DENT Instruments ELITEpro XC Operator's Manual page 119

ELITEpro XC Connected to a
Wireless Network
In addition to acting as an Access Point for one-to-one connections, an ELITEpro XC with the WiFi
module may also be connected to a local area network (LAN) through a wireless access point or wireless
router. To set up the logger it must first be configured via a USB connection to a PC running ELOG and
may require assistance from someone familiar with the network you want to connect to. Below is a
diagram of this communication method:
1) Set up a WiFi logger for connection to a wireless network first. Connect the USB cable to a USB port
on your computer, inserting the other end in the USB port on the ELITEpro XC (Hint: Look for this
USB symbol:
appropriate voltage or wrapped in an appropriately rated insulating sleeve. The DENT-supplied cable
does not meet this requirement without an insulating sleeve.
2) If it does not launch automatically, start ELOG 14 and connect to the logger.
3) From the ELOG menu, select Logger > Communication > Logger WiFi Setup.... The Logger WiFi Setup
dialog box appears.
