ELITEpro XC™ SAFETY SUMMARY AND SPECIFICATIONS
This general safety information is to be used by both
the Logger operator and servicing personnel. DENT
Instruments, Inc. assumes no liability for user's
failure to comply with these safety guidelines.
The ELITEpro XC™ is an Over-Voltage Category III device. Use approved rubber gloves with mechanical
protection and goggles when operating the device.
CAUTION: This LOGGER may contain life threatening voltages. QUALIFIED PERSONNEL MUST disconnect all high
voltage wiring before using or servicing the LOGGER.
SYMBOLS ON EQUIPMENT
Shop for Dent products online at:
Warning: Use of this device in a manner for which it is not intended may impair its
means of protection.
Denotes caution. See manual for a description of the meanings.
When connecting the ELITEpro XC to an AC load, follow these steps in sequence to
prevent a shock hazard.
1. If possible, de-energize the circuit to be monitored.
2. Connect the CTs to the phases being monitored.
3. Connect the voltage leads to the different phases. Use proper safety
equipment (gloves, mask, and protective clothing) as required for the
voltages monitored.
Risk of electric shock. Life threatening voltages may be present. Qualified personnel
only.
DO NOT EXCEED 600V Phase to Phase. This logger is equipped to monitor loads up
to 600V. Exceeding this voltage will cause damage to the logger and danger to the
user. Always use a Potential Transformer (PT) for loads in excess of 600V. The
ELITEpro XC is a 600 Volt Over Voltage Category III device.
Dispose of properly.
IN: 6-10 VDC, 500 mA
OUT: 6 VDC, 200 mA maximum
