Page 1 Operator’s Guide ELITEpro XC ™ ELOG™ 14 Software ™ ™ ELITEpro XC /ELOG October 23, 2014 PowerMeterStore 1.877.766.5412 www. .com Shop for Dent products online at:...
Page 2 You now own one of the world’s most versatile, accurate, feature-rich, and lowest priced power/energy loggers, the ELITEpro XC™. The ELITEpro XC logger contains many features, some of which enable you to measure data across multiple platforms, view and graph real-time data, and retrieve data remotely.
Page 3: Table Of Contents
ELITEpro XC™ RÉSUMÉ DE SÉCURITÉ ET SPÉCIFICATIONS........... 11 ELITEpro XC™ TECHNICAL SPECIFICATIONS ................ 14 ELITEpro XC™ CONNECTIONS .................... 16 SECTION I: Installing, Setting Up, and Using the ELITEpro XC™ ........... 17 Install the ELOG Software on the Computer.................. 17 Mount the ELITEpro XC ........................18 ELITEpro XC Connections ......................
Page 4 Using The 2-Watt Element (2 Ct) Method On A 3-Wire Delta Service ........94 Using The 3-Watt Element (3 Ct) Method On A 3-Wire Delta Service ........95 Appendix C—Troubleshooting ELITEpro XC Driver Installation ............. 97 Appendix D—AUTOPOLL: Unattended Data Collection ............... 101 AutoPoll Menu Options ......................
Page 5 Appendix F—Communication Options ..................112 USB (Standard) ........................112 Ethernet LAN (Standard) ....................... 113 WiFi and Wireless Access Point Connection (Optional) ............116 ELITEpro Mobile App (Optional) .................... 122 Bluetooth (Optional) ......................126 Cell Modem Connection (Optional)..................129 Index ..........................130 PowerMeterStore 1.877.766.5412 www.
Page 6: Introduction
The measurements are stored in on-board, non- volatile memory in a time series format at an interval selected by the user. The ELITEpro XC can be mounted anywhere with its magnetic back and is small enough to be secured inside the electrical panel.
Page 7 And there’s much more: As always, there have been a number of improvements made to the software to improve performance, increase ease of use, and reduce issues. Enjoy these new features! PowerMeterStore 1.877.766.5412 www. .com Shop for Dent products online at:...
Page 8: Elitepro Xc™ Safety Summary And Specifications
4RH8 E186827 The ELITEpro XC™ is an Over-Voltage Category III device. Use approved rubber gloves with mechanical protection and goggles when operating the device. CAUTION: This LOGGER may contain life threatening voltages. QUALIFIED PERSONNEL MUST disconnect all high voltage wiring before using or servicing the LOGGER.
Page 9 Do not use other CTs. Only use shunted CTs with a 333mV maximum output only. Serious shock hazard and logger damage can occur if unshunted CTs are used. The UL listing covers the use of the following DENT Instruments CTs that are UL Recognized and have been evaluated to IEC 61010-1: CT-HSC-020-X (20A Mini), CT-HSC-050-X (50A Mini), CT-HMC-0100-X (100A Midi), and the CT-HMC-0200-X (200A Midi).
Page 10 Battery Life: The lithium battery is only used to maintain the date and clock settings during power failure and has a life expectancy of greater than 10 years. Contact DENT Instruments for service. No accessories are approved for use with the ELITEpro XC other than those specified in the DENT Instruments product literature and price sheets.
Page 11: Elitepro Xc™ Résumé De Sécurité Et Spécifications
600V. Le dépassement de cette tension peut causer des dommages à l'appareil et du danger pour l'utilisateur. Utiliser toujours le potentiel transformateur (PT) pour des charges de plus de 600V. Le ELITEpro XC est un appareil à 600 V de surtension de catégorie III. Se débarrasser de correctement.
Page 12 IN: 6-10 VDC, 500 mA OUT: 6 VDC, 200 mA maximum USB port LIMITATIONS DE DÉTECTEUR UTILISEZ SEULEMENT TRANSFORMATEURS DE COURANT (TC) SHUNTÉE. N’utilisez pas d'autres TC. Utilisez seulement des TC shuntée avec une puissance maximale 333mV. Un sérieux risque de décharge électrique et des dommages à l'enregistreur peut se produire si des TC pas shuntée sont utilisés.
Page 13 Il n'y a aucun entretien requis avec le ELITEpro XC. Respectez les points suivants: Nettoyage: Aucun agents de nettoyage, y compris l'eau, doit être utilisé sur le ELITEpro XC. Espérance de Vie de la Batterie: La pile au lithium est utilisée uniquement pour maintenir les paramètres de date et d'heure en cas de coupure de le courant et a une espérance de vie de plus de 10...
Page 14: Elitepro Xc™ Technical Specifications
ELITEpro XC™ TECHNICAL SPECIFICATIONS Specification Description Memory 16 MB non-volatile Single Phase-Two Wire, Single Phase-Three Wire, Three Phase-Four Wire (WYE), Three Service Types Phase-Three Wire (DELTA), DC Systems (solar/battery). Voltage Channels 3 channels, CAT III, 0-600 VAC (line-to-line) or 600 VDC Current Channels 4 channels, .67 VAC max, +/- 1 VDC max;...
Page 15 Power From L1 Phase to L2 Phase. 80-600V (AC or DC) CAT III DC/50/60Hz, 125 mA, 5 W, or 10 VA max. Line Power Supply Non-user replaceable .5 Amp internal fuse protection. Power In (optional) 6-10 VDC maximum, 500 mA minimum Mechanical Operating Temperature -7 to + 60°C (20 to 140°F)
Page 16: Elitepro Xc™ Connections
PhaseChek LEDs Terminal Block for Analog Input Connections Optional WiFi—External 5 dbi antenna Ethernet connection Power In/Out Magnetic Mounting Feet CT Connections Voltage Lead Connections ELITEpro XC Top End View PowerMeterStore 1.877.766.5412 www. .com Shop for Dent products online at:...
Page 17: Section I: Installing, Setting Up, And Using The Elitepro Xc
SECTION I: INSTALLING, SETTING UP, AND USING THE ELITEpro XC™ IMPORTANT: DO NOT CONNECT THE ELITEpro XC TO YOUR COMPUTER UNTIL YOU HAVE INSTALLED ELOG 14 Install the ELOG Software on the Computer Complete this step prior to installation and ascertain that communication between the ELITEpro XC and PC is established before going into the field.
Page 18: Mount The Elitepro Xc
AVERTISSEMENT! ENLEVEZ L'ENREGISTREUR DE TOUTES LES SOURCES DE TENSION AVANT DE MONTER. 1) To mount the ELITEpro XC, use the black tab on the end of the case containing the PhaseChek and voltage lead connections. Using a screw, securely mount the ELITEpro XC near a dedicated circuit disconnect breaker.
Page 19: Elitepro Xc Connections
USB connector for high speed downloads, setup, and communication with a computer. The  ELITEpro XC is also powered from the USB connection. If a USB cable is to be used inside an electrical panel, it must be rated to the appropriate voltage or wrapped in an appropriately rated insulating sleeve.
Page 20: Complete The Wiring Connections
X (200A Midi). The use of any other CT will invalidate the UL Listing of the ELITEpro XC. 1) Connect the CTs to the channel(s) on the ELITEpro XC labeled CH 1, CH 2, CH 3 and CH 4. The CT leads need to be connected to the terminal block using a small screwdriver.
Page 21 Connecting Split-Core Style Millivolt CTs to a Load 1) Open the CT by holding on to the removable leg and pulling it apart. 2) Connect CT around the load conductor to be measured. Make sure the maximum current of the conductor does not exceed the maximum CT rating listed on the CT data sheet.
Page 22: Voltage Connections
5) Connect the white wire on the CT to the positive terminal on the measuring device. 6) Connect the black wire on the CT to the negative terminal on the measuring device. Current Transformer connections Voltage lead connections ? Correct orientation of a CT is required to ensure proper measurement.
Page 23 CT. Repeat the above three steps if you are using more than one RōCoil CT. To connect the CTs wires to the terminals on the ELITEpro XC: 1) Connect the CTs brown wire to the negative terminal on the connector.
Page 24: Analog Channel Connections
Typical uses might include logging ambient temperature, building temperatures, solar insolation, tank pressures, duct flows etc. The ELITEpro XC™ has four analog input channels that can be configured for voltage or current input used in any combination among channels. The limiting specifications for analog input are shown below.
Page 25 NOTE: The ELITEpro XC™ can measure input voltages up to 30.0 volts. The polarity protection circuitry however can only withstand 15 volts of reverse applied polarity without permanent damage to the meter. The maximum allowable current flowing into the analog input terminal is 23 mA.
Page 26 24 volt DC supply. The ELITEpro XC™ has four measurement channels. The negative terminals of each channel are common to each other and connected to the reference plane for power measurements. For this reason it is imperative that the ELITEpro XC™ be connected as the last component in the current loop rather than the first if multiple channels are used.
Page 27 Sensor Power Supply Separately Excited Current or Voltage Loop Configuration PowerMeterStore 1.877.766.5412 www. .com Shop for Dent products online at:...
Page 28: Power In/Out Connection
1) To power the ELITEpro XC using an external supply contact DENT Instruments for an appropriately rated power supply. 2) The ELITEpro XC can also supply 6V DC at up to 200mA to an external device when the ELITEpro XC voltage leads are connected to mains power between 80 and 600 VAC.
Page 29 NOTE: The Power Channel drop-down list displays any enabled channel, allowing users to choose which one(s) to use as a source for the pulses. For example, if the setup table is only configured to measure one power channel, no other options will be available in the Power Channel drop-down list.
Page 30 5) Upon completion of your pulse output measurements, disconnect the wires of your device. PowerMeterStore 1.877.766.5412 www. .com Shop for Dent products online at:...
Page 31: Connecting The Usb Cable
1) Connect the USB cable to an available USB port on the computer and insert the other end in the COM port of the ELITEpro XC. If a USB cable is used inside an electrical panel, it must be rated to the appropriate voltage or wrapped in an appropriately rated insulating sleeve.
Page 32: Other Communication Connections
THER OMMUNICATION ONNECTIONS The RJ-45 Connector is for Ethernet Network connections.  NOTE: The Ethernet connector accommodates high speed downloads, setup and communication with a computer. If an Ethernet cable is to be used inside an electrical panel, it must be rated to the appropriate voltage or wrapped in an appropriately rated insulating sleeve. The Coax connector, if present, is for an optional external WiFi antenna.
Page 33: Communicating With The Elitepro Xc
Communicating with the ELITEpro XC 1) Plug the USB cable into the logger and the PC. ELOG 14 should auto-launch and connect to the ELITEpro XC. If not, double-click the ELOG icon on the PC desktop. The ELOG window opens,...
Page 34 The Logger Connection information displays along the bottom of the window, providing a status message as the computer connects to the ELITEpro XC. Simultaneously, the logger’s COMM LED will begin to flash. ELOG fills the information fields of the Logger Connection...
Page 35: Terminating The Elitepro Xc To Computer Connection
ELITE ERMINATING THE OMPUTER ONNECTION To end the connection between the computer and the ELITEpro XC, select Logger > Communication > Terminate Connection. -or- Use the Disconnect speed button to quickly terminate the connection. PowerMeterStore 1.877.766.5412 www. .com Shop for Dent products online at:...
Page 36: Section Ii: Elitepro Xc, Best Practices
The ELITEpro XC requires that it be configured for use by first creating a “Setup Table” file and then loading the file into the meter. The ELITEpro XC is a flexible meter that can monitor a wide variety of parameters over a wide range of currents, voltages and service types. This requires that you determine what is recorded and at what intervals.
Page 37: Open An Existing Setup Table On Your Pc
2) Select ELITEpro XC from the drop-down menu. 3) Click OK. PEN AN XISTING ETUP ABLE ON Existing Setup Tables on the computer can be opened, modified and saved. 1) Select File>Open to display the Open dialog box. 2) Select Setup Table File and click OK.
Page 38: Retrieve An Existing Setup Table From The Elitepro Xc
ETRIEVE AN XISTING ETUP ABLE FROM THE Existing setup tables on the ELITEpro XC can be retrieved once the computer and the logger are connected and communicating. Select Logger>Retrieve Logger Setup Table.  The setup table stored in the logger is retrieved and displayed, with the name of the file above the ELOG menu bar.
Page 39: Configure The Setup Table
ABLE The Setup Table consists of several sections where the attributes of the ELITEpro XC are defined. ELITEpro XC is the default entry. This field cannot be edited once you are in the Setup Logger Type Table window. Logger type must be chosen from the Select A Setup Table Type window.
Page 40: Data Logging Controls
The feature is dynamic so that any time any parameter in a Setup Table affecting the memory duration is changed, the Memory Capacity field is updated, providing the (new) length of time the logger’s memory will last. The ELITEpro XC has 16 MB internal non-volatile memory. PowerMeterStore 1.877.766.5412...
Page 41: Quick Setups
UICK ETUPS The Quick Setups section of the window provides four buttons to quickly configure the ELITEpro XC. 1) Click the Quick Setup button that represents your monitoring scenario. Each button opens the CT Selection dialog window. See ELOG Quick Setup Wiring Diagrams at the end of this section for more detail.
Page 42: Physical Power Channels
Clicking this button displays a wiring diagram that corresponds to the selected setup, showing how to connect the CTs and the voltage leads of the ELITEpro XC. The diagram can be printed and carried into the field for easy reference during installation. Refer to ELOG Quick Setup Wiring Diagrams for detailed information of each Quick Setup option.
Page 43 NOTE: The PT Ratio is used when monitoring voltages greater than 600 VAC (maximum rating of the ELITEpro XC). Use an instrument grade transformer with low phase shift and high accuracy since errors in the transformer will translate directly into errors in the recorded data. The PT Ratio value put into the Setup Table in the logger should be the transformer primary:secondary ratio.
Page 44 AC voltages greater than 600V. The default is 1.000. Type This is the type of CT connected to the Choices are: MilliVolt or RōCoil. ELITEpro XC Amps Depends on the type of CT selected. Displays the value entered in the CT Size screen. Phase Shift Compensate for CT Phase Shift with this setting.
Page 45: Calculated Power Channels
ALCULATED OWER HANNELS Channels 5 and 6 are the Calculated Power Channels. They combine the data from two or more power channels (also called "hardware” or “physical channels") and are used primarily for calculating total system volts, amps, kW, kVA, power factor, and kVAR in polyphase or multiple single phase systems. The Calculated Power Channels are frequently used to: Record total system power parameters ...
Page 46: Analog Output Channels
The following graphic is an example of a Setup Table for a 3-phase 4-wire connected load using a Calculated Power Channel with Combine Channels 1, 2, and 3 selected to optimize memory usage on the ELITEpro XC. NOTE: The Recorded values are not shown for simplicity.
Page 47: Send A Setup Table To The Logger
OGGER When you’ve finished selecting the configuration options, the setup table needs to be sent to the ELITEpro XC. 1) After connecting to the logger, click on one of the SEND SETUP TABLE to Logger command buttons on the Setup Table screen.
Page 48: Save A Setup Table On The Computer
Typical Setup. This button displays a schematic Now the ELOG software is configured and the graphic of how to connect the ELITEpro XC to a ELITEpro XC is connected and monitoring can load. The schematic can be printed and carried begin.
Page 49: Led Diagnostics
COMM—C OMMUNICATIONS The ELITEpro XC COMM LED flashes different colors (green, blue, red) to indicate that the logger is connected, logging information, and communicating with the computer. Which color indicating which condition is dependent on the version of firmware being used by the logger. However; one color always indicates the same condition: green will flash approximately once per second when the ELITEpro XC is logging and communicating with the computer.
Page 50: Power Measurement-Connecting Sensors & Configuring Channels
WARNING: Use of this device in a manner for which it is not intended may impair its means of protection. Do not exceed 600 VAC into voltage inputs! When connecting the ELITEpro XC to an AC load, follow these steps in sequence to prevent a shock hazard.
Page 51: Wiring Label Conventions
IEC 61010-1 standard by other Nationally Recognized Testing Laboratories (NRTLs), the use of any other CT will invalidate the UL Listing of the ELITEpro XC. This is simply a decision made by UL, and in the opinion of DENT Instruments, all CTs provided are equally safe to use.
Page 52 1000A 600A Current Ratings of CTs Available from DENT Instruments All of the CTs in the table are available from DENT Instruments. ? You can extend These are internally shunted CTs (333mV output) which make the leads for a RōCoil up to 100...
Page 53: Ct Selection Examples
CT value to be used in the Logger setup table, multiply the utility CT ratio by the ELITEpro XC CT size (e.g. if the utility CT is 4000:5 and the DENT CT is 50A use (4000/5) x 50 = 40,000 for the value of the CT in the logger Setup Table.
Page 54: Elog Quick Setup Wiring Diagrams
Clicking this button displays a wiring diagram that corresponds to the selected setup, showing how to connect the CTs and the voltage leads of the ELITEpro XC. The diagram can be printed and carried into the field for easy reference during installation.
Page 55 Single Phase, 2-Wire PowerMeterStore 1.877.766.5412 www. .com Shop for Dent products online at:...
Page 56 Single Phase, 3-Wire PowerMeterStore 1.877.766.5412 www. .com Shop for Dent products online at:...
Page 57 3 Phase, 3-Wire Delta PowerMeterStore 1.877.766.5412 www. .com Shop for Dent products online at:...
Page 58 3 Phase, 4-Wire Wye PowerMeterStore 1.877.766.5412 www. .com Shop for Dent products online at:...
Page 59: Using The Elog Software
The ELOG speed buttons enable users to quickly navigate between commonly used functions. For ™ over a serial or Bluetooth connection, example, to connect between the computer and the ELITEpro XC use the button instead of the menu commands Logger > Communication > Connect Via... The button toolbar can be toggled on and off by selecting the View >...
Page 60 Setup PC: Quickly access computer setup configurations Create Graph: Create a graph from an open data file, available under the Data dropdown menu UnZoom Graph: Use to back out of an expanded graph Help Topics: Opens the ELITEpro XC and ELOG Manual PowerMeterStore 1.877.766.5412 www.
Page 61: File Menu
Descriptions of other options are below: File > New creates a new file. There are four file types that are available for ELITEpro XC ™ loggers. ELOG Data File—contains data retrieved from a logger. If the computer is already connected to ...
Page 62: Edit Menu
 a logger, ELOG prompts you to select the logger type (ELITEpro XC) for which you want to create a new Setup Table. If you are already connected to a logger, ELOG assumes that the Setup Table you are about to create is for the logger type to which you are connected.
Page 63: View Menu
The Connection Window appears at the bottom of the screen during connection to a logger and provides information about the logger, communication port, baud rates, etc. Refer to Communicate with the ELITEpro XC in Section 1 for more information. The Toolbar option enables/disables buttons under the main menu.
Page 64: Logger Menu
OGGER The Logger menu is used to configure the ELITEpro XC, view channel data in real time, download logger data, and set communication parameters. Graphing and analysis functions are found under the Data menu. Communication Sub-Menu Use the options on the Communication sub-menu to establish a connection between the computer and the ELITEpro XC.
Page 65 The options on the Communication sub-menu determine how communication with the ELITEpro XC is established and where logger information is saved. PC Setup  Use this option to set the default location for data, setup tables, and logger files. You can also set the default PC communication ports here.
Page 66 Choose From Last Used Logger List…  Use this option to connect to a logger contained in a recently used logger list. Cancel Communications Operation  During any communication operation between the computer and the logger (connecting, retrieving data, viewing real time values), this option may be used to cancel the current communication command.
Page 67 About The Connected Logger…  This option displays a text window containing information about the currently connected logger’s properties, such as logger type, firmware version, description, etc., and information about built-in communication options, if any. Click Refresh to retrieve new information (for example, if the number of records used is changing) or OK to close the window.
Page 68 Retrieve Data From Logger Retrieves data from the logger and saves it as an .elog file on the hard disk. The Select A Directory And A Name… dialog box displays prompting you for a file name. The default name is the logger serial number plus two digits that correspond to the number of times that data has been retrieved from the logger, however, at this point you may name the data file whatever you wish.
Page 69 When the data is retrieved, a second comma separated value format (.csv) file can be created at the same time as the .elog data file is being downloaded. A .csv file is also called a “flat file,” or “ASCII file” and can be opened in other applications such as spreadsheets and databases.
Page 70 Display Real-Time Values Sub-Menu The Display Real Time Values option shows instantaneous readings for channels in use in either a textual or graphical format. Real-Time Values are an excellent way to verify the correct installation of a meter. Real-Time Values may be displayed in either a textual or graphical format. Show As Text ...
Page 71 Click Exit to close the window. Show As Graphs  This menu selection displays the data as a graph instead of the text format described previously. Select Logger > Display Real-Time Values > Show as Graphs to display the following dialog window. 1) Select any or all physical power channels currently turned on in the logger in the Hardware Channels To Display section.
Page 72 3) Select OK to view the graph. The graph presentation is very similar to paper strip chart recorders. The graph begins on the left edge and moves to the right. When it reaches the right edge, the entire graph scrolls to the left with each new reading.
Page 73 Use Export Graph to save the graph in a graphical or textual format. Graphs can be saved in an  .emf, .wmf, .bmp, .jpg (default), .png format or as ASCII text file. You can select where the graph will go (clipboard, file, or printer) and what measurements (pixels, millimeters, inches, points) are used to save the graph.
Page 74 Harmonics  Select Logger > Display Real-Time Values > Harmonics to see the actual harmonic content in the current, voltage, and power waveforms. A typical display is shown here: The buttons along the lower left side of the window ? The individual harmonic select the Channel to be displayed.
Page 75 The image presented is a single waveform snapshot. The first image is by default channel 1, but you can select different channels and update the image, copy the image to the clipboard for pasting into other programs, or print the image. You can also record the harmonic values to your PC and then view a log of the harmonics in a spreadsheet.
Page 76 Retrieve Logger Setup Table This function instantly retrieves the Setup Table in the logger so it can be viewed, edited, resent to the logger or saved to the hard disk. Logger Clock Sub-Menu This function is used to set the logger’s internal clock time and date. You may change the clock manually or synchronize it to the computer's clock.
Page 77 Edit Logger Description Line This option allows you to change the user-defined, one line description stored in the logger. The Description Line can be used to help identify the specific logger after the logger has been retrieved from the field. Logging ON/OFF This option starts or stops data collection.
Page 78 Clear Logger Sub-Menu There are three options for clearing data stored in the Logger: Clear all logger data, Clear only peak demand values (kW, kVA, & kVAR), or Clear only KWh, KVARh, KVAh, etc., totals. After the data is deleted, it cannot be retrieved. See the section Clear Logger Sub-menu for more information. Do not select any options until you are sure that all information should be deleted from the logger.
Page 79: Tools Menu
PC Setup Selecting Tools > PC Setup allows you to configure the computer connected to the ELITEpro XC. It is also where you set the default file storage folders. Data Files Saved To: ...
Page 80 The Enable Auto Launch of ELOG checkbox defaults to enable the Auto Launcher, which launches ELOG (if not already open) when an ELITEpro SP or ELITEpro XC or newer ELITEpro is connected to a USB port. When not checked, it disables the feature and hides the Auto Launcher icon in the system tray.
Page 81: Data Menu
Data retrieved from an ELITEpro XC can be opened, graphed, exported, or analyzed. NOTE: These are the only options available on the Data menu when first accessed. The other options appear after a data file is open. Create New Graph 1) When a data file is open, Data >...
Page 82 3) Use Record Range to define a Starting and Ending range, or select the All Records checkbox to display all records available. Options default to All Records, but unchecking the box enables you to set the Record Range. 4) Click Next to go to the Set Graph Parameters dialog window to select the type of graph to create. 5) Under Axes, select the Graph Type in the drop-down menu.
Page 83 Once created, the graph may be edited in a number of ways. In general, any editable feature may be changed by double-clicking on the graph and making changes in the dialog box that appears. For example: Double-clicking anywhere in the graph area ...
Page 84 Graph Data Cursor: The data cursor is a vertical line that appears on a graph and is used to help  visually line up multiple graphs. Use the Show graph data cursor check box to turn on the data cursor. It can also be turned on and off at any time while viewing a graph by clicking the right mouse button.
Page 85 Open Data File Data files stored on the logger can be viewed (but not edited) by selecting this menu item. To view a data file it must first be downloaded from the logger by using the Logger > Retrieve Data... command or Data >...
Page 86 3) Select a file and click Open. When the file data has exported to a .csv file format the ELOG File Export dialog box displays. 4) Start a spreadsheet program such as Excel™. 5) Use the File > Open command in the spreadsheet and select All Files in the Files of type drop-down list.
Page 87 Example of a Data Summary Peak Demand  Provides a report of peak demand information on the channels used for collecting the data. The Peak Demand report is opened in Microsoft Notepad™ and can be edited, saved, printed and/or moved into another report. NOTE: Calculations for peak demand are only available when Channels 5, 6 are on.
Page 88 Analyze a Selected Data Range ELOG has a number of analysis features. With a data file open: NOTE: The analyses features only work on one variable at a time. A variable may be selected in several ways all using standard Windows™ methods. 1) To select an entire column of data, place the mouse pointer over the column header (e.g., Chan 1 Avg.
Page 89 Each time an analysis function is used and File is selected, Notepad is opened and the result of the analysis function is added to the existing Notepad file. For the first five analysis functions, Average is the arithmetic average of all the values in the selected column within the date range of data selected.
Page 90 Check Data for Errors Use this command to check the data shown for gaps or overlaps in the time sequence, or timestamp errors. Fill Missing Records "Fill Missing Records" detects gaps in the time sequence of the data shown, and fills the missing records with 0 values.
Page 91: Section Iii: Appendices
IRMWARE PDATES You can check the firmware version of your ELITEpro XC from the Tools menu. Select Tools > Update Logger Firmware. The Firmware Update dialog box displays. No update is required if your firmware File version and Logger Version are the same.
Page 92: Appendix B-Unusual Metering Systems
Appendix B—Unusual Metering Systems “W ” (R HASE ELTA WITH A 3 Phase DELTA with a “Wild” (Red) Leg Configure the Setup Table as follows: PowerMeterStore 1.877.766.5412 www. .com Shop for Dent products online at:...
Page 93: 2-½ Element Meters
2-½ Element Meters Configure the Setup Table as follows: *The CT on channel three of the ELITEpro XC is placed on the L2 phase and is backwards. Note that the Ch3 CT is jumpered in parallel into Ch4 of the logger.
Page 94: Using The 2-Watt Element (2 Ct) Method On A 3-Wire Delta Service
***Set the CT value that is true for the CT connected to the ELITEpro XC. Again, because the 2 ½ element method is most often used in high voltage applications, there will be high voltage CTs present. Use the high-accuracy 5A CT from DENT Instruments on the existing high voltage CT secondary. The CT value used in the Setup Table should be the primary rating of the high voltage CT (assuming the secondary output is 5A).
Page 95: Using The 3-Watt Element (3 Ct) Method On A 3-Wire Delta Service
Volts X Amps and VA would contain harmonic content. The other is Displacement Power Factor that uses the Power triangle PF=W/SQRT (W^2 + VAR^2) which does not contain harmonic content. The ELITEpro XC displays and records displacement Power Factor. PowerMeterStore 1.877.766.5412...
Page 96 It is very similar to the 3-phase, 4-wire WYE connection. Use a CT on each phase and connect the three ELITEpro XC voltage wires to each phase. The neutral wire should then be connected to earth ground. The Setup table should look just like that of the 4-wire WYE setup. See ELOG Quick Setup Wiring Diagrams in Section II.
Page 97: Appendix C-Troubleshooting Elitepro Xc Driver Installation
Appendix C—Troubleshooting ELITEpro XC Driver Installation If you have connected the ELITEpro XC to a computer via the USB cable and the driver fails to install, follow these steps to correct the problem. 1) Go to the Device Manager by right-clicking My Computer in the Start Menu and selecting Properties.
Page 98 Windows XP 3) Look for the ELITEpro XC listed in the Device Manager Window: PowerMeterStore 1.877.766.5412 www. .com Shop for Dent products online at:...
Page 99 5) In the Hardware Update Wizard, select Install from a list or specific location (Advanced) and click Next. 6) In the next window, select Search for driver software in this location: and Include Subfolders in the search. Click Browse and locate the ELITEpro XC driver folder in the ELOG directory. PowerMeterStore 1.877.766.5412 www.
Page 100 7) Click Next> and the ELITEpro XC driver will install. In the event that you receive a warning dialog box from Microsoft, click Continue to proceed. 8) Unplug the ELITEpro XC and plug it back in. ELOG 14 should launch and automatically connect to the ELITEpro XC.
Page 101: Appendix D-Autopoll: Unattended Data Collection
Appendix D—AUTOPOLL: Unattended Data Collection When ELOG is installed onto the PC, AutoPoll is also installed. AutoPoll may be used for unattended and automatic data retrieval from a number of remote loggers where the PC calls the loggers. AutoPoll (short for Automatic Polling) is a stand-alone Windows application program that may be launched from ELOG by using the Logger >...
Page 102 Save (Ctrl+S) and Save As:  These functions allow you to save an open Logger List using the current name and location (Save) or with a new name and/or to a new location on the PC hard drive (Save As). Print ...
Page 103 View Menu View is used to toggle the Toolbar and Status Bar on or off as desired. The Toolbar contains the speed buttons and the Status Bar is the line at the bottom of the screen that reports the callout status. The Current Call List is the active Logger List that is being used by AutoPoll to schedule calls to loggers.
Page 104 Lists may be selected is set here. The Direct Connect section shows the port and baud rate of the connected ELITEpro XC. The Modem Connect section displays connection information about legacy products. Enter an amount of minutes into the Final Delay Time box to retry data retrieval one last time.
Page 105 AutoPoll Log. An excerpt example of the Log is shown below: At the end of each call, a dashed line is added to the bottom of the file to separate calling sessions. - DENT Instruments - AutoPoll Event Log File...
Page 106: Understanding The Logger Lists
As subsequent polling sessions are completed, the autopoll.log file is automatically updated and the new contact reports are appended to the existing .log file. The maximum size of the autopoll.log file is 1 Megabyte. If this limit is exceeded, AutoPoll automatically changes the existing .log file into a .bak (backup)and starts a new .log file.
Page 107 Configuring a Logger List Clicking Setup in the Logger List brings up the following screen for entering network connections and AutoPoll tasks: Connection Tab  The default connection type is Network. If the logger is to be used on a network enter the IP Address and Port Number assigned to the logger.
Page 108 The default call schedule shown above is a Single Call on January 1st at 00:00 (Midnight). Because the Append New Data button is selected, when the PC calls the logger only the “new” data in the logger stored since the last data download will be retrieved. Logger Tasks Set Logger Clock—If the Set Logger Clock box is checked then, after the PC calls the logger and the data download is complete, the PC will set the logger clock to the PC time.
Page 109 Call Interval Five choices are available for automatic polling and data retrieval however only one Call Interval may be selected at a time. The choices are: Immediate Call—Calls the logger as soon as the AutoPoll program is initiated. Use this to test the system after completing a logger installation to verify correct operation.
Page 110: Appendix E-Calculated Power Channel Formulas
Appendix E—Calculated Power Channel Formulas The following information details the formulas used to calculate the parameters available in the Power Sum Channels 5 and 6. L1-N, L2-N, L3-N ONFIGURATION Measurement Formula Notes/Description L1 + L2 + L3 Amps (System) Average of L1, L2, and L3 amp values. For a Phase to Neutral with WYE Sum of three phase to neutral voltages configured meter.
Page 111: Delta Configuration: L1-L2 And L3-L2
DELTA C : L1-L2 L3-L2 ONFIGURATION When using the 2 CT method. When using the 3 CT method on a Delta service the channel 5 and 6 Power Sum equations are the same as for the WYE configuration shown above. Measurement Formula Notes/Description...
Page 112: Appendix F-Communication Options
2) ELOG 14 should launch automatically and connect to the logger. If it does not, click on the icon on the computer desktop. 3) The ELITEpro XC should automatically connect to the PC. If it does not, choose the correct location from the Friendly Ports™ drop-down menu. For more information regarding Friendly Ports™, see Communicate with the ELITEpro XC in Section 1.
Page 113: Ethernet Lan (Standard)
Ethernet port 1) Configure the EXC for use on the network. First connect the USB cable to a USB port on your computer, inserting the other end into the USB port on the ELITEpro XC. (Hint: Look for this USB symbol: ) If a USB cable is used inside an electrical panel, it must be rated to the appropriate voltage or wrapped in an appropriately rated insulating sleeve.
Page 114 4) Configure the Logger Ethernet Setup information once the ELITEpro XC has established a connection with the PC. a) From the ELOG menu, select Logger > Communication > Logger Ethernet Setup... The Logger Ethernet Setup dialog box displays. The Ethernet connection must have an IP Address that can either be set manually with the Use Static IP address option (for a fixed address) or obtained automatically from the router connected to the logger using the Use DHCP option (dynamic address).
Page 115 b) If necessary, change the Port Number. The factory default is 3001 and will usually work in most cases. The use of the Subnet Mask and Gateway Address are outside the scope of this manual. If needed, ask the network administrator for assistance c) Click Update Logger.
Page 116: Wifi And Wireless Access Point Connection (Optional)
ELITEpro XC as its own Access Point Using the ELITEpro XC as an Access Point “Hot Spot” is probably its most useful mode. As a Hot Spot, the logger allows one-to-one connection between the meter and a WiFi enabled device such as a laptop computer, tablet, or smartphone.
Page 117 6) Click Save Changes in the Logger WiFi Setup dialog box. ELOG updates the WiFi settings and prompts you to click OK in order to reset the ELITEpro XC. NOTE: After the blue COMM LED on the ELITEpro XC device stops blinking, use the ELOG command Logger >...
Page 118 PC in Step 7 above: a) Open a web browser in the smart device. b) In the Address box of the browser, enter the IP Address of the ELITEpro XC, which is: 192.168.1.1 c) When the login page appears, enter the Web Page Password you set in the Logger WiFi Setup dialog box in step 5 above.
Page 119 1) Set up a WiFi logger for connection to a wireless network first. Connect the USB cable to a USB port on your computer, inserting the other end in the USB port on the ELITEpro XC (Hint: Look for this USB symbol: ).
Page 120 Logger > Communication > About the Connected Logger… to see the IP address. 8) Click Save Changes. ELOG updates the WiFi settings and prompts you to click OK in order to reset the ELITEpro XC. NOTE: After the blue COMM LED on the ELITEpro XC device stops blinking, use the ELOG command Logger >...
Page 121 “No TCP connection” message. Ensure the blue COMM LED is not blinking. 4) If you are unable to make a connection, contact DENT Instruments for questions and assistance. NOTE: The WiFi access point has a 5 minute inactivity timeout. After 5 minutes of no usage the connection is dropped.
Page 122: Elitepro Mobile App (Optional)
OBILE PTIONAL The ELITEpro Mobile App provides access to any Wi-Fi-equipped ELITEpro XC or SP meter. Use this app in a remote setting, such as your car or office, to access data from an ELITEpro meter. Once connected with the meter, you can see real-time data to verify connections and read voltage, current, kW, kVA, PF, kVAR, and other parameters.
Page 123 The Real time Data Tab This tab allows you to see if you have the correct values and verify your connections. This tab shows voltage, currents, KW, KVA, PF, and KVAR by scrolling to the right and left. All of these values are being read directly from the EXC and are being updated every second.
Page 124 View Record This tab shows the last recorded record with the time stamp. You can scroll to the right or left to see all of your selected recorded values. Select Update to view the newest record. Graph This tab displays a Phasor plot graph. Using the graph you can see the phase relationship between the voltage and the current.
Page 125 Logger Properties On this tab the current settings and options are shown. For example, you are shown the current settings of the wired network, wireless network, and what Port you are using. Logger Settings The properties of the logger are shown. Memory capacity, integration period and status of logging (ON or OFF) are displayed.
Page 126: Bluetooth (Optional)
Connections must be configured initially via USB by users with knowledge of Windows Bluetooth wireless technology enabled products. To make a Bluetooth connection from a PC to an ELITEpro XC both devices must have a Bluetooth module. Most PCs, including laptops, do not have Bluetooth and it may be necessary to purchase a Bluetooth dongle (usually a plug-in USB device) and add it to the PC.
Page 127 1) Click Add a Device. You should then see a list of Bluetooth devices external to the PC including the ELITEpro XC identified by its serial number. (The logger may be the only device the PC sees.) 2) Select the desired ELITEpro XC and click Next.
Page 128 If you are unable to connect to the logger, check the following items: 1) In Windows Control Panel, open Devices and Printers and verify that the ELITEpro XC is shown in the Bluetooth devices along with the Bluetooth module in the PC. If not, reinstall the PC’s Bluetooth device and/or re-pair the PC to the logger.
Page 129: Cell Modem Connection (Optional)
ODEM ONNECTION PTIONAL The cell modem connection option is limited based on availability and customer requirements. Contact DENT Instruments for further information and assistance. PowerMeterStore 1.877.766.5412 www. .com Shop for Dent products online at:...
Page 130: Index
INDEX communications, AutoPoll ..........103 active Logger list, AutoPoll ..........103 configuring a power channel ..........42 Analog Connections ............24 creating a CSV file ............. 69 analog inputs ..............123 CT Connection appending new data ............68 polarity ................ 53 AutoPoll ..............
Page 131 ............. 84 annotation ..............84 attributes ..............84 creating................ 82 data cursor ..............84 ELITEpro XC ............See Logger data options ..............83 communicating with ............ 33 data points..............84 Configure using the ELOG Logger Menu ...... 64 export ................
Page 132 ..............85 options ................. 44 Summaries polarity ................ 22, 53 data, setup, logger ............86 Port preferences ............... 33 symbols on the ELITEpro XC ..........8 friendly ports..............33 PowerMeterStore 1.877.766.5412 www. .com Shop for Dent products online at:...
Page 133 View record ..............124 terminate connection ............66 Tools Menu ............... 79 voltage connections ............24 PC Setup ..............33, 79 voltage rating ..............24 Restore Hidden Messages ..........80 Update Logger Firmware ..........80 troubleshooting communications............34 troubleshooting ESP driver installation ......97 Waveform capture ............

DENT Instruments ELITEpro XC Operator's Manual

Introduction

Elitepro XC™ SAFETY SUMMARY and SPECIFICATIONS

Elitepro XC™ RÉSUMÉ de SÉCURITÉ ET SPÉCIFICATIONS

Elitepro XC™ TECHNICAL SPECIFICATIONS

Elitepro XC™ CONNECTIONS

SECTION I: Installing, Setting Up, and Using the Elitepro XC

SECTION II: Elitepro XC, Best Practices

Section III: Appendices

Appendix A-Installing Firmware Updates

Appendix B-Unusual Metering Systems

Appendix C-Troubleshooting Elitepro XC Driver Installation

Appendix D-Autopoll: Unattended Data Collection

Appendix E-Calculated Power Channel Formulas

Appendix F-Communication Options

Index

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DENT Instruments ELITEpro XC

Summary of Contents for DENT Instruments ELITEpro XC

Table of Contents
