Wifi And Wireless Access Point Connection (Optional) - DENT Instruments ELITEpro XC Operator's Manual

W F W
I I AND IRELESS
When the ELITEpro XC is equipped with the optional WiFi module it may
be used in one of two ways: as a WiFi connection to an existing WiFi
network or in Access Point Mode where the logger connects one-to-one
to a single device such as a laptop or smart phone.
Connection ranges also depend on whether an internal or high-gain
external antenna is used.
ELITEpro XC as its own Access Point
Using the ELITEpro XC as an Access Point "Hot Spot" is probably its most useful mode. As a Hot Spot, the
logger allows one-to-one connection between the meter and a WiFi enabled device such as a laptop
computer, tablet, or smartphone.
1) Set up the logger for Access Point connection. Connect the USB cable to a USB port on your
computer, inserting the other end in the USB port on the ELITEpro XC (Hint: Look for this USB
symbol:
voltage or wrapped in an appropriately rated insulating sleeve. The DENT-supplied cable does not
meet this requirement without an insulating sleeve.
2) If it does not launch automatically, start ELOG 14 and connect to the logger.
3) From the ELOG menu, select Logger > Communication > Logger WiFi Setup.... The Logger WiFi Setup
dialog box appears.
Shop for Dent products online at:
A P C
CCESS OINT ONNECTION
). If a USB cable is used inside an electrical panel, it must be rated to the appropriate
PowerMeterStore
www.
(O )
PTIONAL
116
D Y K ? The WiFi
ID OU NOW
connection will work over a
range of 30 to 300ft range,
depending on the
installation environment.
Range is limited when
mounted within a metal
cabinet.
