONx.eds” in the path of CAN_GW.exe.
  • Page 8 IO connection object. The other is by using an explicit message to set/get the IO attribute of application object. Release the use of the Predefined Master/Slave Connection Set. i-7241D DNS/DCON Gateway Quick Start User Guide (Version 1.3, Jan/2008) ------ 8...
