1-2
Functional Description
Description of Operation
7000-TD002A-EN-P – September 2007
A complete block diagram of the PF7000 control circuit is shown in
Figure 1.1. The major blocks are described in the following sections.
Figure 1.1 – Functional Block Diagram of PF 7000 control system
Flux Range
Inv Flux
CurCmd
InvTorque
CurCmd
