DENT Instruments ELITEpro XC Operator's Manual page 15

Line Power Supply
Power In (optional)
Operating Temperature
Humidity
Enclosure
Weight
Dimensions
Operating System
Processor
Hard Drive
Communications Port
CD Drive
Shop for Dent products online at:
Power
From L1 Phase to L2 Phase. 80-600V (AC or DC) CAT III DC/50/60Hz, 125 mA, 5 W, or 10
VA max.
Non-user replaceable .5 Amp internal fuse protection.
6-10 VDC maximum, 500 mA minimum
Mechanical
-7 to + 60°C (20 to 140°F)
5% to 95% non-condensing
ABS plastic, 94-V0 flammability rating
340 g (12 ounces, excluding sensors and leads)
69 x 58 x 203 mm (2.7" x 2.2" x 8.0")
Minimum System Requirements
Windows® 7 (32 or 64 bit), Windows 8, Vista (32 or 64 bit) or XP
Pentium Class 1 GHz or more recommended
50 MB minimum available
One USB
CD or DVD drive required if using the CD software installation
