3) Enter the CT Phase Shift if different from the default value. Or, choose the RōCoil radio button if you
are using them for your connection.
4) Click OK.
Once the Quick Setup is completed, the View Typical Setup button appears in the Quick Setup area of
the screen. Clicking this button displays a wiring diagram that corresponds to the selected setup,
showing how to connect the CTs and the voltage leads of the ELITEpro XC. The diagram can be printed
and carried into the field for easy reference during installation. Refer to ELOG Quick Setup Wiring
Diagrams for detailed information of each Quick Setup option.
Additionally, depending on the setup, Calculated Power Channels with configuration options display in
the lower section of the Setup Table screen. See Calculated Power Channels.
P P
HYSICAL OWER
The ELITEpro XC has four configurable hardware channels corresponding to the current transformers or
other sensors.
1) Click on the maximize button in the upper right-hand corner of the Setup Table window to display as
much of the full screen as possible.
Shop for Dent products online at:
CT-CON-0150EZ
CT-CON-1000
CT-SCS-0050
CT-SCS-0100
CT-SCM-0100
CT-SCM-0200
CT-SCM-0400
CT-SCM-0600
CT-SCL-0600
CT-SCL-1000
CT‐SHS‐0005
Mini 20A
Mini 50A
MIDI 100A
MIDI 200A
Recommended CT Phase Shift Value
