The I-7231D CPS/DCON Gateway
1. Introduction
This user guide introduces the user how to implement the I-7231D
module into their applications in a quick and easy way. Therefore, it only
provides the basic instructions. For more detail information about the I-
7231D, please refer to the I-7231D user manual in the product CD or
download it from following web site:
http://www.icpdas.com/download/can/index.htm
The purpose of this manual is focused on helping users to quickly
familiarize themselves with the I-7231D module. Users can apply the I-
7231D module as follows.
I-7231D CPS/DCON Quick Start User Guide (Version 1.1,Oct/2004, I-7231D) ------ 1
Quick Start User Guide

Advertisement

Table of Contents

   Related Manuals for ICP DAS USA I-7231D

   Summary of Contents for ICP DAS USA I-7231D

  • Page 1 Therefore, it only provides the basic instructions. For more detail information about the I- 7231D, please refer to the I-7231D user manual in the product CD or download it from following web site: http://www.icpdas.com/download/can/index.htm...
  • Page 2 CAN Baud rate: RS-485 Baud rate: 800 K bps 57600 bps Refer to the right Refer to the right 1000 K bps 115200 bps hand side table hand side table 231D CPS/DCON Quick Start User Guide (Version 1.1,Oct/2004, I-7231D) ------ 2...
  • Page 3 I- specific EDS files, turn off the I- 7231D on the CAN network 7231D, remove the wire between the Init* pin and Gnd pin, and turn on the I-7231D. I-7231D CPS/DCON Quick Start User Guide (Version 1.1,Oct/2004, I-7231D) ------ 3...
  • Page 4 COM port of your PC. Also, connect the configured I-7000/87K modules with the COM2 of the I-7231D. The architecture is displayed in the following figure. Step 3: Turn off the I-7231D firstly. Connect the INIT* pin and the GND pin on the I- 7231D. Then, turn on the I-7231D.
  • Page 5 Step 7: When the DCON modules have been scanned, the scan result will be compared with the parameters stored in the EEPROM of the I-7231D. If any difference has been detected, the warning message will pop up as follows.
  • Page 6 After clicking the “Setting” button, users can see that the each field of the CAN Parameter Viewer frame is changed to the value configured in the CAN Parameter Setting frame on the left hand side. I-7231D CPS/DCON Quick Start User Guide (Version 1.1,Oct/2004, I-7231D) ------ 6...
  • Page 7 Step 11: User can click the “PDO Information”, “Device Information “, and “Dcon Information button to view the PDO objects, device profile and I-7000/87K configuration information. These information dialogs are shown below. I-7231D CPS/DCON Quick Start User Guide (Version 1.1,Oct/2004, I-7231D) ------ 7...
  • Page 8 EEPROM of the I-7231D. Then, user can use this EDS on any CAN master interface. Step 12: Power off the I-7231D, and remove the wire between the Init* pin and GND pin on the I-7231D. Then, power on the I-7231D. When the I-7231D has finished the initialization, the RUN LED on the I-7231D will be flashed about twice per second, and the I-7231D is into the NMT pre-operational state.
