Output Contactor Configuration [Output Ctctr Cfg]
Linear Number: 5
Default Value: Not Running
Access Level: Basic
Read/Write: Read/Write when Stopped
This parameter specifies the conditions under which the output contactor will be commanded to open by
the drive. The possible contactor configurations specified by this parameter are:
Not Running
All Faults
Special Features [Special Features]
Linear Number: 99
Default Value: 0000000000000000
Access Level: Advanced
Read/Write: Read/Write when Stopped
This parameter is used to enable features in the drive. The options available are:
Bit Enum Text
0 Rvs Enable
1 ActDischarge
2 UWV Ph Rot'n
3 FrceCool Mtr
4 Rvs Encoder
5 SyncXfr Enab
6 Metric Units
7 BiDr FlyStrt
8 Heavy Duty
9 UltraHvyDuty
10 LineVoltSync
11 EnergySaving
12 Process PID
13 Unused
14 Unused
15 Unused
Contact factory for availability
Load Loss Detection [Load Loss Detect]
Linear Number: 199
Default Value: Disabled
Access Level: Advanced
Read/Write: Read/Write
This parameter specifies the response of the drive to a loss of load condition.
specifically designed for down-hole pump applications, where the user would normally not want to run
with a loss of load, as that is not a normal condition for this type of pump application. Refer to Motor
Protection group for parameters needed to configure this feature. This parameter has the following options:
Disabled
Warning
Fault
Open the contactor when not running
Open the contactor for any fault condition in the drive
Drive Reverse mode is enabled
Active Discharge mode is enabled**
UWV as Forward Phase Rotation
Force Cooled Motor**
Reverse Encoder direction(for Sync motor drives only)**
Synchronous transfer is enabled
Use metric units
Bidirectional flying start is enabled
Drive is designed for Heavy Duty Applications
Drive is designed for Ultra Heavy Duty (>150%) Application enabled
Use Line Voltage for Synchronous transfer
Enable Unity Power Factor compensation
Enable Process PID controller
The drive will operate normally in the event of a Load Loss condition
The drive will run with a warning indication in the event of a load loss condition
The drive will shutdown on a Class2 fault in the event of a load loss condition
Parameter Descriptions
Description
7000-TD002A-EN-P – September 2007
2-27
