GW-7472 / GW-7473
EtherNet/IP to Modbus RTU/TCP Gateway

User Manual

Warranty
All products manufactured by ICP DAS are under warranty regarding defective
materials for a period of one year, starting from the date of delivery to the original
purchaser.
Warning
ICP DAS assumes no liability for damages resulting from the use of this product.
ICP DAS reserves the right to change this manual at any time without notice. The
information published by ICP DAS is believed to be accurate and reliable.
However, no responsibility is assumed by ICP DAS for its use, not for any
infringements of patents or other rights of third parties resulting from its use.
Copyright
Copyright © 2014 by ICP DAS Co., Ltd. All rights are reserved.
Trademark
The names used for identification only may be registered trademarks of their
respective companies.
GW-7472 / GW-7473 User Manual, Version 2.5, June 2014
