Elitepro Mobile App (Optional) - DENT Instruments ELITEpro XC Operator's Manual

ELITE M
PRO OBILE
The ELITEpro Mobile App provides access to any Wi-Fi-equipped ELITEpro XC or SP meter. Use this app in
a remote setting, such as your car or office, to access data from an ELITEpro meter. Once connected with
the meter, you can see real-time data to verify connections and read voltage, current, kW, kVA, PF,
kVAR, and other parameters. You can also see a Phasor plot graph that displays the phase relationship
between voltage and current.
How it Works:
1) Download the ELITEpro Mobile app.
2) Connect to the ELITEpro access point.
3) Open the app and log in.
Read analog inputs

Get real-time data

Plot Phasor graphs

View logger properties

Erase data

Installing the App
1) Download the Mobile App from the store.
2) Open the App installer icon.
3) Select the ELITEpro Mobile App and install the program. You are given an option of Done or Open
after the app is installed. Select Done.
Using the ELITEpro Mobile App
Set the EXC to Access Point (AP) mode and make sure you are using Port 80. Then connect your smart
device to the EXC's wireless network. Next, open the ELITEpro Mobile App and enter the EXC's IP
address and password.
Shop for Dent products online at:
A (O )
PP PTIONAL
When you are using AP mode with the EXC, the EXC address will be
192.168.1.1 and the default password is 1234. After entering the IP address
and password, tap the Login and the App will open to the Real Time Data tab.
